AMM-34-50-11-001-C-801
1. General
A. This task gives procedures to remove the Global Positioning System (GPS 3) unit.
B. There is one GPS 3 (GDL 88) installed on the aircraft under 131 CZ-B - Floor Panel, Aft
Short, Left Cabin.
2. Job Set-Up
SUBTASK AMM-34-50-11-001-C-921-001
A. Make aircraft safe for maintenance. Refer to
Maintenance.
B. Make sure all power is removed from the aircraft.
3. Procedure
SUBTASK AMM-34-50-11-001-C-011-001
(Refer to
Fig.
401.)
CAUTION: DO NOT REMOVE 131 CZ-B - FLOOR PANEL, AFT SHORT, LEFT CABIN.
THE GPS 3 (GDL 88) MOUNT AND WIRING ARE ATTACHED TO THE
UNDERSIDE OF THE FLOOR PANEL.
A. Remove screws, but do not remove 131 CZ-B - Floor Panel, Aft Short, Left Cabin
Refer to
AMM-25-11-30-001-801 – Cockpit Floor Panels - Removal
B. Lift the forward edge and pivot 131 CZ-B - Floor Panel, Aft Short, Left Cabin
GDL 88 mounting knob
C. Pull on the lock down lever knob
GPS 3 (GDL 88) unit right angled hook.
NOTE: Pulling on the lever knob will disengage the locking teeth.
D. Pull the GPS 3 (GDL 88) unit
EFFECTIVITY: ALL POST MB 500-34-030
EA500 Aircraft Maintenance Manual — 06-117751

GPS 3- REMOVAL

AMM-20-00-01-051-801 – Make Safe For
(2)
.
(2)
while loosening. Disengage locking lever away from
(1)
straight out of the rack.
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
(3)
.
(3)
to access
34-50-11
CONFIG C
Page 401-Rem
Sep 30/20
.
