SURVEILLANCE STATUS = NO INFO
SUBTASK AMM-34-50-20-071-C-701-007
* * * ALL POST MB 500-31-016, MB 500-31-018 AND MB 500-34-030
A. ADS-B Parameter Test
(1) Do ADS-B Out Test Set-Up. Refer to
continue testing using the set-up from
SUBTASK
AMM-34-50-20-071-C-701-004-B.
(2) For each installed transponder (except for noted limitation), perform the following
procedure.
Limitation: If the aircraft is equipped with Garmin GPS 400W, this test applies to
Transponder 1 (XPDR 1) only.
(a) Select BDS 0,8 IDENT & CAT and check the following data:
AA = matches aircraft ICAO code displayed on the MFD Settings Page
FLIGHT ID = Aircraft Registration number (N-number for US registered aircraft)
EMIT CAT = LIGHT
(b) Select BDS 6,1 A/C STATUS ST1 and check the following data:
AA = matches aircraft ICAO code displayed on the MFD Settings Page
MODE A (4096) CODE = Entered Squawk Code from the PFD
(c) Select BDS 6,2 TSS SUBTYPE 1 and check the following data:
AA = matches aircraft ICAO code displayed on the MFD Settings Page
SIL ≥ 3
TCAS OP = NO
SELECTED ALTITUDE = comparable Selected Altitude using ACP controls
BARO PRESS = comparable selected Baro Pressure Setting
(d) Select BDS 6,5 A/C OP STATUS AIR and check the following data:
AA = matches aircraft ICAO code displayed on the MFD Settings Page
VERSION = 2 - DO-260B
1090 = 0
SIL ≥ 3
(e) On IFR 6000, press STOP TEST.
(f) Set WOW Box switches to W-on-W (on-ground).
(g) Set active XPDR = ALT mode.
(h) Press RUN TEST soft key to start test.
(i) Select BDS 0,6 SURFACE POS and check the following data:
AA = matches aircraft ICAO code displayed on the MFD Settings Page
LAT = comparable to the aircraft latitude
LON = comparable to the aircraft longitude
MOVEMENT = STOPPED
HDG = current aircraft heading on the L PFD within 1 deg
(j) Select BDS 0,8 IDENT & CAT and check the following data:
AA = matches aircraft ICAO code displayed on the MFD Settings Page
FLIGHT ID = Aircraft Registration number
EFFECTIVITY: NOTED
EA500 Aircraft Maintenance Manual — 06-117751
SUBTASK AMM-34-50-20-071-C-701-005
SUBTASK AMM-34-50-20-071-C-701-004-A
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
34-50-20
CONFIG C
Page 538
Sep 30/20
