(16) If no further maintenance is required, remove all of the Nav Aids test equipment from
the aircraft. Stow the Air Data Accessories Kit ; (Nav Aids PN ADA500945)
equipment and Barfield Pitot/Static Tester DPS450.
B. Complete the Standby Pitot/Static System Leak Test (using the Barfield Pitot/Static
Tester DPS500) as follows:
CAUTION: DO NOT OVER TIGHTEN HOSES. DAMAGE MAY OCCUR TO TEST
EQUIPMENT. HOSES SHOULD BE SNUG.
CAUTION: THE LEAK TEST CAN BE ACCOMPLISHED WITH ELECTRICAL
POWER OFF. MAKE SURE THAT IF THE WOW BOX IS CONNECTED,
THE SWITCHES ARE SET TO WONW DURING THIS TEST IF
ELECTRICAL POWER IS USED. WITH WEIGHT OFF WHEELS, THE
HEATERS ARE COMMANDED ON BY THE AIRCRAFT COMPUTER
SYSTEM. IF THE PITOT/STATIC HEAT ECBS ARE NOT COLLARED
OFF, HARM TO PERSONNEL OR AIR DATA TEST EQUIPMENT CAN
OCCUR.
NOTE: Refer to step (1) if using the Air Data Accessories Kit ; (Nav Aids PN
ADA500945) or step (2) if using the Air Data Accessories Kit (NavAids P/N
ADA500MD-945).
(1) Connect the Barfield Pitot/Static Tester DPS450 to the aircraft Standby Pitot/Static
probe as follows:
(a) Attach the Pitot/Static probe adaptor (PS35210-4-4)
Static probe.
(b) Connect the hose
Tester DPS450 to the end fitting on the Pitot/Static probe adaptor (PS35210-4-4)
(6) .
(c) Connect the hose from the Ps
Pitot/Static probe adaptor (PS35210-4-4)
NOTE: Cover the probe drain hole with vinyl tape.
(2) Connect the Barfield Pitot/Static Tester DPS500 to the aircraft using the Air Data
Accessories Kit (NavAids P/N ADA500MD-945) as follows:
(a) Remove the P22201MD-4 adapter (or the P22201-3 adapter) from the Pt Hose.
Connect the hose from the Pt adapter on the Barfield to the PS35210MD-4-4
adapter (or PS35210- 4-4 adapter) connector marked PITOT (this is the
connector at the end of the adapter).
(b) Disconnect the hose from the static PTA and connect to the other PS35210
connector (connector on the side of the adapter). Connect the PS35210 adapter
to the Pitot/Static probe, make sure of complete coverage of the static ports on
the Pitot/Static probe.
NOTE: The PS35210MD-4-4 adapter contains a built-in seal that covers the pitot
static probe drain hole. If using the PS35210-4-4 adapter, the drain hole
must be covered with vinyl tape.
NOTE: The Pitot/Static probe is the upper pitot probe on the left hand side.
EFFECTIVITY: NOTED
EA500 Aircraft Maintenance Manual — 06-117751
(3) from the Pt connection
(1) connection on the fitting on the side on the
(6)
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
(6) to the Standby Pitot/
(2) on the Barfield Pitot/Static
.
34-10-00
Page 512
Sep 30/20
