AMM-34-50-20-071-A-801
1. General
A. This task gives procedures to do the adjustment/test of the transponder components.
• An adjustment/test is only required for the transponder that is being installed. The
opposite transponder, if it has not been removed, does not require an adjustment/
test
• There are two testing methods, the preferred method is with the use of a transponder
antenna coupler to limit emissions that may interfere with Air Traffic Control
operations and the second method which uses the IFR-6000 antennas.
2. Equipment and Materials
Transponder Test Set (Aeroflex, IFR6000)
UC-584 Universal Transponder Antenna Coupler | Dual Antenna Kit (Viavi 112349)[1]
Weight-on-Wheels (WOW) Box (EAI, 87-117390-1001) or Avio Maintenance Computer (AMC)
(EAI 20-120576-1001 or 20-121926-1001), SW version "1.5.71 or higher" for Pre-Avio NG
aircraft and "2.2.02 or higher" for Avio NG aircraft
PCMCIA to Parallel Port Adapter, (Quatech, PN SPP-100), for use with Transponder
Programming Kit, (Bender, PN AMP6400-1 (parallel port) or PN AMP6400-2 (USB)).
Transponder Programming Kit, (Bender, PN AMP6400-1 (parallel port) or PN AMP6400-2
(USB))
Personal Computer (PC) — for Address Module Programming
[1] For test with UC-584 antenna coupler.
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
PRE SB 500-99-002 AND SB 500-99-005
EA500 Aircraft Maintenance Manual — 06-117751
TRANSPONDER - ADJUSTMENT/TEST
Table 501. Special Tools and Equipment
Name and Part Number
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
34-50-20
CONFIG A
Page 501
Sep 30/20
