(10) Press STOP TEST button.
(11) Repeat until all FAILED tests have been completed.
(12) Press Return button on IFR 6000 to return to XPDR-AUTO TEST screen appears.
• A PASS message should appear.
(13) On left PFD press MODE softkey to change the mode to ALT.
(14) CODE status box on the Left PFD and Right PFD show 1200.
(15) Press RUN TEST button on Transponder Test Set, IFR6000.
Transponder Test Set, IFR6000 indicates:
• "A Code" = 1200
• "C Alt" = Reading within +/- 100 ft. of the right PFD altitude reading
(16) On Transponder Test Set, IFR6000, press XPDR button one time. Check that the
following is displayed:
• XPDR – ALT ENCODER
(17) On Transponder Test Set, IFR6000, press SOURCE SELECT button. Check that the
following is displayed:
• SOURCE: XPDR
(18) On Transponder Test Set, IFR6000, select RUN TEST.
NOTE: Wait approximately 30 seconds between cockpit IDENT Tests
(19) Press IDNT key on the pilot's keyboard.
• IDENT is displayed on Transponder Test Set, IFR6000.
NOTE: IDENT will disappear from the IFR test set in approximately 20 seconds.
(20) Press IDNT key on the Copilot's keyboard. (If Installed)
• IDENT is displayed on Transponder Test Set, IFR6000.
NOTE: IDENT will disappear from the IFR test set in approximately 20 seconds.
(21) Press IDNT button on the Pilot's Stick Grip.
• IDENT is displayed on Transponder Test Set, IFR6000.
NOTE: IDENT will disappear from the IFR test set in approximately 20 seconds.
(22) Press IDNT button on the Copilot's Stick Grip.
• IDENT is displayed on Transponder Test Set, IFR6000.
NOTE: IDENT will disappear from the IFR test set in approximately 20 seconds.
(23) Press STOP TEST button on Transponder Test Set, IFR6000.
E. Generic Mode S Test
(1) Press STOP TEST button on Transponder Test Set, IFR6000.
(2) Make sure XPDR is still in MODE ALT on Left PFD.
