Eclipse EA500 Maintenance Manual page 236

Table of Contents

Advertisement

System Test
ADS-B Out System Tests
2. Equipment and Materials
Transponder Test Set (Aeroflex, IFR6000) or equivalent
UC-584 Universal Transponder Antenna Coupler | Dual Antenna Kit (Viavi 112349)[1]
Weight-on-Wheels (WOW) Box (EAI, 87-117390-1001) or AMC 2.4.01 (or higher).
Ground Power Unit (GPU). AllStar 450 or AllStar G.S.E. or Hobart GPU-400 or Hobart GPU-
600 or Bycan PS-28100
[1] For test with UC-584 antenna coupler.
EFFECTIVITY: NOTED
EA500 Aircraft Maintenance Manual — 06-117751
ADS-B Out Test Set-Up
C-701-005
ADS-B Out Functional Test:
C-701-006
ADS-B Out Parameter Test:
C-701-007
ADS-B Out Fail Indicator Functional Test:
AMM-34-50-20-071-C-701-008
Table 502. Special Tools and Equipment
Name and Part Number
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
Procedures
SUBTASK AMM-34-50-20-071-
SUBTASK AMM-34-50-20-071-
SUBTASK AMM-34-50-20-071-
SUBTASK
34-50-20
CONFIG C
Page 502
Sep 30/20
