Eclipse EA500 Maintenance Manual page 85

(22) On the WX-PA, press 2
(23) On the WX-PA, select "Continuous Out" on the MODE MENU, then press the MENU/
ENTR button once (so that WX-PA indicates "PAUSED" and not "RUNNING").
(24) On the WX-PA, press the FLAPS/A button to select top mount antenna configuration
(if not already selected).
• WX-PA displays "Top Mnt".
(25) On the WX-PA, select a cardinal bearing of 180° and a range of 75 NM.
• Use F1 and F2 buttons to adjust range and the F3 and F4 buttons to adjust
bearing.
(26) On the WX-PA, with "Continuous Out" still selected on the MODE MENU, press the
MENU/ENTR button once so that WX-PA indication changes from "PAUSED" to
"RUNNING".
(27) On the PFD, press the STRIKE CLEAR LSK.
• Strike data cleared from PFDs, then begins building again.
(28) Verify that the Strike Rate is displayed on the PFDs.
• Strike RATE will show 600 ± 200 strikes per minute.
(29) Test strikes appearing on the PFDs are at approximately 180 ± 10° relative and 75
NM.
(30) With aircraft magnetic heading active, turn the aircraft 45 ± 5° clockwise, or to the
right.
(31) Older test strikes on PFDs are at approximately 135 ± 30° relative and 75 NM. Newer
strikes displaying at approximately 180 ± 10° relative and 75 NM. Each newer test
strike during the turn forms part of an approximately 45° "arc" pattern, from
approximately 135° relative to approximately 180° relative.
(32) Power down the WX-PA Portable Analyzer unit and remove WX-PA test set and
antenna from aircraft.
(33) If no other work is to be performed, turn OFF the aircraft power by setting the SYS
BATT and START BATT Switches to the OFF (down) position and BUS TIE to OPEN
(down) position.
(34) Install 331 DT - Upper Over Fin Fairing. Refer to
Fairing - Installation.
EFFECTIVITY: 0001 - 0008, 0010 - 0050, 0052, 0054 -
0267 POST SB 500-31-024
EA500 Aircraft Maintenance Manual — 06-117751
nd
, then press MENU/ENTR to return to Main Menu.
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
AMM-55-10-12-041-801 – Overfin
34-40-50
CONFIG B
Page 505
Sep 30/20
