(c) Press XPDR SQWK.
(d) Using the keyboard numbers, set the code to 1200.
(e) Press Enter.
• CODE status box on the left PFD shows 1200.
C. Transponder-1 MODE A,C,S Test using Transponder Test Set, IFR6000
(1) Power Up: Press the POWER Key to power the Test Set.
(2) Press SETUP Control Key to display setup screens. Continue pressing SETUP
Control Key to cycle to SETUPXPDR Screen. Use NEXT PARAM and PREV PARAM
Soft Keys to select each parameter.
(3) Select RF PORT: Select DIR W/COUPLER
(a) Select CPL CABLE LOSS: Set to loss found on cable.
(b) Select COUPLER LOSS: Set to loss found on coupler.
(4) Press XPDR button to go to the XPDR AUTO TEST page.
(5) Press CONFIG button. On the CONFIG line, scroll to GENERIC MODE S using the
up/down buttons. Press Return button and select Run Test, found on display screen.
• Top ERP dBm should be between 48 to 60 and MTL. dBm should be between
-67 to -79 to PASS.
(6) Press STOP TEST button.
(7) Repeat until all FAILED tests have been completed.
(8) Press Return button on IFR 6000 to return to XPDR-AUTO. TEST screen appears.
• A PASS message should be displayed.
(9) On left PFD, scroll to XPDR using lower softkey.
(10) Press MODE softkey to change the mode to ALT.
(11) CODE status box on the left PFD and right PFD show 1200.
(12) Press RUN TEST button on Transponder Test Set, IFR6000.
Transponder Test Set, IFR6000 indicates:
• A Code = 1200
• C Alt = Reading within +/- 100 ft. of the Left PFD altitude reading
(13) On Transponder Test Set, IFR6000, press XPDR button one time. Check that the
following is displayed:
• XPDR – ALT ENCODER
(14) On Transponder Test Set, IFR6000, press Source Select button. Check that the
following is displayed:
• SOURCE: XPDR
(15) On Transponder Test Set, IFR6000, select RUN TEST.
NOTE: Wait approximately 30 Seconds between cockpit IDENT tests.
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
PRE SB 500-99-002 AND SB 500-99-005
EA500 Aircraft Maintenance Manual — 06-117751
© 2020 Eclipse Aerospace, Inc.
Temporary Revision No. 34-21
34-50-20
CONFIG A
Page 505
Sep 30/20
