Eclipse EA500 Maintenance Manual page 297

AMM-34-50-26-001-801
1. General
A. This task gives procedures to remove the ADS-B Fail Indicator.
B. There is one ADS-B Fail Indicator installed on the lower left instrument panel.
2. Equipment and Materials
Extraction Tool (Aerospace Optics 18–234)
Cap Extractor Tool (Aerospace Optics 17–150)
3. Job Set-Up
SUBTASK AMM-34-50-26-001-921-001
A. Make aircraft safe for maintenance. Refer to
Maintenance.
B. Make sure all power is removed from the aircraft.
4. Procedure
SUBTASK AMM-34-50-26-001-011-001
(Refer to Fig. 401.)
A. Remove the ADS-B Fail Indicator as follows:
(1) Remove two screws
(2) Disconnect electrical connector
(3) Identify the two extraction slots positioned on either side of the cap
switch cap (7)
finger pressure on two sides of the switch cap pulling the switch cap from the switch
body.
(4) Remove switch cap
the hinged slide retainer.
(5) From the front of the switch body
screws (8) in the base of the body. Loosen the two screws until the Integral Mounting
Hardware releases the mounting sleeve from the mounting panel.
(6) From behind the bracket
switch body by sliding aft from the bracket
EFFECTIVITY: ALL POST MB 500-34-030
EA500 Aircraft Maintenance Manual — 06-117751
ADS-B FAIL INDICATOR - REMOVAL
Table 401. Special Tools and Equipment
Name & Part Number
(2) that secure bracket
(3) from switch body
by using the Cap Extractor Tool (Part Number: 17-150) or by applying
(7) from the switch body
(6) locate the two slot head integral mounting
(1) , remove the locking sleeve
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
AMM-20-00-01-051-801 – Make Safe For
(1) to the Instrument panel.
(6) with extraction tool 18–234.
(6) by gently removing the cap pins from
(4) and spacer
(1) .
(7) . Extract the
(5) from the
34-50-26
Page 401-Rem
Sep 30/20
