Eclipse EA500 Maintenance Manual page 295

NOTE:
STRUCTURE AND EQUIPMENT
REMOVED FOR CLARITY
Transponder Antenna Relay - Removal/Installation (Avio NG +1.5 Display shown)
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
POST SB 500-99-002; 0105-0112,
0116-0119, 0121-0122, 0125-0265 POST
SB 500-99-005; AND 0266-0267
EA500 Aircraft Maintenance Manual — 06-117751
A
B
A
Figure 401 (Sheet 1 of 1)
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
7
5
6
B
1
2 (x2)
3 (x2)
Page 403-Inst
4
34-50-23
Sep 30/20
