Stormscope - Adjustment/Test - Eclipse EA500 Maintenance Manual

AMM-34-40-50-071-A-801
1. General
A. This task gives the procedures to perform the Adjustment/Test for the Lightning Detection
System (LDS). The LDS on the aircraft is referred to by it's trademark name
Stormscope®. The left hand GPS 400W is GPS 1 and right hand is GPS 2. Stormscope
is only displayed on the left hand (GPS 1) unit. The Stormscope computer is on the
options rack in the maintenance bay. The Stormscope antenna is mounted internally
under the upper over fin fairing on top of the horizontal stabilizer.
B. Testing Matrix:
(1) If the 331 DT - Upper Overfin Fairing is not installed, perform
AMM-34-40-50-071-A-701-001
(2) If the 331 DT - Upper Overfin Fairing is installed, perform
AMM-34-40-50-071-A-701-002
2. Equipment and Materials
Table 501. Special Tools and Equipment (AMC Automated Procedure):
External Battery Pack, (PowerVamp, Model APS1500
WX-PA Portable Analyzer (L3 Com P/N 78-8060-5791-1)
3. Job Set-Up
SUBTASK AMM-34-40-50-071-A-921-001
A. Make aircraft safe for maintenance. Refer to
Maintenance.
B. Connect an External Battery Pack to the aircraft EXTERNAL POWER RECEPTACLE
and turn on power. Ensure the green EXT POWER light on the IPL is on. But do not turn
on aircraft's power. Refer to
Practices.
C. Remove (if necessary) 331 DT - Upper Over Fin Fairing. Refer to
AMM-55-10-12-001-801 – Overfin Fairing - Removal.
D. Remove 311 AL - Maintenance Bay Panel. Refer to
Access Panels.
EFFECTIVITY: 0001 - 0008, 0010 - 0050, 0052, 0054 -
0267 PRE SB 500-31-024
EA500 Aircraft Maintenance Manual — 06-117751

STORMSCOPE - ADJUSTMENT/TEST

.
.
Name and Part Number
AMM-20-00-01-051-801 – Make Safe For
AMM-24-40-00-051-801 – External Power - Maintenance
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
SUBTASK
SUBTASK
AMM-06-50-00-051-801 – Aircraft
34-40-50
CONFIG A
Page 501
Sep 30/20
