AMM-34-50-20-071-B-801
1. General
A. This task gives procedures to do the adjustment/test of the:
• Dual Standard (Non-Diversity) Transponder System and components (or) Optional
Dual Diversity Transponder System and components.
• An adjustment/test is only required for the transponder that is being installed. The
opposite transponder, if it has not been removed, does not require an adjustment/
test
• There are two testing methods, the preferred method is with the use of a transponder
antenna coupler to limit emissions that may interfere with Air Traffic Control
operations and the second method which uses the IFR-6000 antennas.
(1) Refer to
Table 501
System Test
Dual Standard Transponder
System Test
Dual Diversity Transponder
System Test
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
POST SB 500-99-002; AND 0105-0112,
0116-0119, 0121-0122, 0125-0262 PRE SB
500-99-005
EA500 Aircraft Maintenance Manual — 06-117751
TRANSPONDER - ADJUSTMENT/TEST
for testing procedures.
Table 501. Test Matrix
Std. Transponder 1 Adjustment/Test:
AMM-34-50-20-071-B-701-001-A
AMM-34-50-20-071-B-701-001-B, and
Std. Transponder 2 Adjustment/Test:
AMM-34-50-20-071-B-701-002-A
AMM-34-50-20-071-B-701-002-B.
Transponder Cooling Adjustment/Test:
24–071–801
.
Diversity Transponder 1 Adjustment/Test:
AMM-34-50-20-071-B-701-003-A
AMM-34-50-20-071-B-701-003-B, and
Diversity Transponder 2 Adjustment/Test:
AMM-34-50-20-071-B-701-004-A
AMM-34-50-20-071-B-701-004-B.
Transponder Cooling Adjustment/Test:
24–071–801
.
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
Procedures
SUBTASK
or
SUBTASK
SUBTASK
or
SUBTASK
TASK AMM-34–50–
SUBTASK
or
SUBTASK
SUBTASK
or
SUBTASK
TASK AMM-34–50–
34-50-20
CONFIG B
Page 501
Sep 30/20
