needed, lubricate with Pitot adaptor lubricating fluid (Part Number LF5050).
Adjust the Pitot/AOA Probe Adaptor nozzles to align with the holes of the
Pitot/AOA probe.
NOTE: No other lubricating fluid is allowed, possible malfunction of the
equipment in flight is possible
NOTE: When installing the pressure test adapters, make sure of a good seal by
applying a firm force to seat the adapter on the probe.
NOTE: If present, cover the probe drain hole with vinyl tape.
(b) Connect the Pitot Test Hose Assembly (long hose)
the Barfield Pitot/Static Tester DPS500. Connect the other end of the long hose
(3) to the quick connect cross
(c) Connect the Pitot Test Hose Assembly (one short hose)
cross (4)
on the Pitot/AOA Probe Adaptor
NOTE: Make sure that the Pitot/AOA Probe Adaptor nozzles are still aligned with
the holes on the Pitot/AOA probe.
(d) Connect the Static Test Hose Assembly ; (Nav Aids PN E500-5160)
Barfield Pitot/Static Tester DPS500 Ps connection
(e) Connect the other end of the Static Test Hose Assembly
the Static Port Adaptor (Nav Aids, SS53515-4-4)
(f) Connect the Static Port Adaptor (Nav Aids, SS53515-4-4)
port with the connected fitting to the top port and finger tighten the screws to seat
the seals over the Static ports.
NOTE: The right static upper port can be tested from the left Static lower port by
connecting the short hose to the lower port connection on the Static Port
Adaptor. The aircraft's left lower port is connected to the right upper port
and the left upper port is connected to the right lower port by aircraft
design. Refer to
(2) Connect the Barfield Pitot/Static Tester DPS500 to the aircraft using the Air Data
Accessories Kit (NavAids P/N ADA500MD-945) as follows:
NOTE: When installing the pressure test adapters, make sure that the seal is good
by applying a firm force to seat the adapter on the probe.
NOTE: The P22201MD-4 adapter contains a built-in seal that covers the Pitot/AOA
probe drain hole. If using the P22201-3 adapter, the drain hole must be
covered with teflon or vinyl tape.
NOTE: The Pitot/AOA probes with a drain hole near the base of the mast, must have
the drain hole covered. Failure to do so will result in a failure of this test.
(a) Connect the Pitot Test Hose Assembly
Pitot/Static Tester DPS500. DO NOT OVERTIGHTEN.
(b) Connect the opposite end of the hose to the NAV Aids P22201MD-4 adapter.
(c) Install the NAV Aids P22201MD-4 adapter to the Pitot/AOA Probe. Make sure
that the internal seal of the adapter covers the pitot probe drain hole. If using the
EFFECTIVITY: NOTED
EA500 Aircraft Maintenance Manual — 06-117751
(4) .
. Connect the other end of the short hose
(7)
Fig. 504, Sheet
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
(3) to the Pt connection
(5) to the quick connect
(5) to the center connection
.
(1) .
(12)
(10) .
(10)
1.
(3) to the Pt connection
(2) on
(12) to the
to the top fitting of
to the left Static
(2) on the Barfield
34-10-00
Page 508
Sep 30/20
