Eclipse EA500 Maintenance Manual page 9

Adjust the Pitot/AOA Probe Adaptor nozzles to align with the holes of the
Pitot/AOA probe.
NOTE: No other lubricating fluid is permitted. Malfunction of the equipment in
flight is possible.
NOTE: When installing the pressure test adapters, make sure that the seal is
good by applying a firm force to seat the adapter on the probe.
NOTE: The Pitot/AOA probes with a drain hole near the base of mast, must
have the drain hole covered. The drain hole must be covered with teflon
or vinyl tape. Failure to do so will result in a failure of this test.
(b) Connect the Pitot Test Hose Assembly (long hose)
the Barfield Pitot/Static Tester DPS450. Connect the other end of the long hose
to the quick-connect cross
(c) Connect the Pitot Test Hose Assembly (three short hoses)
quick-connect cross. Connect the other end of the short hoses to the upper,
center and lower connections on the Pitot/AOA Probe Adaptor
NOTE: Make sure that the Pitot/AOA Probe Adaptor nozzles are still aligned with
the holes on the Pitot/AOA probe.
(d) Connect the Static Port Adaptor (Nav Aids, SS53515-4-4)
port and finger tighten the screws to seat the seals over the static ports.
(e) Connect the Static Test Hose Assembly ; (Nav Aids PN E500-5160) (long hose)
(12) to the Barfield Pitot/Static Tester DPS450 Ps connection
other end of the Static Test Hose Assembly to the quick connect cross
(f) Connect the (short hose)
SS53515-4-4)
cross (11)
(2) Connect the Barfield Pitot/Static Tester DPS450 to the aircraft using the Air Data
Accessories Kit (NavAids P/N ADA500MD-945) as follows:
NOTE: When installing the pressure test adapters, make sure that the seal is good
by applying a firm force to seat the adapter on the probe.
NOTE: The P22201MD-4 adapter contains a built-in seal that covers the Pitot/AOA
probe drain hole. If using the P22201-3 adapter, the drain hole must be
covered with teflon or vinyl tape.
NOTE: The Pitot/AOA probes with a drain hole near the base of the mast, must have
the drain hole covered. Failure to do so will result in a failure of this test.
(a) Connect the Pitot Test Hose Assembly
Pitot/Static Tester DPS450. DO NOT OVERTIGHTEN.
(b) Connect the opposite end of the hose to the NAV Aids P22201MD-4 adapter.
(c) Install the NAV Aids P22201MD-4 adapter to the Pitot/AOA Probe. Make sure
that the internal seal of the adapter covers the pitot probe drain hole. If using the
EFFECTIVITY: NOTED
EA500 Aircraft Maintenance Manual — 06-117751
(4) .
(9) to the top fitting of the Static Port Adaptor (Nav Aids,
(10) . Connect the other end of the short hose to the quick connect
.
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
(3) to the Pt connection
(5, 6 and 8)
(7)
(10) to the left static
(1)
(3) to the Pt connection (2)
(2) on
to the
.
. Connect the
(11) .
on the Barfield
34-10-00
Page 505
Sep 30/20
