Communications Specifications; Communications Functions - Omron E5 C Series Manual

E5GC
USB-Serial Conversion Cable
Windows XP/Vista/7/8/10 *1
Applicable OS
Applicable software CX-Thermo version 4.62 or higher
Applicable models E5@C-T Series, E5@C Series, and E5CB Series
USB interface standard Conforms to USB Specification 2.0
DTE speed 38,400 bps
Computer: USB (Type A plug)
Connector
Digital Temperature Controller: Special serial
specifications
connector
Bus power (Supplied from the USB host controller) *2
Power supply
Power supply voltage 5 VDC
Current
450 mA max.
consumption
4.7±0.2 VDC (Supplied from USB-Serial Conversion
Output voltage
Cable to the Digital Temperature Controller.)
250 mA max. (Supplied from USB-Serial Conversion
Output current
Cable to the Digital Temperature Controller.)
Ambient operating
0 to 55°C (with no condensation or icing)
temperature
Ambient operating
10% to 80%
humidity
Storage temperature −20 to 60°C (with no condensation or icing)
Storage humidity 10% to 80%
Altitude 2,000 m max.
Weight Approx. 120 g
Windows is a registered trademark of Microsoft Corporation in the
United States and or other countries.
*1. CX-Thermo version 4.65 or higher runs on Windows 10.
*2. Use a high-power port for the USB port.
Note: A driver must be installed on the computer. Refer to the Instruction
Manual included with the Cable for the installation procedure.

Communications Specifications

Transmission line
connection method
Communications
Synchronization method
Protocol
Baud rate *
Transmission code
Data bit length *
Stop bit length *
Error detection
Flow control
Interface
Retry function
Communications buffer
Communications
response wait time
* The baud rate, data bit length, stop bit length, and vertical parity can
be individually set using the Communications Setting Level.

Communications Functions

You can use the memory in the PLC to read and write
E5@C parameters, start and stop operation, etc.
The E5@C automatically performs communications with
PLCs. No communications programming is required.
Number of connected Digital Temperature
Programless
Controllers: 32 max. (Up to 16 for the FX Series)
communica-
Applicable PLCs
tions
OMRON PLCs
Mitsubishi Electric PLCs MELSEC Q Series, L Series,
KEYENCE PLCs
10
RS-485: Multidrop
RS-485 (two-wire, half duplex)
Start-stop synchronization
CompoWay/F, or Modbus
9,600, 19,200, 38,400, or 57,600 bps
ASCII
7 or 8 bits
1 or 2 bits
Vertical parity (none, even, odd)
Block check character (BCC)
with CompoWay/F or
CRC-16 with Modbus
None
RS-485
None
217 bytes
0 to 99 ms
Default: 20 ms
CS Series, CJ Series, CP
Series, NJ Series, or NX1P
FX3 Series, or iQ-R Series
KEYENCE KV Series
When Digital Temperature Controllers are connected,
set points and RUN/STOP commands can be sent
from the Digital Temperature Controller that is set as
Component
the master to the Digital Temperature Controllers that
Communi-
are set as slaves.
cations
Slope and offsets can be set for the set point.
Number of connected Digital Temperature
Controllers: 32 max. (including master)
When Digital Temperature Controllers are connected,
the parameters can be copied from the Digital
Copying *
Temperature Controller that is set as the master to the
Digital Temperature Controllers that are set as slaves.
MELSEC is a registered trademark of Mitsubishi Electric Corporation.
KEYENCE is a registered trademark of Keyence Corporation.
* Both the programless communications and the component
communications support the copying.
Current Transformer (Order Separately)
Ratings
E54-CT1
E54-CT3
Dielectric strength 1,000 VAC for 1 min
Vibration resistance
E54-CT1: Approx. 11.5 g
Weight
E54-CT3: Approx. 50 g
E54-CT3 Only
Accessories Armatures (2)
Plugs (2)
Heater Burnout Alarms and SSR Failure
Alarms
CT input (for heater Models with detection for single-phase
current detection) heaters: One input
Maximum heater current 50 A AC
Input current
±5% FS ±1 digit max.
indication accuracy
Heater burnout alarm 0.1 to 49.9 A (in units of 0.1 A)
setting range *1 Minimum detection ON time: 100 ms *3
0.1 to 49.9 A (in units of 0.1 A)
SSR failure alarm setting
Minimum detection OFF time: 100 ms
range *2
*4
*1. For heater burnout alarms, the heater current will be measured
when the control output is ON, and the output will turn ON if the
heater current is lower than the set value (i.e., heater burnout
detection current value).
*2. For SSR failure alarms, the heater current will be measured when
the control output is OFF, and the output will turn ON if the heater
current is higher than the set value (i.e., SSR failure detection
current value).
*3. The value is 30 ms for a control period of 0.1 s or 0.2 s.
*4. The value is 35 ms for a control period of 0.1 s or 0.2 s.
Electrical Life Expectancy Curve for
Control Output Relay (Reference Values)
500
300
200
100
E5GC
250 VAC, 30 VDC
50
(resistive load)
cosφ = 1
30
20
10
5
3
2
1
0.1 0.2 0.3 0.5 1
Switching current (A)
E54-CT1L
E54-CT3L
1,500 VAC for 1 min
50 Hz, 98 m/s 2
E54-CT1L: Approx. 14 g
E54-CT3L: Approx. 57 g
None
2 3 5 10
