Eclipse EA500 Maintenance Manual page 40

Left Pitot/AOA Probe
Left Dual Static Port
P
T
P
S
P
P
S
Standby Pitot/
Static Probe
Left Dual OAT
EFFECTIVITY: NOTED
EA500 Aircraft Maintenance Manual — 06-117751
Left
PFD
AOA Data
Left ADC
PSIA
Trans
Primary Static
FADEC Left Chan A
FADEC Right Chan B
Left APC
Left Aircraft Computer
System (ACS)
T 1B
T 1A
Autopilot Servos
Air Data System Block Diagram
Figure 504 (Sheet 1 of 1)
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
Right
PFD
AOA Data
Right ADC
Right Pitot/AOA Probe
PSIA
Trans
Secondary Static
FADEC Right Chan A
FADEC Left Chan B
Right APC
Right Aircraft
Computer System (ACS)
T 2B
T 2A
Right Dual OAT
Right Dual Static Port
34-10-00
Page 536
Sep 30/20
