Gps 2 Antenna Splitter - Removal - Eclipse EA500 Maintenance Manual

AMM-34-50-14-001-801
1. General
A. This task gives procedures to remove the GPS 2 Antenna Splitter.
B. There is one GPS 2 Antenna Splitter installed on the aircraft under 231 NZ - Floor Panel,
Baggage Compartment.
2. Job Set-Up
SUBTASK AMM-34-50-14-001-921-001
A. Make aircraft safe for maintenance. Refer to
Maintenance.
B. Make sure all power is removed from the aircraft.
C. Remove 231 NZ - Floor Panel, Baggage Compartment. Refer to
– Aircraft Access Panels
3. Procedure
SUBTASK AMM-34-50-14-001-C-011-001
(Refer to Fig. 401.)
A. Disconnect the three coaxial connectors
(1) Install protective caps on the three coaxial connectors
B. Remove two screws
C. Remove the GPS 2 Antenna Splitter
EFFECTIVITY: ALL POST MB 500-34-030
EA500 Aircraft Maintenance Manual — 06-117751

GPS 2 ANTENNA SPLITTER - REMOVAL

for location and removal instructions.
(3) from the GPS 2 Antenna Splitter
(2) that attach the GPS 2 Antenna Splitter
(1) from the aircraft.
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
AMM-20-00-01-051-801 – Make Safe For
AMM-06-50-00-051-801
(3) .
(1) to the aircraft.
(1) .
34-50-14
Page 401-Rem
Sep 30/20
