(a) Remove the P22201MD-4 adapter (or the P22201-3 adapter) from the Pt Hose.
Connect the hose from the Pt adapter on the Barfield to PS35210MD-4-4 adapter
(or PS35210- 4-4 adapter) connector marked PITOT (this is the connector at the
end of the adapter).
(b) Disconnect the hose from the static PTA and connect to the other PS35210
connector (connector on side of adapter). Connect the PS35210 adapter to the
Pitot/Static probe, make sure of a complete coverage of the static ports on the
Pitot/Static probe.
NOTE: The PS35210MD-4-4 adapter contains a built-in seal that covers the pitot
static probe drain hole. If using the PS35210-4-4 adapter, the drain hole
must be covered with vinyl tape.
NOTE: The Pitot/Static probe is the upper pitot probe on the left hand side.
(3) Press CLEAR/QUIT to return to main menu on Barfield Pitot/Static Tester DPS450.
(4) Press F1 to select Rate Timer and then press F3 to select Set Wait.
(5) Press 5 and then press ENTER.
• The Set Wait will be updated to 5 minutes.
(6) Press F4 to select Set Time, press 1, and then press ENTER.
• The Set Time will be updated to 1 minute.
(7) Press CLEAR/ QUIT to return to Main Menu.
(8) Press LEAK MEASURE/ CONTROL for CONTROL MODE.
(9) Press ROC RATE Ps to select the ROC control aim, enter 4000 and press Enter.
(10) Press ALT Ps to select the ALT control aim, enter 30000 and press Enter.
• The system starts to control to the new set point.
(11) Press SPEED Qc, enter 200 and press Enter. Wait for at least a 15 second
stabilization period after the altitude and airspeed achieve these new air data
parameter set point values to continue.
(12) Press LEAK MEASURE/CONTROL to change to LEAK MEASURE MODE.
(13) Press F1 twice to Start Timing.
• After the Waiting and Timing intervals are complete, the Barfield Pitot/Static
Tester DPS450 displays Timed Rates Available.
(14) Check the maximum ROC is 100 ft/min or less and the maximum Rt CAS is 2 kt/min
or less.
• If the leak rate is not within tolerances, refer to Leak Testing the Barfield Pitot/
Static Tester DPS450 and Connecting Hoses
AMM-34-10-00-071-701-003) and subtract the Barfield Pitot/Static Tester
DPS450 leak check altitude value recorded in Leak Testing the Barfield Pitot/
Static Tester DPS450 and Connecting Hoses
AMM-34-10-00-071-701-003
get a corrected total system leak value.
(15) Press the LEAK MEASURE/CONTROL to return to CONTROL MODE.
