3. Job Set-Up with UC-584 Antenna Couplers
SUBTASK AMM-34-50-20-071-921-001-A
Refer to
Fig.
501.
A. Make aircraft safe for maintenance. Refer to
Maintenance.
B. If on jacks, refer to
AMM-08-20-00-051-801 – Leveling.
C. Connect external power. Refer to
Maintenance Practices.
prompted.
D. Prepare Anti-ice system for maintenance. Refer to
Anti-Ice Systems For Maintenance
E. Connect Antenna Coupler UC-584S to Aircraft upper Transponder Antenna as follows:
(as applicable)
NOTE: For Transponder–1 Adjustment/Test
(1) Place Antenna Coupler
bottom of the coupler.
(2) Lock Antenna Coupler
down and locked position.
NOTE: Coupler must be tightly pressed and locked in place for Test Set to function
correctly. Coupler will lock into place when the black rubber gasket is not
completely depressed against the aircraft, but the Test Set will not measure
functions accurately.
CAUTION: DO NOT CONNECT COAX CABLE TO IFR-6000 ANT PORT. DAMAGE
TO EQUIPMENT WILL OCCUR.
(3) Connect long RF coaxial cable
I/O Connector.
CAUTION: THE RF COAXIAL CABLE CAN BE A TRIPPING HAZARD. MAKE
SURE TO SECURE THE CABLE. PERSONAL INJURY AND DAMAGE
TO THE ANTENNAS AND TEST EQUIPMENT COULD OCCUR.
(4) Temporarily secure the coaxial cable to the aircraft with tape. Tape can be removed
after the test is completed.
(5) Push Antenna Coupler
on the rim of the coupler is completely depressed tightly against the aircraft.
F. Connect Antenna Coupler UC-584 to Aircraft lower Transponder Antenna as follows: (as
applicable)
NOTE: For Transponder–2 Adjustment/Test
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
PRE SB 500-99-002 AND SB 500-99-005
EA500 Aircraft Maintenance Manual — 06-117751
AMM-07-10-00-051-801 – Jacking - Maintenance Practices
AMM-24-40-00-051-801 – External Power -
Do not turn on START BATT and SYS BATT switches until
.
(2)
over the antenna
(2)
into place by pushing lever on the side of the coupler into a
(1)
between the Antenna Coupler
(2)
firmly against the aircraft skin until the black rubber gasket
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
AMM-20-00-01-051-801 – Make Safe For
AMM-20-00-03-051-801 – Prepare
(3)
, guiding antenna in to the slot on the
(2)
and
and Test Set RF
34-50-20
CONFIG A
Page 502
Sep 30/20
