  • Page 1 At the end of this document you will find links to products related to this catalog. You can go directly to our shop by clicking HERE. HERE...
  • Page 2 Introduction Preparations Digital Temperature Controllers Part Names and Basic Procedures Programmable Type Basic User’s Manual Operation E5@C-T Advanced Operations Parameters User Calibration Appendices Index H185-E1-01...
  • Page 4 OMRON. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.
  • Page 5 Omron’s exclusive warranty is that the Products will be free from defects in materials and workmanship for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron). Omron disclaims all other warranties, express or implied.

  • Page 6: Performance Data

    Disclaimers Performance Data Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of Omron’s test conditions, and the user must correlate it to actual application requirements. Actual perfor- mance is subject to the Omron’s Warranty and Limitations of Liability.

  • Page 7: Safety Precautions

    Safety Precautions Safety Precautions Definition of Precautionary Information The following notation is used in this manual to provide precautions required to ensure safe usage of the E5@C-T Digital Controllers. The safety precautions that are provided are extremely important to safety. Always read and heed the information provided in all safety precautions.
  • Page 8 Safety Precautions Safety Precautions CAUTION Minor injury due to electric shock may occasionally occur. Do not touch the terminals while power is being supplied. Electric shock, fire, or malfunction may occasionally occur. Do not allow metal objects, conductors, cuttings from installation work, or moisture to enter the Digital Controller or a Setup Tool port.
  • Page 9 Safety Precautions CAUTION Loose screws may occasionally result in fire. Tighten the terminal screws to the specified torque of 0.43 to 0.58 N·m. Set the parameters of the product so that they are suitable for the system being controlled. If they are not suitable, unexpected operation may occasionally result in property damage or accidents.
  • Page 10 Precautions for Safe Use Precautions for Safe Use Be sure to observe the following precautions to prevent operation failure, malfunction, or adverse affects on the performance and functions of the product. Not doing so may occasionally result in unex- pected events. Do not handle the Digital Controller in ways that exceed the ratings. •...
  • Page 11 Precautions for Safe Use • Design the system (e.g., control panel) considering the 2 seconds of delay in setting the Digital Controller’s output after the power supply is turned ON. • The output will turn OFF when you move to the Initial Setting Level. Take this into consideration when performing control.
  • Page 12 When waterproofing is required, insert the Waterproof Packing on the backside of the front panel. Keep the Port Cover on the front-panel Setup Tool port of the E5EC-T/E5AC-T securely closed. The degree of protection when the Waterproof Packing is used is IP66. To maintain an IP66 degree of...

  • Page 13: Precautions For Operation

    Precautions for Operation Precautions for Operation • It takes approximately two seconds for the outputs to turn ON from after the power supply is turned ON. Design the system (e.g., control panel) to allow for this delay. • The Digital Controller requires 30 minutes to warm up after the power supply is turned ON. Always turn ON the power supply at least 30 minutes before starting actual control operations.
  • Page 14 Preparations for Use Preparations for Use Be sure to thoroughly read and understand the manual provided with the product, and check the follow- ing points. Timing Check point Details Purchasing Product After purchase, check that the product and packaging are not dented or the product appearance otherwise damaged.
  • Page 15 Versions Versions Check the version on the nameplate on the E5@C-T Digital Controller or on the label on the packing box. If the version is not given, the version of the E5@C-T Digital Controller is version 1.0. Product nameplate Package label The version is given here.

  • Page 16: H185-E1

    Revision History Revision History A manual revision code appears as a suffix to the catalog number on the front cover of the manual. H185-E1-01 Cat. No. Revision code Revision code Date Revised content January 2014 Original production E5@C-T Digital Temperature Controllers User’s Manual (H185)

  • Page 17: E5@C-T Digital Temperature Controllers User's Manual (H185)

    Conventions Used in This Manual Model Notation “E5@C-T” is used to indicate information that is the same for the E5CC-T, E5EC-T, and E5AC-T Digital Controllers. Also, “E5EC-TPR@,” “E5AC-TPR@,” or “Position-proportional Models” indicates the Digital Controllers with position-proportional control. “Standard Models” indicates other Digital Controllers.

  • Page 18: Conventions Used In This Manual

    Conventions Used in This Manual How to Read Display Symbols The following tables show the correspondence between the symbols displayed on the displays and alphabet characters. How This Manual is Organized Goal Related sections Contents Learning about the Section 1 Introduction appearance, features, functions, and model numbers Setting up the E5@C-T...
  • Page 19 Conventions Used in This Manual E5@C-T Digital Temperature Controllers User’s Manual (H185)
  • Page 20 Sections in this Manual Sections in this Manual Introduction Preparations Part Names and Basic Procedures Basic Operation Advanced Operations Parameters User Calibration Appendices Index E5@C-T Digital Temperature Controllers User’s Manual (H185)

  • Page 21: Table Of Contents

    Panel Cutout (Unit: mm)......................2-3 2-1-3 Mounting ............................. 2-5 Using the Terminals......................... 2-7 2-2-1 E5CC-T Terminal Block Wiring Example..................2-7 2-2-2 E5EC-T/E5AC-T Terminal Block Wiring Example ..............2-11 2-2-3 Precautions when Wiring ......................2-16 2-2-4 Wiring............................2-16 E5@C-T Digital Temperature Controllers User’s Manual (H185)
  • Page 22 Insulation Block Diagrams....................2-23 Using the Setup Tool Port..................... 2-24 2-4-1 Procedure ..........................2-24 2-4-2 Connection Method........................2-24 2-4-3 Installing the Driver ........................2-27 Section 3 Part Names and Basic Procedures Basic Application Flow ......................3-2 Power ON..........................3-3 Part Names, Part Functions, and Setting Levels ..............3-4 3-3-1 Part Names and Functions ......................
  • Page 23 Determining PID Constants (Autotuning and Manual Setting).......... 4-49 4-9-1 AT (Auto-tuning) ........................4-50 4-9-2 RT (Robust Tuning) (Used for Autotuning) ................4-52 4-9-3 Manual Setup ..........................4-54 4-10 Alarm Outputs........................4-56 4-10-1 Alarm Types ..........................4-56 4-10-2 Alarm Values ..........................4-59 4-11 Alarm Hysteresis ........................
  • Page 24 5-14 Determining PID Constants for PID Sets (Autotuning for All PID Sets) ......5-45 5-14-1 Autotuning All PID Sets (Autotuning) ..................5-45 5-14-2 Executing Autotuning for All PID Sets..................5-48 5-15 Program-related Functions....................5-53 5-15-1 Advance............................ 5-53 5-15-2 Segment Jump.......................... 5-54 5-15-3 Hold ............................
  • Page 25 6-10 Advanced Function Setting Level ..................6-80 6-11 Communications Setting Level ..................6-111 Section 7 User Calibration User Calibration ........................7-2 Parameter Structure ........................ 7-3 Thermocouple Calibration ...................... 7-4 Resistance Thermometer Calibration ..................7-7 Calibrating Analog Input ......................7-9 Calibrating the Transfer Output.................... 7-11 Checking Indication Accuracy .....................
  • Page 26 Introduction 1-1 Appearance, Features, and Functions of the E5@C-T ....1-2 1-1-1 Appearance ........... . 1-2 1-1-2 Features .

  • Page 27: Introduction

    PF Key) to shift the digit that is being set to aid in changing the set values. Setup Tool Port on Front Panel of the E5EC-T/E5AC-T This port allows you to change or set parameters from the Setup Tool even when the Controller is installed in a panel.

  • Page 28: Main Functions

    1 Introduction Controlling the Program You can use a key operation to freely jump to another segment and execute it. Editing the Program From the initial display in Operation Level, you can change to the display to edit segment data with one key.
  • Page 29 1 Introduction • Holding • Waiting to advance to the next segment • Jumping to segments with a key operation Program Status Outputs • Time signals • ON output in run status • ON output at program end • Stage outputs (one-pulse output at start of each segment) Adjusting PID Constants •...

  • Page 30: I/O Configuration And Model Number Legend

    1 Introduction I/O Configuration and Model Number Legend 1-2-1 I/O Configuration I/O Configuration of E5 C-T Inputs E5 C-T Outputs Input signals Output signals Program control Control Heating Set point (SP) Operation Open • Linear current Limits SP mode Control output 1 •...
  • Page 31 1 Introduction I/O Related to Programmed Models Changing SP mode or Input Output between run and reset status Program SP Mode Fixed SP Mode Program No. 7 Fixed Run/Reset Switching Press the M (Mode) and Program No. 1 D (Down) Key simultaneously for at least 1 second.

  • Page 32: Model Number Legends

    1 Introduction 1-2-2 Model Number Legends E5CC-T E 5 C C - T (3) (4) (5) (6) Meaning 48 × 48 mm Control output 1 Control output 2 Relay output None Voltage output (for driving SSR) None *2*1 Linear current output None Voltage output (for driving SSR) Voltage output...
  • Page 33 1 Introduction E5EC/AC-T C - T (3) (4) (5) (6) Meaning 48 × 96 mm 96 × 96 mm Control output 1 Control output 2 Relay output None Voltage output (for driving SSR) None *2*1 Linear current output None Voltage output (for driving SSR) Voltage output (for driving SSR) Voltage output (for driving SSR) Relay output...

  • Page 34: Preparations

    E5CC-T Terminal Block Wiring Example ......2-7 2-2-2 E5EC-T/E5AC-T Terminal Block Wiring Example ..... . 2-11 2-2-3 Precautions when Wiring .

  • Page 35: Installation

    2 Preparations Installation 2-1-1 Dimensions (Unit: mm) E5CC-T (64) 44.8 × 44.8 48 × 48 E5EC-T (64) 2 - 2 E5@C-T Digital Temperature Controllers User’s Manual (H185)

  • Page 36: Panel Cutout (Unit: Mm)

    2 Preparations E5AC-T (64) 96 × 96 91 × 91 2-1-2 Panel Cutout (Unit: mm) E5CC-T Individual Mounting Group Mounting (48 × number of Units − 2.5) +1.0 +0.6 E5EC-T Individual Mounting Group Mounting* (48 × number of Units − 2.5) +1.0...
  • Page 37 2 Preparations E5AC-T Individual Mounting Group Mounting (96 × number of Units − 3.5) +1.0 +0.8 • Waterproofing is not possible when group mounting several Controllers. • The recommended panel thickness is 1 to 5 mm for the E5CC-T, and 1 to 8 mm for E5EC-T, and E5AC-T.

  • Page 38: Mounting

    2 Preparations 2-1-3 Mounting E5CC-T There are two models of Terminal Covers that you can use with the E5CC-T. Adapter E53-COV23 Terminal Cover* E53-COV17 Adapter Terminal Cover (Sold separately.) The Terminal Cover is provided only with the following models: E5CC-T@@@@5M-@@@. Waterproof packing Panel Mounting to the Panel...
  • Page 39 Waterproofing is not possible when group mounting several Controllers. Waterproof packing is not necessary when there is no need for the waterproofing function. (2) Insert the E5EC-T/E5AC-T into the mounting hole in the panel. (3) Push the Adapter from the terminals up to the panel, and temporarily fasten the E5EC-T/E5AC-T.

  • Page 40: Using The Terminals

    2 Preparations Using the Terminals 2-2-1 E5CC-T Terminal Block Wiring Example Terminal Arrangement The terminals block of the E5CC-T is divided into five types of terminals: control outputs 1 and 2, sensor input, auxiliary outputs, input power supply, and options. Control outputs 1 and 2 Auxiliary outputs Sensor input...
  • Page 41 2 Preparations Terminal Details Do not connect anything to the terminals that are shaded gray. Linear current Relay output Control output 1 Control output 1 output Voltage output Control output 1 − − (for driving SSR) Control output 2 Voltage output (for driving SSR) Voltage output Control output 1...
  • Page 42 2 Preparations Auxiliary Outputs Model Numbers The E5CC-T has three auxiliary outputs. The code in the model number is always 3. E5CC-T@@ 3 @ @ M-@@@ No. of auxiliary outputs Code Auxiliary outputs Specification Model with 3 auxiliary outputs SPST-NO, 250 VAC, 2 A Terminal Details Model with 3 auxiliary outputs...
  • Page 43 2 Preparations Options Model Numbers The options specification of the E5CC-T is given in the following location in the model number. E5CC-T@@ @ @ @ M-@@@ Options Code Specification Remarks None Event inputs 1 and 2, and 002* Communications (RS-485) and CT1 Communications (RS-485), CT1, and CT2...

  • Page 44: E5Ec-T/E5Ac-T Terminal Block Wiring Example

    2 Preparations 2-2-2 E5EC-T/E5AC-T Terminal Block Wiring Example Terminal Arrangement The terminals block is divided into five types of terminals: control outputs 1 and 2, sensor input, auxiliary outputs, input power supply, and options. Not used. Input Power Supply Options...
  • Page 45 2 Preparations Terminal Details Do not connect anything to the terminals that are shaded gray. Relay output Control output 1 Voltage output Linear current Control output 1 Control output 1 − − output (for driving SSR) Voltage output Voltage output Relay output Control output 1 Control output 1...
  • Page 46 E5@C-T@@ @ @ @ M-@@@ Input power supply The codes that are given in the following table show the specification. Code Specification E5EC-T E5AC-T 100 to 240 VAC (50/60 Hz) 8.7 VA max. 9.0 VA max. 24 VAC, 50/60 Hz 5.5 VA max.
  • Page 47 2 Preparations Options Model Numbers The options specification is given in the following location in the model number. E5@C-T@@ @ @ @ M-@@@ Options Code Specification None or potentiometer input (Position-proportional Models only) Communications (RS-485), and event inputs 1 and 2 Potentiometer input (Position-proportional Models only) Event inputs 1 to 4 Communications (RS-485), event inputs 1 and 2, and CT1...
  • Page 48 2 Preparations Terminal Details Do not connect anything to the terminals that are shaded gray. − B(+) Communications RS-485 Event inputs A(−) − − Event inputs Event inputs Potentiometer Potentiometer input* input* − − B(+) Communications RS-485 Event inputs Event inputs A(−) −...

  • Page 49: Precautions When Wiring

    Inputs Refer to 2-2-1 E5CC-T Terminal Block Wiring Example or 2-2-2 E5EC-T/E5AC-T Terminal Block Wiring Example for the terminal arrangement. When extending the thermocouple lead wires, be sure to use compensating wires that match the thermocouple type. When extending the lead wires of a resistance thermometer, be sure to use wires that have low resistance and keep the resistance of the three lead wires the same.
  • Page 50 PNP, 12 VDC ±20%, 21 mA (with short-circuit protection) Voltage output (for driving SSR) (control output 2) Control output 1 and control output 2 are not isolated. E5EC-T/E5AC-T QX (voltage output (for RX (relay output) CX (linear current output) RR or PR (2 relays) driving SSR)) −...
  • Page 51 Auxiliary Outputs 1 to 4 On the E5CC-T, when heating/cooling control is used, auxiliary output 2 becomes control output (cooling). On the E5EC-T or E5AC-T, when heating/cooling control is used, auxiliary output 4 becomes control output (cooling). 2 - 18...
  • Page 52 Non-contact inputs Option number: 001 or 006 − Option number: 004 − Option number: 005 − − E5EC-T/E5AC-T Contact inputs Non-contact inputs Option number: 004 or 008 − Option number: 005 or 010 − − E5@C-T Digital Temperature Controllers User’s Manual (H185)
  • Page 53 2 Preparations Contact inputs Non-contact inputs Option number: 019 or 021 − − − Option number: 020 or 022 − − • Use event inputs under the following conditions: • The outflow current is approximately 7 mA. Contact input ON: 1 kΩ max., OFF: 100 kΩ min. No-contact input ON: Residual voltage of 1.5 V max.;...
  • Page 54 Models with an option number of 006 or 019 to 022 have a transfer output. E5CC-T Option number: 006 − − Linear current Linear voltage E5EC-T/E5AC-T Option number: 019, 020, 021, or 022 − − Linear current Linear voltage Output type Specification 4 to 20 mA DC, Load: 500 Ω...
  • Page 55 2 Preparations Communications RS-485 Models with an option number of 002 to 004, 008, 020, or 022 support RS-485 communications. Connect the communications cable across terminals 13 and 14. Communications Unit Connection Diagram Host computer RS-485 Shield − E5 C-T (No. 1) E5 C-T (No.

  • Page 56: Insulation Block Diagrams

    Relay outputs Auxiliary outputs 1, 2, and 3 : Reinforced insulation : Functional isolation E5EC-T/E5AC-T Sensor input, CT inputs, and potentiometer input Communications and event inputs Voltage outputs (for driving SSRs), linear current outputs, and transfer output Power supply...

  • Page 57: Using The Setup Tool Port

    For information on the models that can be used with CX-Thermo, contact your OMRON sales representative. The E58-CIFQ2-E is required to connect to the Setup Tool port on the front panel of the E5EC-T or E5AC-T. 2-4-1...
  • Page 58 Setup Tool Ports and Connecting Cables The location of the Setup Tool port on the E5EC-T/E5AC-T and the required cable are shown below. There are Setup Tool ports on both the top panel and front panel of the Digital Controller.
  • Page 59 2 Preparations • Front-panel Port E58-CIFQ2-E E58-CIFQ2 Connect the E58-CIFQ2 Conversion Cable USB-Serial Conversion Cable USB-Serial Conversion Cable to the E58-CIFQ2-E Conversion Cable. There is a triangle on the connecting surface. Align the arrow ( ) on the small connector on the E58-CIFQ2 USB-Serial Conversion Cable with the triangle mark ( ) on the small connector on the E58-CIFQ2-E Conversion Cable.

  • Page 60: Installing The Driver

    When the CX-Thermo Support Software for the Digital Controller is installed, the driver for the USB-Serial Conversion Cable will be copied to the following folder. C:\Program Files\OMRON\Drivers\USB\E58-CIF 3. Installing the Driver Install the driver to enable the Cable to be used with the personal computer.
  • Page 61 2 Preparations 2 - 28 E5@C-T Digital Temperature Controllers User’s Manual (H185)

  • Page 62: Part Names And Basic Procedures

    Part Names and Basic Procedures 3-1 Basic Application Flow ......... 3-2 3-2 Power ON .

  • Page 63: Basic Application Flow

    3 Part Names and Basic Procedures Basic Application Flow The following figure shows the basic flow for using the Digital Controller. Power ON Set the input type and other basic settings. • Input type • Control method • Make program-related settings. •...

  • Page 64: Power On

    3 Part Names and Basic Procedures Power ON After the power comes ON, all indicators and displays will light for approximately 1 second, and then the operation display will appear. The top display will show the PV and the middle display will show the SP. Power ON •...

  • Page 65: Part Names, Part Functions, And Setting Levels

    3 Part Names and Basic Procedures Part Names, Part Functions, and Setting Levels 3-3-1 Part Names and Functions E5CC-T Front panel Temperature unit Operation indicators No. 1 display PV or specified monitor/setting item Top View of E5CC-T No. 2 display Press O Key once to go to SP or specified monitor/setting value Program Setting Level.
  • Page 66 3 Part Names and Basic Procedures E5AC-T Front Panel Top View of E5AC-T Temperature unit No. 1 display Operation indicators PV or specified monitor/setting item No. 2 display SP or specified monitor/setting value No. 3 display Front-panel Setup Tool port Program No., segment No.,...
  • Page 67 Each indicator lights when the function that is assigned to corresponding auxiliary output (1 to 4) is ON. to 4 (auxiliary output 4: E5EC-T/E5AC-T only) Control outputs 1 Each indicator lights when the function that is assigned to and 2 corresponding control output (1 or 2) is ON.
  • Page 68 3 Part Names and Basic Procedures Name Overview Description Mode Key Changes the • Press once to go to the next parameter. parameter that is • Hold to go to the previous parameter. displayed within a setting level. Down Key and Up Set the value.

  • Page 69: Entering Numeric Values

    Tool port the computer (i.e., the CX-Thermo Support Software). Front-panel Setup Use the E58-CIFQ2 USB-Serial Conversion Cable and the E58-CIFQ2-E Tool port Conversion Cable to connect the E5EC-T/E5AC-T to the computer (i.e., the (E5EC-T/E5AC-T CX-Thermo Support Software). only) 3-3-2 Entering Numeric Values...

  • Page 70: Setting Levels

    3 Part Names and Basic Procedures 3-3-3 Setting Levels On the E5@C-T, the parameters are classified into levels according to their applications. These levels are called setting levels. The setting levels consist of some basic setting levels and other setting levels. Moving between Setting Levels The following figure gives an overall image of the setting levels.
  • Page 71 3 Part Names and Basic Procedures Press O and M Keys Protect Level for at least 1 s. Used to set protection Starting in manual mode for operations. Power ON Press O and M Keys Level changes automatically. for at least 3 s. Press O or S Key Press S Key.
  • Page 72 3 Part Names and Basic Procedures Basic Setting Levels Operation Level This level is displayed automatically when the power supply is turned ON. This level is used for the SP and other basic settings and monitoring. Normally, select this level for operation. Program Setting Level This level is used to set the parameters for the programs (SPs, rates of rise, times, etc.).

  • Page 73: Manual Control Level

    3 Part Names and Basic Procedures Use the following procedure to move to Advanced Function Setting Level. Power ON Level changes automatically. Step 4: Press for at least 3 s. Initial Setting Level Operation Level Step 5: Enter −169 for the amoV parameter. amov Moves to Advanced Function Setting Level Enter −169.
  • Page 74 3 Part Names and Basic Procedures Calibration Level This level is used to calibrate the Digital Controller. You can move to the Calibration Level from the Advanced Function Setting Level. You can use this level only when control is stopped. Monitor/Setting Item Level To use the S Key to display the Monitor/Setting Items, change the setting of the PF Setting parameter to pfdp.

  • Page 75: Procedures After Turning On The Power Supply

    3 Part Names and Basic Procedures Procedures after Turning ON the Power Supply 3-4-1 Basic Flow of Operations The basic flow of operations after you turn ON the power supply is shown below. 1. Turn ON the power supply. ↓ 2.

  • Page 76: Basic Procedure

    3 Part Names and Basic Procedures 3-4-2 Basic Procedure The basic procedure is given below. Turn ON the power supply. Operation Level s. e rr s.err (input error) flashes on the display if a sensor is not connected or if the connected sensor is different from input type.
  • Page 77 3 Part Names and Basic Procedures List of Input Types Temperature range in °C Temperature range in °F Input type Specifications Set value −200 to 850 −300 to 1500 Resistance Pt100 −199.9 to 500.0 −199.9 to 900.0 thermometer 0.0 to 100.0 0.0 to 210.0 −199.9 to 500.0 −199.9 to 900.0...

  • Page 78: Basic Operation 6

    3 Part Names and Basic Procedures Set the control method. Operation Level Operation Level Initial Setting Level Initial Setting Level in-t The display flashes. Press the O in-t (IN-T) will be displayed to show that the Initial Setting (Level) Key for at Level has been entered.
  • Page 79 3 Part Names and Basic Procedures Set the alarm type. Operation Level Operation Level Initial Setting Level Initial Setting Level in-t in-t (IN-T) will be displayed The display flashes. to show that the Initial Setting Level has been entered. Press the O (Level) Key for at least 3 seconds.
  • Page 80 3 Part Names and Basic Procedures Alarm Type Numbers Alarm Alarm type Description Operation type No. Alarm function There will be no alarm outputs. Upper- and The alarm output is ON while the Example: lower-limit PV is equal to or higher than the alarm upper-limit alarm point or while Temperature...
  • Page 81 3 Part Names and Basic Procedures Alarm Alarm type Description Operation type No. Absolute-value The alarm output is ON while the Example: upper-limit PV is equal to or higher than the alarm alarm value. Temperature Upper-limit alarm point (e.g., 100°C) Alarm value (e.g., 100°C) Absolute-value The alarm output is ON while the...
  • Page 82 3 Part Names and Basic Procedures Alarm Alarm type Description Operation type No. PV change rate The alarm output turns ON if the alarm change in the PV within the specified calculation period Change rate width exceeds a specific width. Time PV rate of change calculation period PV Change Rate Alarm Output...
  • Page 83 3 Part Names and Basic Procedures Set the programs. Set the programs, parameters (including the alarm values), and segments. Example: Segment 1 Segment 2 Segment 3 200.0 100.0 Segment 0 40.0 0.15 0.30 0.10 Time Program No. 0 Number of Segments Used: 4 Step Time/Rate of Rise Programming: Step time programming Segment No.
  • Page 84 3 Part Names and Basic Procedures Operation Level Operation Level Program Setting Level Program Setting Level d. p rg d.prg (d.PRG) is displayed. Indicates that you entered the Program Setting Level. Select program number 0. Press M (Mode) Key once. Press O (Level) Key once.

  • Page 85: Advanced Operations 7

    3 Part Names and Basic Procedures Start program operation (run). Operation Level Operation Level Press M (Mode) Key Press M (Mode) and several times. D Keys simultane- ously for at least 1 s. r-r (R-R): Set the Program Start parameter (Run/Reset) to run.

  • Page 86: Basic Operation

    Basic Operation 4-1 Moving between Setting Levels ........4-3 4-1-1 Moving to the Initial Setting Level .
  • Page 87 4 Basic Operation 4-9 Determining PID Constants (Autotuning and Manual Setting) ..4-49 4-9-1 AT (Auto-tuning) ..........4-50 4-9-2 RT (Robust Tuning) (Used for Autotuning) .

  • Page 88: Moving Between Setting Levels

    4 Basic Operation Moving between Setting Levels The Operation Level is displayed first when the power supply to the Digital Controller is turned ON. To display the parameters, you must move to the following setting levels. • Operation Level (Entered when the power supply is turned ON.) •...

  • Page 89: Moving To The Program Setting Level

    4 Basic Operation 4-1-2 Moving to the Program Setting Level Moving from the Operation Level to the Program Setting Level Press the O Key for less than 1 second in the Operation Operation Level Level. The display will change to the Program Setting Level and the Program Setting Level Display Program Selection parameter will be displayed.

  • Page 90: Moving To The Adjustment Level

    4 Basic Operation 4-1-3 Moving to the Adjustment Level Moving from the Operation Level to the Adjustment Level Operation Level Press the O Key twice for less than 1 second each time in the Operation Level. The display will change from the Operation Level to the Adjustment Adjustment Level Level.

  • Page 91: Moving To The Protect Level

    4 Basic Operation 4-1-5 Moving to the Protect Level Moving from the Operation Level to the Protect Level Operation Level Press the O and M Keys simultaneously for at least 3 seconds* in the Operation Level. The No. 1 display will flash when the keys are pressed for 1 s or longer.

  • Page 92: Moving To The Advanced Function Setting Level

    4 Basic Operation 4-1-6 Moving to the Advanced Function Setting Level Moving to the Advanced Function Setting Level for the First Time (i.e., with the Default Settings) To enter the Advanced Function Setting Level, you must first enter the Protect Level and change the setting of the icpt (Initial Setting/Communications Protect) parameter to 0 (enable moving to Advanced Function Setting Level) to clear the protection.
  • Page 93 4 Basic Operation Moving to the Advanced Function Setting Level after Clearing Protection After you have set the icpt (Initial Setting/Communications Protect) parameter to 0 (enable moving to Advanced Function Setting Level), select amov (Move to Advanced Function Setting Level) in the Initial Setting Level.

  • Page 94: Moving To The Communications Setting Level

    4 Basic Operation 4-1-7 Moving to the Communications Setting Level Moving from the Operation Level to the Communications Setting Level Operation Level Press the O Key for at least 3 seconds in the Operation Level. The No. 1 display will flash when the keys are pressed for 1 s or longer.

  • Page 95: Initial Setup Examples Through Starting Program Operation

    4 Basic Operation Initial Setup Examples through Starting Program Operation The initial setup, including setting the sensor input type, alarm types, control periods, program-related parameters, and other parameters, is done using parameter displays. To change the parameter that is displayed, use the O and M Keys. You can also use these keys to change the level depending on how long you press the key.

  • Page 96: Initial Setup Example For Step Time Programming

    4 Basic Operation 4-2-2 Initial Setup Example for Step Time Programming This example shows how to create the following program with step time programming. Programming Example for Step Time Programming In this example of step time programming, the program starts with a ramp. The segment time is 0, so you set only the segment SP.
  • Page 97 4 Basic Operation Operating Flow for Step Time Programming Item Operating flow Settings Page Turn ON the power supply and then press the O Key Power ON for at least three seconds to move to the Initial Setting Level. Make the Initial Setting Level initial Set the parameter to a K thermocouple (default).
  • Page 98 4 Basic Operation Item Operating flow Settings Page Create Program Setting Level the pro- • Set the program number to 0 (default). 4-39 Set the Program Number parameter. gram. • Set the parameter to 4. 4-40 Set the Number of Segments Used parameter. •...

  • Page 99: Initial Setup Example For Rate Of Rise Programming

    4 Basic Operation 4-2-3 Initial Setup Example for Rate of Rise Programming This example shows how to create the following program with rate of rise programming. Programming Example for Rate of Rise Programming In this example of rate of rise programming, the program starts with a ramp. Program operation is started from the PV.
  • Page 100 4 Basic Operation Operating Flow for Rate of Rise Programming Item Operating flow Settings Page Turn ON the power supply and then press the O Power ON Key for at least three seconds to move to the Initial Setting Level. Initial Setting Level Make Set the parameter to a K thermocouple...
  • Page 101 4 Basic Operation Item Operating flow Settings Page Program Setting Level Create • Set the program number to 0 (default). 4-39 Set the Program Number parameter. the pro- gram. • Set the parameter to 3. 4-40 Set the Number of Segments Used parameter. •...
  • Page 102 4 Basic Operation Item Operating flow Settings Page • Set the Run/Reset parameter to Run. 6-14 Operation Level Start Start program operation. pro- gram opera- tion. For details, refer to 4-7 Setting Programs for details on the rate of rise programming example. Additional Information If you need to execute autotuning before the SP is reached, change the SP Mode parameter to Fixed SP Mode, set the desired SP, and then execute autotuning.

  • Page 103: Setting The Input Type

    4 Basic Operation Setting the Input Type The Controller supports four input types: resistance thermometer, thermocouple, infrared temperature sensor, and analog inputs. Set the input type that matches the sensor that is used. 4-3-1 Input Type The following example shows how to set a K thermocouple for −20.0 to 500.0°C (input type 6).
  • Page 104 4 Basic Operation List of Input Types Temperature range in °C Temperature range in °F Specifications Set value −200 to 850 −300 to 1500 Pt100 −199.9 to 500.0 −199.9 to 900.0 Resistance 0.0 to 100.0 0.0 to 210.0 thermometer −199.9 to 500.0 −199.9 to 900.0 JPt100 0.0 to 100.0...

  • Page 105: Selecting The Temperature Unit

    4 Basic Operation Selecting the Temperature Unit 4-4-1 Temperature Unit • Either °C or °F can be selected as the temperature unit. • Set the temperature unit in the Temperature Unit (d-u) parameter of the Initial Setting Level. The default is c (°C). The following procedure selects °C.

  • Page 106: Selecting Pid Control Or On/Off Control (Not Supported For Position-Proportional Models.)

    4 Basic Operation Selecting PID Control or ON/OFF Control (Not Supported for Position-proportional Models.) Two control methods are supported: 2-PID control and ON/OFF control. Switching between 2-PID con- trol and ON/OFF control is executed by means of the PID ON/OFF parameter in the initial setting level. When this parameter is set to pid, 2-PID control is selected, and when set to onof, ON/OFF control, is selected.

  • Page 107: Setting Output Specifications

    4 Basic Operation Setting Output Specifications 4-6-1 Control Periods (Not Supported for Position-proportional Models.) • Set the output periods (control periods). Though a shorter period provides Control Period better control performance, it is recommended that the control period be set to (Heating) 20 seconds or longer for a relay output to preserve the service life of the relay.

  • Page 108: Assigned Output Functions (Assigning Control Outputs Is Not Supported For Position-Proportional Models.)

    Auxiliary Output 4 Assignment Alarm 4 (E5EC-T/E5AC-T only) If the Controller is equipped with HB/HS alarm detection, it is set by default to detect heater alarms (HA). Therefore, the alarm 1 function is disabled and the Alarm 1 Type is not displayed. To enable alarm 1, set an output assignment to alarm 1.
  • Page 109 Alarm 2 Alarm 2 Assignment (cooling) sub3 Auxiliary Output 3 Alarm 3 Alarm 3 Alarm 3 Alarm 3 Assignment E5EC-T or E5AC-T Without control output 2 With control output 2 Parameter name Display Standard Heating/cooling Standard Heating/cooling out1 Control Output 1...
  • Page 110 4 Basic Operation Assign the control outputs and auxiliary outputs. Control output 1: Control output (heating) Control output 2: Control output (cooling) Auxiliary output 1: Alarm 1 Auxiliary output 2: Alarm 2 Operating Procedure • Setting Heating/Cooling Control Initial Setting Level Press the M Key several times in the Initial Setting Level to 5-hc display s-hc (Standard or Heating/Cooling).

  • Page 111: Auxiliary Output Opening Or Closing In Alarm

    4 Basic Operation • Setting Auxiliary Output 2 Advanced Function Setting Press the M Key several times in the Advanced Function Level Setting Level to display sub2 (Auxiliary Output 2 Assignment). sub2 Auxiliary Output 2 Assignment alm2 Press the U or D Key to set the parameter to alm2. sub2 The default is alm2 (Alarm 2).

  • Page 112: Setting Programs

    4 Basic Operation Setting Programs 4-7-1 Programming Introduction You program operation so that the SP changes with time. The broken-line pattern that represents the changes in the SP over time is called a program. The programs are set in advance by the user. The main features are as follows: •...
  • Page 113 4 Basic Operation Programming Methods There are two programming methods: Step Time Programming, in which the time and SP are set, and Rate of Rise Programming, in which the segment type is set (to ramp, soak, or step) and the time, SP, and/or slope are set.
  • Page 114 4 Basic Operation Rate of Rise Programming • You set the segment type (soak, ramp, or step) and other parameters for each segment. • Ramp: You set only the SP and slope. You set the ending point as the SP and the slope until reaching the SP.

  • Page 115: Program Patterns

    4 Basic Operation 4-7-2 Program Patterns Program patterns are shown below. The starting segment changes as shown below depending on whether the starting point is the PV, fixed SP, or a set SP. Starting Point = PV or Fixed SP: Segment 0 Is Starting Segment Starting Point Is PV and Segment Is Ramp Starting Point Is Fixed SP and Segment Is Ramp Segment 0...
  • Page 116 4 Basic Operation Starting Point = Set SP: Segment 1 Is Starting Segment (Segment 0 = Step Operation) Starting Point Is PV and Segment Is Ramp Segment 1 Segment 2 Segment 0 Ramp 50°C Time Starting Point Is PV and Segment Is Soak Segment 1 Segment 2 Segment 0...

  • Page 117: Setting Flow For Program-Related Settings

    4 Basic Operation 4-7-3 Setting Flow for Program-related Settings After you set the parameters related to the initial program settings, set the parameter to create the pro- gram. The setting flows for program-related parameters are given below. Initial Program-related Settings Initial Setting Level Set the Program Time Unit parameter.

  • Page 118: Making The Initial Program-Related Settings

    4 Basic Operation The parameter setting procedures for the example in 4-2 Initial Setup Examples through Starting Pro- gram Operation are given starting on the next page. 4-7-4 Making the Initial Program-related Settings Set the following parameters before you create the program. Initial Setting Level Set the Program Time Unit parameter.
  • Page 119 4 Basic Operation Setting the Step Time/Rate of Rise Programming Parameter (i.e., the Program Setting Method) This parameter sets the program setting method. Related Parameters Parameter name Display Setting range Default Level t-pr time: Step time programming time Step Time/Rate of Initial Setting Level pr: Rate of rise programming Rise Programming...
  • Page 120 4 Basic Operation Setting the Time Unit of Ramp Rate Parameter (for Rate of Rise Programming) This parameter is set only for rate of rise programming. This parameter sets the time unit for the denom- inator of the Segment Slope parameter. Related Parameters Parameter name Display...
  • Page 121 4 Basic Operation Setting Example This example is for setting the parameter to stop control. Operating Procedure Press the M Key several times in the Initial Setting Level to Initial Setting Level select the Reset Operation parameter. rtsm Reset Operation stop Press the U or D Key to set stop (stop operation).
  • Page 122 4 Basic Operation Setting of the Startup Operation parameter Parameter Continue Reset Manual Mode Segment Number Retained. Retained. Elapsed Program Time Retained. Retained. Remaining Standby Time Retained. Retained. Program Repetitions Retained. Retained. Hold Status Retained. Retained. Auto/Manual Retained. Retained. Retained. Retained.
  • Page 123 4 Basic Operation Setting the Operation End Operation Parameter This parameter sets the operation to perform when the program has been completed. You can set any of the following options. • Reset Status (Default) • Operation will be ended. • Continue •...

  • Page 124: Creating The Program

    4 Basic Operation Related Parameters Parameter name Display Setting range Default Level spmd psp: Program SP SP Mode Adjustment Level fsp: Fixed SP Setting Example This procedure shows how to set the parameter to the program SP. Operating Procedure Press the M Key several times in the Adjustment Level to Adjustment Level select the SP Mode parameter.
  • Page 125 4 Basic Operation Setting Example This procedure shows how to select program 0. Operating Procedure Select the Display Program Selection parameter in Program Program Setting Level Setting Level. d.prg Display Program Selection Press the U or D Key to select 0. d.prg The default is the number of the currently executing program.
  • Page 126 4 Basic Operation Setting Example This procedure shows how to select segment 0. Operating Procedure Press the M Key several times in the Program Setting Level to Program Setting Level select the Display Segment Selection parameter. d.seg Display Segment Selection Press the U or D Key to select 0.
  • Page 127 4 Basic Operation Setting Example The following example shows how to set 50. Operating Procedure Specify a segment number for the Display Segment Selection Program Setting Level parameter and press the M Key several times to select the Segment 0 Segment SP parameter.
  • Page 128 4 Basic Operation Setting Example The following example shows how to set 0.40. Operating Procedure Specify a segment number for the Display Segment Selection Program Setting Level parameter and press the M Key several times to select the time Segment 1 Segment Time parameter.
  • Page 129 4 Basic Operation Setting Example The following example shows how to set alarm value 1 to 30°C. Operating Procedure Press the M Key several times in the Program Setting Level to Program Setting Level select the Alarm Value 1 parameter. al-1 Alarm Value 1 Press the U or D Key to select 30.

  • Page 130: Changing Programs During Operation

    4 Basic Operation 4-7-6 Changing Programs during Operation The temperature vector will change if the program is changed during operation. The following sections show how the temperature vector will changed. Step Time Programming • Changing the SP If the SP is changed during a segment, the present SP will move in a straight line with the changed SP as the target point.
  • Page 131 4 Basic Operation Rate of Rise Programming • If the rate of rise is changed during a segment, both the slope of the present SP and the segment time for the ramp period will change. Set point After change Point of change Before change Time...

  • Page 132: Setting The Fixed Sp

    4 Basic Operation Setting the Fixed SP You can set a fixed SP for the following purposes. • To perform fixed SP operation (i.e., control with a fixed SP) • To specify the starting point for autotuning all PID sets (i.e., the SP for the first execution of autotun- ing) For details on autotuning all PID sets, refer to 5-14-1 Autotuning All PID Sets (Autotuning).
  • Page 133 4 Basic Operation Reset Operation = Fixed SP Operation Press the M Key several times in the Operation Level to dis- Adjustment Level play the Run/Reset parameter. Run/Reset Press the D Key to select rst. The default is rst. Fixed SP Mode is entered (the fsp operation display will light). The following procedure sets the set point to 200°C.

  • Page 134: Determining Pid Constants (Autotuning And Manual Setting)

    4 Basic Operation Determining PID Constants (Autotuning and Manual Setting) There are two types of autotuning for the E5@C-T. Normal Autotuning • Autotuning is executed for the currently selected PID set. • The current SP when autotuning is specified is used as the autotuning SP. •...

  • Page 135: At (Auto-Tuning)

    4 Basic Operation 4-9-1 AT (Auto-tuning) • When AT is executed, the optimum PID constants for the set point at that time are set automatically. A method (called the limit cycle method) for forcibly changing the manipulated variable and finding the characteristics of the control object is employed.
  • Page 136 4 Basic Operation AT Operations AT is started when at-2 (100% AT), at-1 (40% AT) ata2 (all PID 100% AT), or ata1 (all PID 40% AT) is specified for the AT Execute/Cancel parameter. The TUNE indicator will light during execution. Only the Communications Writing, RUN/RESET, and AT Execution/Cancel parameters can be changed during AT execution.

  • Page 137: Rt (Robust Tuning) (Used For Autotuning)

    4 Basic Operation The 100% autotuning is executed. Operating Procedure Adjustment Level Press the M Key several times in the Adjustment Level to dis- play at (AT Execute/Cancel). AT Execute/ Cancel Press the U or D Key to select at-2 (100% AT execute). The TUNE indicator will light during autotuning.
  • Page 138 4 Basic Operation RT Features • Even if hunting occurs for PID constants when autotuning is executed in normal mode, it is less likely to occur when autotuning is executed in RT Mode. Temperature Temperature Much hunting occurs. Hunting is reduced. Set value Set value Time...

  • Page 139: Manual Setup

    4 Basic Operation 4-9-3 Manual Setup You can manually set individual PID constants in the Proportional Band, Integral Time, and Derivative Time parameters in the PID Setting Level after you select the PID set number with the Display PID Selection parameter. If you change the setting of the Proportional Band, Integral Time, and Derivative Time parameters in the Adjustment Level, the new settings are saved in the Proportional Band, Integral Time, and Derivative Time parameters for the currently selected PID set.
  • Page 140 4 Basic Operation When P (Proportional Band) Is Adjusted The curve rises gradually, and a long stabilization time is created, but overshooting is prevented. value Increased Overshooting and hunting occur, but the set value is quickly reached and the temperature stabilizes. value Decreased When I (Integral Time) Is Adjusted...

  • Page 141: Alarm Outputs

    4 Basic Operation 4-10 Alarm Outputs • You can use alarms on models with auxiliary outputs. For relay outputs or voltage outputs (for driving SSRs), alarms can also be used by setting the Control Output 1 Assignment or Control Output 2 Assignment parameter to any of the alarms from alarm 1 to 4.
  • Page 142 4 Basic Operation Alarm output operation Alarm type Description of function When alarm value When alarm value value X is positive X is negative Upper- and Set the upward deviation in lower-limit range*1 the set point for the alarm upper limit (H) and the lower deviation in the set point for the alarm lower limit (L).
  • Page 143 4 Basic Operation Alarm output operation Alarm type Description of function When alarm value When alarm value value X is positive X is negative MV absolute-value Standard Control Standard Control This alarm type turns ON lower-limit alarm*9 the alarm when the manipulated variable (MV) is lower than the alarm Heating/Cooling...

  • Page 144: Alarm Values

    4 Basic Operation • With rate of rise programming, if the Reset Operation parameter is set to stop control and the Segment Type parameter of segment 0 is set to Soak, the applicable SP for a deviation alarm (alarm type 1 to 7) is the PV. 4-10-2 Alarm Values •...
  • Page 145 4 Basic Operation • Setting the Alarm Value Press the O Key for less than 1 second in the Operation Program Setting Level Level. d.prg Display Program The display will change to the Program Setting Level. Selection Press the U or D Key to set 1. d.prg Press M Key several times to select the Alarm Value 1 param- al-1...
  • Page 146 4 Basic Operation SP Alarms You can set an SP absolute-value upper-limit or SP absolute-value lower-limit alarm for the set point (SP). The alarm point is set in the corresponding alarm value parameter. The Alarm SP Selection parameter is used to specify the alarm for either the ramp SP or the target SP. The corresponding alarm hysteresis setting is also valid.

  • Page 147: Alarm Hysteresis

    4 Basic Operation 4-11 Alarm Hysteresis • The hysteresis of alarm outputs when alarms are switched ON/OFF can be set as follows: Upper-limit alarm Lower-limit alarm Alarm hysteresis Alarm hysteresis Alarm value Alarm value • Alarm hysteresis is set independently for each alarm in the Alarm Hysteresis 1 to Alarm Hysteresis 4 parameters (Initial Setting Level).

  • Page 148: Alarm Latch

    4 Basic Operation 4-11-2 Alarm Latch • The alarm latch can be used to keep the alarm output ON until the latch is canceled regardless of the temperature once the alarm output has turned ON. Any of the following methods can be used to clear the alarm latch. •...

  • Page 149: Using Heater Burnout (Hb) And Heater Short (Hs) Alarms (Not Supported For Position-Proportional Models.)

    4 Basic Operation 4-12 Using Heater Burnout (HB) and Heater Short (HS) Alarms (Not Supported for Position-proportional Models.) These functions are supported for models that detect heater burnout (HB) and heater short (HS) alarms. 4-12-1 HB Alarm What Is an HB Alarm? An HB alarm is detected by measuring the heater current with a current transformer (CT) when the control output is ON.
  • Page 150 4 Basic Operation Toff Control output (heating) In the above diagram, power is considered to be ON (normal) if the heater current is greater than hb1 or hb2 (heater burnout detection current) during the Ton interval. The HB alarm will be OFF in this case.

  • Page 151: Hs Alarm

    4 Basic Operation • Checking the Heater Current Adjustment Level Press the M Key several times in the Adjustment Level to display ct1 (Heater Current 1 Value Monitor). Heater Current 1 Value Monitor Check the heater current from the CT input that is used to detect heater burnout.
  • Page 152 4 Basic Operation Parameters Parameter No. 1 display Value No. 2 display Level off, on HS Alarm Use OFF or ON Advanced Function (default: ON) Setting Level off, on HS Alarm Latch OFF or ON (default: OFF) HS Alarm Hysteresis 0.1 to 50.0 A 0.1 to 50.0 (default: 0.1 A)

  • Page 153: Installing Current Transformers (Ct)

    For the E5CC-T, connect the CT in advance to terminals 16 and 17 (CT1), or 17 and 18 (CT2). For the E5EC-T/E5AC-T, connect the CT in advance to terminals 19 and 20 (CT1) or 20 and 21 (CT2). Then pass the heater power line through the hole in the CT. For specifications, models, and dimen- sions of the CTs that can be used with the Digital Controller, refer to A-2 Current Transformer (CT).
  • Page 154 4 Basic Operation (a) Delta connecting lines: Refer to the following diagram for CT installation positions. * Heater voltage fluctuations are not considered, so be sure to take that into account when setting the detection current. Load (such as a heater) Load AC line Product...

  • Page 155: Calculating Detection Current Values

    4 Basic Operation 4-12-4 Calculating Detection Current Values Calculate the set value using the following equation: Heater Burnout Detection 1/2 set value = Normal current value + Burnout current value HS Alarm 1/2 set value = Leakage current value (output OFF) + HS current value •...
  • Page 156 4 Basic Operation Example: Using Three 200-VAC, 1-kW Heaters Normal Burnout 15 A 10 A Load Load Load Load Load Load 200 V 200 V Burnout 15 A 10 A Product Product To CT input To CT input The heater power supply provides 15 A when the current is normal, and 10 A when there is a burnout, so the heater burnout detection current is calculated as follows: (Normal current) + (Heater burnout current) Heater burnout detection current =...
  • Page 157 4 Basic Operation The heater burnout current when there is a burnout at the load is as follows: (Heater burnout detection current) = (17.3 + 10) / 2 13.65 [A] To enable detection in either case, use 16.1 A as the heater burnout detection current. (b) Star Connecting Lines Example: Using Three 200-VAC, 2-kW Heaters Normal...
  • Page 158 4 Basic Operation (c) V Connecting Lines Example: Using Two 200-VAC, 2-kW Heaters Normal 10 A Product 200 V To CT input 17.3 A 200 V 200 V 10 A Product To CT input Normal Burnout 10 A Product Product 200 V 200 V To CT input...

  • Page 159: Using On/Off Control (Not Supported For Position-Proportional Models.)

    4 Basic Operation 4-13 Using ON/OFF Control (Not Supported for Position-proportional Models.) In ON/OFF control, the control output turns OFF when the temperature being controlled reaches the preset set point. When the manipulated variable turns OFF, the temperature begins to fall and the con- trol turns ON again.

  • Page 160: Settings

    4 Basic Operation Parameters Display Parameter Application Level s-hc Standard or Specifying control Initial Setting Level Heating/Cooling method cntl PID ON/OFF Specifying control Initial Setting Level method oreV Direct/Reverse Specifying control Initial Setting Level Operation method c-db Dead Band Heating/cooling Adjustment Level control Hysteresis (Heating)

  • Page 161: Customizing The Pv/Sp Display

    The following table shows the contents of the No. 1, 2, and 3 displays, according to the setting of the PV/SP Display Screen Selection parameter in the Advanced Function Setting Level. Set value No. 1 display No. 2 display No. 3 display (E5EC-T/E5AC-T only) Nothing is displayed. Nothing is displayed. Nothing is displayed. Nothing is displayed.

  • Page 162: Advanced Operations

    Advanced Operations 5-1 Shifting Input Values ......... . . 5-3 5-2 Setting Scaling Upper and Lower Limits for Analog Inputs .
  • Page 163 5 Advanced Operations 5-14 Determining PID Constants for PID Sets (Autotuning for All PID Sets) . . 5-45 5-14-1 Autotuning All PID Sets (Autotuning) ....... . 5-45 5-14-2 Executing Autotuning for All PID Sets .

  • Page 164: Shifting Input Values

    5 Advanced Operations Shifting Input Values Shifting Inputs You can set the PV Slope Coefficient and PV Input Shift parameters to compensate the PV. Parameter Setting range Unit Default °C or °F Temperature input: −199.9 to 999.9 PV Input Shift Analog input: −1,999 to 9,999 None 1.000...
  • Page 165 5 Advanced Operations Using the PV Input Shift After shifting 1000 °C 970 °C 1,000°C is shifted to 970°C. 500°C is shifted to 550°C. 550 °C 500 °C Before shifting 200 °C 500 °C 1000 °C 1300 °C (1) Find the two points to shift and determine the PVs after the shifts are applied. Example: Shift 500°C (temperature before shifting) to 550°C (temperature after shifting).

  • Page 166: Setting Scaling Upper And Lower Limits For Analog Inputs

    5 Advanced Operations Setting Scaling Upper and Lower Limits for Analog Inputs Analog Input • When an analog input is selected, scaling can be performed as needed by the in-h Scaling Upper control application. Limit • Scaling is set in the Scaling Upper Limit, Scaling Lower Limit, and Decimal Point parameters (Initial Setting Level).
  • Page 167 5 Advanced Operations • Setting the Scaling Lower Limit Initial Setting Level Press the M Key several times in the Initial Setting Level to display in-l (Scaling Lower Limit). in-l Scaling Lower Limit Press the U or D Key to set the value to 100. in-l The default is 0.

  • Page 168: Executing Heating/Cooling Control (Not Supported For Position-Proportional Models.)

    Auxiliary Output 4 Assignment sub4 Alarm 4 (E5EC-T/E5AC-T only) If the Controller is equipped with HB/HS alarm detection, it is set by default to ha (Heater Alarm). Each output assignment is automatically initialized as shown below when changing between standard and heating/cooling control.
  • Page 169 5 Advanced Operations Without control output 2 With control output 2 Parameter name Display Standard Heating/cooling Standard Heating/cooling Auxiliary Output 2 sub2 Alarm 2 Alarm 2 Alarm 2 Alarm 2 Assignment Auxiliary Output 3 sub3 Alarm 3 Alarm 3 Alarm 3 Alarm 3 Assignment Auxiliary Output 4...
  • Page 170 5 Advanced Operations Heating/Cooling PID Control If heating/cooling PID control is used, you can set PID control separately for heating and cooling. The PID constants for both heating and cooling can be automatically set according to the cooling control characteristics by setting the Heating/Cooling Tuning Method parameter and then performing autotuning (AT).
  • Page 171 5 Advanced Operations Three-position Control • Set the PID ON/OFF parameter to onof and set the Standard or Heating/Cooling Parameter to h-c to perform three-position control. • A dead band (an area where the MV is 0) can be set for either heating or cooling control. Reverse operation Dead band Hysteresis (heating)

  • Page 172: Using Event Inputs

    • The number of event inputs that is supported depends on the model of the Digital Controller. E5CC-T: Up to 4 event inputs E5EC-T/E5AC-T: Up to 6 event inputs • Event inputs can be used for changing between run and reset status, changing between automatic...
  • Page 173 5 Advanced Operations Turn event inputs ON and OFF while the power is being supplied. Event input ON/OFF changes are detected for inputs of 50 ms or longer. The functions are described in detail below. Changing the Run/Reset Status When the Event Input Assignment parameter is set to RR-1 (Run (OFF)/Reset (ON)), program operation will start when the event input turns OFF.
  • Page 174 5 Advanced Operations status of the event inputs and the number of the selected program is shown in the following table. The status of any input that is not assigned is taken as OFF. Program number Program Number Switch 0 Program Number Switch 1 Program Number Switch 2 Control by Inverting Direct/Reverse Operation...
  • Page 175 5 Advanced Operations Input contact Status AT canceled. 100% AT executed for all PID sets. Switching between 40% AT Execute/Cancel for All PID Sets When the Event Input Assignment parameter is set to ATA1 (All PID 40% AT Execute/Cancel), 40% AT will be executed for all PID sets when the event input turns ON.
  • Page 176 5 Advanced Operations Parameters Display Parameter Description Level eV-1 Event Input Assignment 1 Initial Setting Level eV-2 Event Input Assignment 2 Initial Setting Level ev-3 Event Input Assignment 3 Initial Setting Level Function of event input ev-4 Event Input Assignment 4 Initial Setting Level ev-5 Event Input Assignment 5...

  • Page 177: Setting The Sp Upper And Lower Limit Values

    5 Advanced Operations Setting the SP Upper and Lower Limit Values 5-5-1 Set Point Limiter The setting range of the set point is limited by the set point limiter. This function can be used to prevent setting incorrect set points. The upper- and lower-limit values of the set point limiter are set using the Set Point Upper Limit and Set Point Lower Limit parameters in the Initial Setting Level.

  • Page 178: Setting

    5 Advanced Operations 5-5-2 Setting Set the set point upper and lower limits in the Set Point Upper Limit and Set Point Lower Limit parame- ters in the Initial Setting Level. In this example, it is assumed that the input type is set to a K thermocou- ple with a temperature range of −200 to 1300°C.

  • Page 179: Using The Key Protect Level

    5 Advanced Operations Using the Key Protect Level 5-6-1 Protection • To move to the Protect Level, press the O and M Keys at the same time for at least three seconds* in the Operation Level, Program Setting Level, Adjustment Level, or PID Setting Level. * The key pressing time can be changed in the Move to Protect Level Time parameter (Advanced Function Setting Level).

  • Page 180: Entering The Password To Move To The Protect Level

    5 Advanced Operations Initial Setting/Communications Protect This protect level restricts movement to the Initial Setting Level, Communications Setting Level, and Advanced Function Setting Level. icpt Communications Advanced Function Set value Initial Setting Level Setting Level Setting Level Possible to reach Possible to reach Possible to reach Possible to reach...
  • Page 181 Precautions for Correct Use Protection cannot be cleared or changed without the password. Be careful not to forget it. If you forget the password, contact your OMRON sales representative. Communications Operation Command to Move to the Protect Level • The Write Variable operation command can be used via communications to write the password to the Move to Protect Level parameter.

  • Page 182: Hiding Parameters

    5 Advanced Operations Hiding Parameters 5-7-1 Parameter Mask Settings You can use a key operation to hide parameters that do not need to be displayed. This allows you to prevent incorrect settings for parameters or to simplify the parameter configuration according to the application.
  • Page 183 5 Advanced Operations Setting Example In this example, the SP Mode parameter in the Adjustment Level is set to mask (mask (hide)). Operating Procedure Moving to Parameter Mask Mode (Advanced Function Setting Level) Press the M Key several times in the Advanced Function Advanced Function Setting Level Setting Level to display the Parameter Mask Setting...

  • Page 184: Or Output Of Alarms

    5 Advanced Operations OR Output of Alarms 5-8-1 Integrated Alarm You can use an integrated alarm to output an OR of alarms 1 to 4, the HB alarm, the HS alarm, and the input error. Set the Integrated Alarm Assignment parameter (alma) and then assign the integrated alarm (alm) to an auxiliary output or a control output.
  • Page 185 5 Advanced Operations Operating Procedure The following procedure outputs an OR of the following alarms on auxil- iary output 2. • Alarm 1 • HB alarm (hb) The settings are made in the Advanced Function Setting Level. Operating Procedure • Assigning the Integrated Alarm to an Auxiliary Output Advanced Function Setting Press the M Key several times in the Advanced Function Set- Level...

  • Page 186: Alarm Delays

    5 Advanced Operations Alarm Delays 5-9-1 Alarm Delays • Delays can be set for the alarm outputs. ON and OFF delays can be set separately for alarms 1, 2, 3, and 4. The ON and OFF delays for alarms 1, 2, 3, and 4 also apply to the individual SUB1, SUB2, SUB3, and SUB4 indicators and to communications status.
  • Page 187 5 Advanced Operations Use the following procedure to set ON and OFF delays for the alarm 1. An ON delay of 5 seconds and an OFF delay of 10 s will be set. Operating Procedure • Setting the Alarm 1 ON Delay Advanced Function Setting Press the M Key several times in the Advanced Function Set- Level...

  • Page 188: Loop Burnout Alarm (Not Supported For Position-Proportional Models.)

    5 Advanced Operations 5-10 Loop Burnout Alarm (Not Supported for Position-proportional Models.) 5-10-1 Loop Burnout Alarm (LBA) • With a loop burnout alarm, there is assumed to be an error in the control loop if the control deviation (SP - PV) is greater than the threshold set in the LBA Level parameter and if the control deviation is not reduced by at least the value set in the LBA Detection Band parameter within the LBA detection time.
  • Page 189 5 Advanced Operations • Detection is not possible if a fault occurs that causes a decrease in temperature while control is being applied to decrease the temperature (e.g., a heater burnout fault). Parameters Related to Loop Burnout Alarms Parameter Display Setting range Remarks Level...
  • Page 190 5 Advanced Operations LBA Level • Set the control deviation when the control loop is working properly. • The default is 8.0 (°C/°F) for Controllers with Temperature Inputs and 10.00% FS for Controllers with Analog Inputs. LBA Band • There is assumed to be an error in the control loop and the alarm output turns ON if the control deviation is greater than the threshold set in the LBA Level parameter and if the control deviation does not change by at least the value set in the LBA Band parameter.
  • Page 191 5 Advanced Operations Press the U or D Key to set the value to 8.0. lbal The default is 8.0 (°C/°F). • Setting the LBA Band Advanced Function Setting Press the M Key several times in the Advanced Function Set- Level ting Level to display lbab (LBA Band).

  • Page 192: Performing Manual Control

    5 Advanced Operations 5-11 Performing Manual Control You can perform manual operation with PID control or with a Position-proportional Model. 5-11-1 Manual MV Standard Models and Position-proportional Models (Close Control with Direct Setting of Position Proportional MV Parameter Set to ON) If you change to Manual Mode, the Manual MV parameter will be displayed and the displayed value will be output as the MV.
  • Page 193 5 Advanced Operations Precautions for Correct Use • The automatic display return function will not operate in Manual Mode. • Switching between automatic and manual operation is possible for a maximum of one million times. Related Displays and Parameters Parameter name Display Setting range Default...
  • Page 194 5 Advanced Operations • Using the PF Key to Move to the Manual Control Level • If the PF Setting parameter is set to A-M (auto/manual), you can change to manual operation (Manual Control Level) by pressing the PF Key for at least one second from the Operation Level, Program Setting Level, Adjustment Level, or PID Setting Level.

  • Page 195: Using The Transfer Output

    Transfer Output Signal (Initial Setting Level) You can use the Transfer Output Signal parameter to specify whether to output a current or voltage from the transfer output. Terminal Arrangement E5CC-T E5EC-T/E5AC-T Option number: 006 Option number: 019, 020, 021, or 022 Transfer output Transfer output...
  • Page 196 5 Advanced Operations Transfer Scaling • Reverse scaling is possible by setting the Transfer Output Lower Limit parameter larger than the Transfer Output Upper Limit parameter. If the Transfer Output Lower Limit and Transfer Output Upper Limit parameters are set to the same value, the transfer output will be output continuously at 0%.
  • Page 197 5 Advanced Operations The following procedure sets the transfer output for an SP range of −50 to 200. Operating Procedure • Setting the Transfer Output Type Initial Setting Level Press the M Key several times in the Initial Setting Level to display tr-t (Transfer Output Type).

  • Page 198: Using Pid Sets

    5 Advanced Operations 5-13 Using PID Sets 5-13-1 PID Sets One set of all the parameters that are related to 2-PID control are called a PID set. • You can register up to eight PID sets. • There are the following two ways that you can specify PID sets. •...

  • Page 199: Pid Sets

    5 Advanced Operations Parameter Display Setting range Unit Default Level name PID * Integral *.c-i Same as PID * Integral Time. Time (Cooling) PID * Derivative *.c-d Same as PID * Derivative Time. Time (Cooling) °C or °F PID * Dead Temperature input: -199.9 to 999.9 *.cdb Analog input: -19.99 to 99.99...
  • Page 200 5 Advanced Operations Setting a Fixed PID Set You can set any of the PID sets from 1 to 8. Specify the PID set number between 1 and 8 in the PID Set No. parameter in the Program Setting Level. (The default is 1.) Program No.
  • Page 201 5 Advanced Operations Using Automatic Selection of PID Sets by Zone You can set the PID Set No. parameters in the Program Setting Level to 0 (automatic selection) to auto- matically select PID sets by zones. • The PID set is automatically set according to which of the preset zones contains the PV (process value), SP (set point), or DV (deviation) (as specified in the PID Set Automatic Selection Data parameter).

  • Page 202: Settings For Pid Sets

    5 Advanced Operations 5-13-2 Settings for PID Sets This section describes the procedures to make settings to use fixed PID sets and to use automatic selection of PID sets according to zones. Using Fixed PID Sets Setting Example This example shows how to set PID set 1 for program 0. Operating Procedure Specifying the PID Set Number (Program Setting Level) Move to the Program Setting Level.
  • Page 203 5 Advanced Operations Using Automatic Selection of PID Sets by Zone Setting Example In this example, automatic selection is specified for program 0 and then settings are made to automati- cally select PID sets 1 to 8 according to the following PV (process value) zones. Parameter name Set value Unit...
  • Page 204 5 Advanced Operations Operating Procedure Setting Automatic Selection of PID Sets (Program Setting Level) Move to the Program Setting Level. The Display Program Program Setting Level Selection parameter is displayed. d.prg Display Program Selection Press the U or D Key to select 0. d.prg The default is the currently selected program number.

  • Page 205: Setting Pid Set Parameters

    5 Advanced Operations 5-13-3 Setting PID Set Parameters This section provides the procedures to set PID-related parameters manually. You do not need to set these parameters manually if you set them automatically with AT (autotuning). Setting Example In this example, the PID 1 Proportional Band parameter (for PID set 1) is set to 20.0. Operating Procedure Setting the PID 1 Proportional Band (PID Setting Level) Move to the PID Setting Level.

  • Page 206: Determining Pid Constants For Pid Sets (Autotuning For All Pid Sets)

    5 Advanced Operations 5-14 Determining PID Constants for PID Sets (Autotuning for All PID Sets) 5-14-1 Autotuning All PID Sets (Autotuning) Introduction You can perform autotuning for all PID sets at the same time to automatically calculate and set the PID constants for the PID sets in the order of the set numbers.
  • Page 207 5 Advanced Operations Related Parameters Restrictions for Parameter Display Setting range Default autotuning all PID Level sets psp: Program SP Must be set to a spmd SP Mode fsp: Fixed SP fixed SP. *1*2 ata1: All PID 40% AT Must be set to All ata2: All PID 100% AT AT Execute/Cancel PID 40% AT or All...
  • Page 208 5 Advanced Operations Description Operation When you autotune all PID sets, the PID sets are autotuned in order of the PID set numbers with the fixed SP (FSP) as the lower limit (starting point) and the All PID AT Upper Limit SP as the upper limit (ending point).
  • Page 209 5 Advanced Operations Operation Waveform Example The waveform for autotuning all PID sets is shown below for when the zone for PID set 1 contains the fixed SP (FSP) and the zone for PID set 8 contains the All PID AT Upper Limit SP. The autotuning SP for each PID set is as follows: Value •...
  • Page 210 5 Advanced Operations Conditions • Reset Operation = Stop control • PID Set Automatic Selection Data = PV • Program No. 0 = 0 • PID Set No = 0 (Auto selection) • PID 1 Automatic Selection Range Upper Limit = 200 (Range for PID set 1: Fixed SP to 200) •...
  • Page 211 5 Advanced Operations Setting the Upper Limits of the Zones for the PID Sets (PID Setting Level) Press the M Key several times in the PID Setting Level to PID Setting Level select the PID 1 Automatic Selection Range Upper Limit 1.aut PID 1 Automatic Selection Range...
  • Page 212 5 Advanced Operations Setting the Autotuning Starting and Ending Points Setting the Autotuning Starting Point (Fixed SP) (Adjustment Level) Press the M Key several times in the Adjustment Level to Adjustment Level select the Fixed SP parameter. Fixed SP Press the U or D Key to set 100. The default is 0.

  • Page 213: Executing Autotuning For All Pid Sets

    5 Advanced Operations Starting Operation in Fixed SP Mode (Operation Level) (The Reset Operation parameter must be set to stop control.) Press the M Key several times in the Operation Level to Operation Level display the Run/Reset parameter Run/Reset Press the U or D Key to set run. The default is rst (reset).

  • Page 214: Program-Related Functions

    5 Advanced Operations 5-15 Program-related Functions This section describes the following program-related functions. • Advance • Segment Jump • Hold • Wait • Program Repetition • Program Links • SP Shift • Time Signals • Program End Outputs • RUN Output •...

  • Page 215: Segment Jump

    5 Advanced Operations 5-15-2 Segment Jump You can force a jump to a specified segment. • This function can be performed only with a key operation. • When you change the Segment No. parameter (Operation Level), operation will jump to the start of the specified segment.

  • Page 216: Wait

    5 Advanced Operations Related Parameters Pausing Program Operation with a Key Operation Parameter Display Setting range Default Level name on: Hold hold Hold Operation Level off: Hold clear Pausing Program Execution with an Event Input Parameter Display Setting range Default Level name Event Input...

  • Page 217: Program Repetition

    5 Advanced Operations Related Parameters Enabling Waiting and Setting a Wait Band Parameter Display Setting range Default Level name Temperature input: 0.1 to 999.9°C or °F, wt-b Wait Band Adjustment Level Analog input: 0.01 to 99.99 Enabling and Disabling Waiting with an Event Input Parameter Display Setting range...

  • Page 218: Sp Shift

    5 Advanced Operations 5-15-7 SP Shift You can shift the program patterns vertically. The shift is applied to all of the programs. • The program SP is shifted by the amount set in the Program SP Shift Value parameter (Adjustment Level).
  • Page 219 5 Advanced Operations • If an advance operation is executed, a time equivalent to the set program time will be considered to have elapsed. For example, if an advance operation is executed before the ON time elapses in the above figure, the output remains ON from the start of the next segment until the OFF time has elapsed.

  • Page 220: Program End Outputs

    5 Advanced Operations 5-15-9 Program end outputs You can set an output to turn ON when a program ends (i.e., at the end of the last segment) and then turn OFF after a specified time. • You can assign this function to either an auxiliary output or a control output. If you do not assign this function, no output is made and only p.end and the SP are displayed alternately.

  • Page 221: Run Output

    5 Advanced Operations Related Parameters Parameter Display Setting range Default Level name Auxiliary Output 1 Assignment: alm1* Auxiliary Output 2 Assignment: sub1 alm2* Auxiliary sub2 Auxiliary Output Output 1 to 4 sub3 3 Assignment: Assignment or sub4 p.end: Program end output alm3* Control Output Advanced...

  • Page 222: Stage Outputs

    5 Advanced Operations 5-15-11 Stage Outputs A pulse is output for one second from the beginning of each segment. • You can assign this function to either an auxiliary output or a control output. Time Stage output Note If the power supply is turned OFF, a software reset is performed with an operation command through communications, or the Initial Setting Level is entered while the stage output is ON, the stage output will turn OFF.
  • Page 223 5 Advanced Operations only the SP start option can be set (because in this case program operation will always start from the process value (PV)). • Set the PV Start parameter (Initial Setting Level) to one of the following settings. •...

  • Page 224: Standby Operation

    5 Advanced Operations Precautions for Correct Use If the reset operation is fixed SP control, rate of rise programming is set, and segment 0 is a step segment, the program pattern includes everything from the fixed SP (the SP for starting program operation) to the SP for segment 0 (step segment).

  • Page 225: Changing The Sp Mode

    5 Advanced Operations • If the power is interrupted during standby status, the remaining standby time is held (if the Startup Operation parameter is set to Continue or Manual and the program was running and with manual operation before the power was interrupted). Related Parameters Parameter Display...

  • Page 226: Sp Tracking

    5 Advanced Operations Related Parameters Changing between Program SP Mode and Fixed SP Mode with a Key Operation Parameter Display Setting range Default Level name psp: Program SP spmd SP Mode Adjustment Level fsp: Fixed SP Changing between Program SP Mode and Fixed SP Mode with an Event Input Parameter Display Setting range...

  • Page 227: Operations Related To Other Functions

    5 Advanced Operations 5-15-16 Operations Related to Other Functions Changing to Manual Mode during Operation and Operation for Errors In the following cases, timing of program progression is continued. • When you change to Manual Mode during program operation • When an input error occurs during program operation •...

  • Page 228: Output Adjustment Functions

    5 Advanced Operations 5-16 Output Adjustment Functions 5-16-1 Output Limits • Output limits can be set to control the output using the upper and lower limits to the calculated MV. • The following MV takes priority over the MV limits. Manual MV* MV at Reset MV at PV error...

  • Page 229: Mv At Pv Error

    5 Advanced Operations Related Parameters Parameter Setting range Unit Default Standard control: −5.0 to 105.0 MV at Reset Heating/cooling control: −105.0 to 105.0 Position-proportional Control Direct Setting of Position Proportional MV parameter set to ON for close control: −5.0 to 105.0 % or 0.0 or Floating control or Direct Setting of Position Proportional MV parameter set...
  • Page 230 5 Advanced Operations • The order of priority of the MV is illustrated in the following diagram. Manual MV* MV upper limit MV at PV Error RUN/Reset Output calculations Input error Auto/Manual Potentiometer input Time error (close control) MV at Reset MV lower limit * When the Manual MV Limit Enable parameter is set to ON, the setting range will be the MV lower limit to the MV upper limit.

  • Page 231: Using The Extraction Of Square Root Parameter

    5 Advanced Operations 5-17 Using the Extraction of Square Root Parameter 5-17-1 Extraction of Square Roots • For analog inputs, the Extraction of Square Root parameter is provided for inputs so that differential pressure-type flow meter signals can be directly Extraction of Square Root input.
  • Page 232 5 Advanced Operations • Setting the Extraction of Square Root Low-cut Point Adjustment Level Press the M Key several times in the Adjustment Level to dis- sqrp Extraction of play sqrp (Extraction of Square Root Low-cut Point). Square Root Low-cut Point Press the U or D Key to set the value to 10.0.

  • Page 233: Setting The Width Of Mv Variation

    5 Advanced Operations 5-18 Setting the Width of MV Variation 5-18-1 MV Change Rate Limit • The MV change rate limit sets the maximum allowable width of change per second in the MV (or the change per second in the valve opening for a Position-proportional Model).
  • Page 234 5 Advanced Operations This procedure sets the MV change rate limit to 5.0%/s. The related parameters are as follows: PID ON/OFF = PID Operating Procedure • Setting 2-PID Control Initial Setting Level Press the M Key several times in the Initial Setting Level to cntl display cntl (PID ON/OFF).

  • Page 235: Setting The Pf Key

    5 Advanced Operations 5-19 Setting the PF Key 5-19-1 PF Setting (Function Key) PF Setting (Advanced • Pressing the PF Key for at least one second executes the operation set in the PF Setting parameter. The default is shft (digit shift). Function Setting Level) shft Set value...
  • Page 236 5 Advanced Operations Monitor/Setting Item Monitor/Setting Item 1 (Advanced Function Setting Setting the PF Setting parameter to the Monitor/Setting Item makes it Level) possible to display monitor/setting items using the S Key. The following table pfd1 Setting Item 5 shows the details of the settings. For setting (monitor) ranges, refer to the pfd5 applicable parameter.
  • Page 237 5 Advanced Operations Setting Monitor/Setting Items Pressing the S Key in either the Operation or Adjustment Level displays the applicable monitor/setting items. Press the S Key to display in order Monitor/Setting Items 1 to 5. After Monitor/Setting Item 5 has been displayed, the display will switch to the top parameter in the Operation Level.

  • Page 238: Displaying Pv/Sv Status

    5 Advanced Operations 5-20 Displaying PV/SV Status 5-20-1 PV and SV Status Display Functions PV Status Display Function (Advanced Function Setting Level) The PV on the No. 1 display in the PV, PV/SP, PV/Manual MV, or PV/SP Manual MV Display and the control or alarm status specified for the PV status display function are alternately displayed in 0.5-s cycles.
  • Page 239 5 Advanced Operations Additional Information Priority of Flashing and Alternating Displays on No. 2 Display The priority for flashing and alternating displays is as follows: Alternating display with SV status display Alternating displays/hold display during program end output The following procedure sets the PV Status Display Function parameter to ALM1.

  • Page 240: Controlling Valves (Can Be Used With A Position-Proportional Model)

    5 Advanced Operations 5-21 Controlling Valves (Can Be Used with a Position-proportional Model) You can use position-proportional control to control a value with a control motor. With position-propor- tional control, you can use either close control or floating control. Precautions for Correct Use The following functions cannot be used with position-proportional control.
  • Page 241 5 Advanced Operations Compensating Valve Positions There are two ways to compensate valve positions: motor calibration and manual setting. Motor calibration was previously described. For calibration with manual settings, another digital controller is used to execute motor calibration and the automatically calculated travel time, valve completely closed position, valve completely open position, and potentiometer specification setting are set together in this Digital Controller.
  • Page 242 5 Advanced Operations Related Displays and Parameters Parameter name Display Set (monitor) values Default Level clfl FLOT: Floating control FLOT Close/Floating CLOS: Close control calb Motor Calibration ERR (Error occurred.) Travel Time 0 to 999 (s) Initial Setting vl-c Level Valve Completely Closed 0 to 9,999 Position...

  • Page 243: Logic Operations

    5 Advanced Operations 5-22 Logic Operations 5-22-1 The Logic Operation Function (CX-Thermo) • The logic operation calculates the Controller status (alarms, run/reset, auto/manual, etc.) and the external event input status as 1 or 0, and outputs the result to a work bit. The work bit status can be output to auxiliary or control outputs, and operating status can be switched according to the work bit status.
  • Page 244 5 Advanced Operations Making the Settings The following display will appear on the Logic Operation Editor Setting Window. Set each of the parameters. (1) Displaying the Library Import Dialog Box Logic operation samples for specific cases are set in the library in advance. Examples of settings for specific cases are loaded by selecting them from the library list and clicking the OK Button.
  • Page 245 5 Advanced Operations (3) Selecting the Operation Type From one to four operations are supported. If work bits are not to be used, set them to No operation (Always OFF) (the default). • No operation (Always OFF) • Operation 1 (A and B) or (C and D) When conditions A and B or conditions C...
  • Page 246 5 Advanced Operations (4) Selecting Input Assignments Select the input assignment for the work bit logic operation from the following settings. Parameter name Setting range 0. Always OFF Always ON ON for one cycle when power is turned Event input 1 (external input)* Event input 2 (external input)* Event input 3 (external input)* Event input 4 (external input)*...
  • Page 247 5 Advanced Operations Parameter name Setting range Work Bit 8 Input Assignment D Same as for work bit 1 input assignment A The event inputs that can be used depend on the Controller model. (5) Switching between Normally Open and Normally Closed for Inputs A to D Click the condition to switch between normally open and normally closed inputs A to D.
  • Page 248 5 Advanced Operations Parameter name Setting range Internal event 2 Same as for Event Input Data 1. Internal event 3 Same as for Event Input Data 1. Internal event 4 Same as for Event Input Data 1. Internal event 5 Same as for Event Input Data 1.
  • Page 249 5 Advanced Operations 1. Select Logic Operation Editor from the CX-Thermo tree, and click the Start Button. 2. The Logic Operation Editor will be displayed. Confirm that the screen for work bit 1 is displayed, and select Operation 3 from the Operation Type Field.
  • Page 250 5 Advanced Operations Operating Procedure This procedure outputs alarm 1 status to auxiliary output 1 during operation (RUN). A library object is used to make the setting. Work bit 1 Alarm 1 Run/Reset Always OFF Always OFF 1. Select Logic Operation Editor from the CX-Thermo tree, and click the Start Button.
  • Page 251 5 Advanced Operations 4. Closing the Logic Operation Editor Dialog Box Click the Close Button. This completes the procedure for setting parameters using the CX-Thermo. Transfer the settings to the Controller to set the Controller. Refer to CX-Thermo help for the procedure to transfer the settings.

  • Page 252: Using The Cx-Thermo To Set Programs

    5 Advanced Operations 5-23 Using the CX-Thermo to Set Programs 5-23-1 Introduction You can use the programming setting functions of the CX-Thermo to easily and visually set programs. Use CX-Thermo version 4.61 or higher. Refer to the following sections for the setting procedures with the keys on the Digital Controller and for information on the parameters.

  • Page 253: Using The Program Setting Functions

    5 Advanced Operations 5-23-2 Using the Program Setting Functions You start the Programmer Editor to set programs with the CX-Thermo. Use the following procedures to start and end the Programmer Editor. Starting the Programmer Editor There are the following two methods that you can use to start the Programmer Editor. Method 1 Select Programmer Editor from the CX-Thermo tree, and click the Start Button.

  • Page 254: Names And Functions Of Objects In The Programmer Editor

    5 Advanced Operations The Programmer Editor will be ended. 5-23-3 Names and Functions of Objects in the Programmer Editor Names of Objects in the Programmer Editor You can set the following items in the Programmer Editor. Program Settings Set programs on the Parameter Tab Pages. Copying Programs Use the program copy fields and button to copy programs.
  • Page 255 5 Advanced Operations Parameter Tab Pages This section describes the parameters that are displayed on each tab page. Basic Tab Page Use this tab page to set the parameters that are used by all programs. Parameter name Description Controller Setting Level Page This parameter sets the time unit for the Program Time Unit...
  • Page 256 5 Advanced Operations Program Tab Page Use this tab page to set the parameters that are used by all segments in one program. Parameter name Description Controller Setting Level Page This parameter specifies the number Number of Segments Used Program Setting Level 6-17 of segments in the program.
  • Page 257 5 Advanced Operations Pattern Tab Page Use this tab page to set each of the segments in a program. Parameter name Description Controller Setting Level Page This parameter sets the SP for the specified Segment Set Point Program Setting Level 6-18 segment number.

  • Page 258: Program Setting Procedures

    5 Advanced Operations 5-23-4 Program Setting Procedures This section provides example setting procedures for step time programming and rate of rise program- ming for the following program pattern. Segment 1 Segment 2 Segment 3 100.0°C Segment 0 60.0°C 20 min. 40 min.
  • Page 259 5 Advanced Operations On the Time Signal Tab Page, set the segments, ON times, and OFF times to the values given below. Program 0 time signal parameter Set value Time Signal 1 Set Segment Time Signal 1 ON Time 0 min. Time Signal 1 OFF Time 1 min.
  • Page 260 5 Advanced Operations Example Procedure for Rate of Rise Programming On the Basic Tab Page, set the Step Time/Ramp Rate Programming (Rate of Rise Programming) Box to Ramp Rate Programming. The default setting is Step Time. On the Program Tab Page, set the Program 0 Number of Segments Box to 4. Set the Segment Type (Segment Format), Segment Set Point, Segment Rate of Rise (Segment Slope), and Segment Time Boxes on the Pattern Tab Page to the values given below.
  • Page 261 5 Advanced Operations Program 0 time signal parameter Set value Time Signal 1 Set Segment Time Signal 1 ON Time 0 min. Time Signal 1 OFF Time 1 min. Time Signal 2 Set Segment Time Signal 2 ON Time 0 min. Time Signal 2 OFF Time 1 min.
  • Page 262 Parameters 6-1 Conventions Used in this Section ....... . 6-2 6-2 Protect Level .

  • Page 263: Conventions Used In This Section

    6 Parameters Conventions Used in this Section Meanings of Icons Used in this Section Describes the functions of the parameter. Function Describes the setting range and default of the parameter. Setting Used to indicate parameters used only for monitoring. Monitor Describes the parameter settings, such as those for Operation Commands, and procedures.

  • Page 264: Protect Level

    6 Parameters Protect Level Four levels of protection are provided on the E5@C-T, operation/adjustment protect, initial setting/com- munications protect, setting change protect, and PF key protect. These protect levels prevent unwanted operation of the keys on the front panel in varying degrees. Power ON Protect Level Page...

  • Page 265: Program Setting Level

    6 Parameters oapt Operation/Adjustment Protect Initial Setting/Communications icpt Protect These parameters specify the range of parameters to be protected. Operation/Adjustment Protect Set value Function Level 0 (default) Can be dis- Can be dis- Can be dis- Can be dis- Can be dis- Can be dis- played played...
  • Page 266 6 Parameters The Event Input Assignment 1 to 6 parameters wtpt Setting Change Protect must not be set to enable/disable setting changes. Changes to settings using key operations are restricted. Change Setting Protect This parameter is not displayed if the Event Input Assignment 1 to 6 parameters are set Function to enable/disable setting changes.

  • Page 267: Precautions For Correct Use

    Move to Protect Level (Protect Level): Page 6-3 Precautions for Correct Use Protection cannot be cleared or changed without the password. Be careful not to forget it. If you forget the password, contact your OMRON sales representative. 6 - 6 E5@C-T Digital Temperature Controllers User’s Manual (H185)

  • Page 268: Operation Level

    6 Parameters Operation Level Display this level to perform control operations on the E5@C-T. You can run and reset the program or you can monitor process values and set points. Power ON Operation PID Setting Program Adjustment Level Level Setting Level Level Press the Key for less than 1 s.
  • Page 269 The following table shows the contents of the No. 1, 2, and 3 displays, according to the set- ting of the PV/SP Display Screen Selection parameter. Function No. 3 display Set value No. 1 display No. 2 display (E5EC-T/E5AC-T only) Setting Nothing is displayed. Nothing is displayed. Nothing is displayed. Process value Set point Nothing is displayed.
  • Page 270 6 Parameters The Event Input Assignment 1 to 6 parameters Auto/Manual Switch must not be set to Auto/Manual and the control must be set to 2-PID control. • This parameter switches the Controller between Automatic and Manual Modes. • If the O Key is pressed for at least 3 seconds when the Auto/Manual Switch parameter is displayed, the Manual Mode will be entered and the manual control level will be displayed.
  • Page 271 6 Parameters Program No. • This parameter specifies the program number to use to start program operation. • This parameter can be used only when resetting and only when the Event Input Assignment 1 to 6 parameters are not set to switch the program number. Function Setting range Unit...
  • Page 272 6 Parameters stbm Remaining Standby Time Monitor Operation must be on standby. • This parameter monitors the remaining standby time. Function Monitor range Unit Standby time in hours and minutes: 0.00 to 99.59 Hours and minutes, Monitor Standby time in days and hours: 0.00 to 99.23 or days and hours* The unit is set in the Standby Time Unit parameter.
  • Page 273 6 Parameters Program Execution Repetitions rptm Monitor • This parameter monitors the number of times the program has been repeated. Function Monitor range Unit 0 to 9,999 Repetitions Monitor Related Sections 5-15 Program-related Functions (page 5-53) Related Parameters Program Repetitions (Program Setting Level): Page 6-22 HB and HS alarms must be supported.
  • Page 274 6 Parameters HB and HS alarms must be supported (two CTs). Heater Current 2 Value Monitor The HB ON/OFF parameter must be set to ON. This parameter measures the heater current from the CT input used for detecting heater burnout. This parameter measures and displays the heater current value.
  • Page 275 6 Parameters HB and HS alarms must be supported (two CTs). lcr2 Leakage Current 2 Monitor The HS Alarm Use parameter must be set to ON. This parameter measures the heater current from the CT input used for detecting SSR short-circuits. This parameter measures and displays the heater current value.
  • Page 276 6 Parameters The control system must be set to heating/cooling MV Monitor (Cooling) control. This parameter is used to monitor the manipulated variable for the cooling control output during opera- tion. • During heating/cooling control, the manipulated variable on the control output (cooling) is monitored.
  • Page 277 6 Parameters Program Setting Level The Program Setting Level is used to set the set points, times, rates of rise, and other parameters for each program. The program to which to move is selected in the first parameter in the Program Setting Level (Display Program Selection).
  • Page 278 6 Parameters d.prg Display Program Selection • This parameter specifies the number of the program to be set. Function Setting range Unit Default 0 to 7 Setting * Number of program currently used for control. Related Sections 4-7 Setting Programs (page 4-27) s-no Number of Segments Used •...
  • Page 279 6 Parameters The Display Segment Selection parameter must not be set to END. The Step Time/Rate of Rise styp Segment n Format (n = 0 to 31) Programming parameter must be set to Rate of Rise. • This parameter sets the segment type for the specified segment number to ramp, soak, or step.
  • Page 280 6 Parameters The Displayed Segment Selection parameter must not be set to END. The Step Time/Rate of Rise Segment n Slope (n = 0 to 31) Programming parameter must be set to Rate of Rise. The Segment Type parameter must be set to Ramp.
  • Page 281 6 Parameters PID Set No. Control must be set to 2-PID control. • This parameter sets the PID set number for the specified program number. • If this parameter is set to 0, the automatic PID set selection function will automatically select the PID set number to be used in control according to the PV, DV, and SP.
  • Page 282 6 Parameters al1h Alarm Upper Limit 1 al2h Alarm Upper Limit 2 al3h Alarm Upper Limit 3 al4h Alarm Upper Limit 4 Alarms 1 to 4 must be assigned. The alarm 1 to 4 type must be set to 1, 4, or 5. al1l Alarm Lower Limit 1 al2l...
  • Page 283 6 Parameters Program Repetitions link Program Link Destination • The Program Repetitions parameter is used to repeatedly execute the same program for the specified number of repetitions. The actual number of executions will be the set value of this parameter plus one. Function •...
  • Page 284 6 Parameters Time Signal 1 ON Time Outputs must be assigned to time signals 1 and 2. Time Signal 2 ON Time • These parameters set the ON times for the time signals. Function Setting range Unit Default 0.00 to 99.59 Hours and minutes, or minutes and seconds * 0.00 Setting...

  • Page 285: Adjustment Level

    6 Parameters Adjustment Level This level is for executing AT (auto-tuning) and other operations, and for set control parameters. This level provides the basic Controller parameters for PID control (proportional band, integral time, derivative time) and heating/cooling control. To move to the Adjustment Level from the Operation Power ON Level, press the O Key twice.
  • Page 286 6 Parameters Adjustment Level Page Page Page Page l.adj Adjustment PV Input Shift w3on Work Bit 3 ON Hysteresis 6-26 6-33 6-43 6-38 Delay (Heating) Level Display 1234 PV Slope 6-33 inrt Hysteresis w3of chys 6-43 Work Bit 3 OFF 6-38 Coefficient (Cooling)
  • Page 287 6 Parameters l.adj Adjustment Level Display This parameter is displayed after moving to the Adjustment Level. The four numeric digits to identify the product code are displayed in the No. 2 display. When a logic operation is set, a period "." will be displayed on the No. 2. display. •...
  • Page 288 6 Parameters Control must be set to 2-PID control and the Reset Operation parameter must be set to fixed SP AT Execute/Cancel operation, or the Reset Operation parameter must be set to stop operation and the Controller must not be on standby or performing a reset. This parameter executes auto-tuning (AT).
  • Page 289 6 Parameters Communications must be supported. The Event Input Assignment 1 to 6 parameters cmwt Communications Writing must not be set to enable/disable communications writing. • This parameter enables/disables writing of parameters to the E5@C-T from the host (personal computer) using communications. •...
  • Page 290 6 Parameters Fixed SP • This parameter sets the SP used in Fixed SP Mode. Function Setting range Unit Default SP Lower Limit to SP Upper Limit Setting Related Parameters SP Mode (Adjustment Level): Page 6-28 HB and HS alarms must be supported. Heater Current 1 Value Monitor The HB ON/OFF parameter must be set to ON.
  • Page 291 6 Parameters HB and HS alarms must be supported. Heater Burnout Detection 1 The HB ON/OFF parameter must be set to ON. This parameter sets the current for the heater burnout alarm to be output. • The heater burnout alarm is output when the heater current value falls below the setting of this parameter.
  • Page 292 6 Parameters HB and HS alarms must be supported (two CTs). Heater Burnout Detection 2 The HB ON/OFF parameter must be set to ON. This parameter sets the current for the heater burnout alarm to be output. • The heater burnout alarm is output when the heater current value falls below the setting of this parameter.
  • Page 293 6 Parameters HB and HS alarms must be supported. HS Alarm 1 The HS Alarm Use parameter must be set to ON. This parameter sets the current for the HS alarm to be output. • An HS alarm is output when the leakage current value exceeds the setting of this parameter.
  • Page 294 6 Parameters HB and HS alarms must be supported (two CTs). HS Alarm 2 The HS Alarm Use parameter must be set to ON. This parameter sets the current for the HS alarm to be output. • An HS alarm is output when the leakage current value exceeds the setting of this parameter.
  • Page 295 6 Parameters wt-b Wait Band • This parameter sets the band for the wait operation as a deviation from the SP. • The wait operation is not performed if the wait band is set to 0. Function Setting range Unit Default °C or °F Temperature input: OFF, or 0.1 to 999.9...
  • Page 296 6 Parameters psps Program SP Shift Value • This parameter performs a fixed-rate compensation (1-point compensation) for the program SP (PSP). • This parameter is masked by default and not displayed. Function Setting range Unit Default −1999 to 9999 Setting Related Sections 5-15 Program-related Functions (page 5-53) Related Parameters...
  • Page 297 6 Parameters Proportional Band Integral Time The control must be set to 2-PID control. Derivative Time These parameters set the PID constants. If auto-tuning is executed, these parameters are set automat- ically. Refers to control in which the MV is proportional to the deviation (control error). action: Setting Refers to a control action that is proportional to the time integral of the deviation.
  • Page 298 6 Parameters Proportional Band (Cooling) The control must be set to heating/cooling control Integral Time (Cooling) and 2-PID control. Derivative Time (Cooling) These parameters set the PID constants for cooling control. These parameters are automatically set according to the Heating/Cooling Tuning Method parameter when auto-tuning is executed.
  • Page 299 6 Parameters The control must be standard control and 2-PID of-r Manual Reset Value control. The Integral Time parameter must be set to 0. • This parameter sets the required manipulated variable to remove offset during stabilization of P or PD control. Function Setting range Unit...
  • Page 300 6 Parameters The control must be set to 2-PID control and the mv-r MV at Reset Reset Operation parameter must be set to stop control. • This parameter sets the MV when switching between run status and reset status during Run/Reset control.
  • Page 301 6 Parameters ol-h MV Upper Limit The control must be set to 2-PID control. A Position-proportional Model must be set to close control. ol-l MV Lower Limit • The MV Upper Limit and MV Lower Limit parameters set the upper and lower limits of the manipulated variable.
  • Page 302 6 Parameters MV Change Rate Limit 2-PID control must be used. • The MV change rate limit sets the maximum allowable width of change in the MV per second. (For Position-proportional Models, the maximum valve opening per second is set.) If the change in the MV exceeds this setting, the MV will be changed by the MV Function change rate limit until the calculated value is reached.
  • Page 303 6 Parameters oc-h Open/Close Hysteresis A Position-proportional Model must be used. • The Open/Close Hysteresis parameter is used to shift the ON and OFF points for the open output and close output to prevent output chattering. Function Setting range Unit Default 0.1 to 20.0 Setting...
  • Page 304 6 Parameters w1 to 8on Work Bit 1 to 8 ON Delay The work bit operation type must not be set to OFF. w1 to 8of Work Bit 1 to 8 OFF Delay • ON Delay When the results of a work bit logic operation is ON, the work bit is turned ON after the time specified in the parameter elapses.

  • Page 305: Pid Setting Level

    6 Parameters PID Setting Level The PID setting level is used to make settings such as PID values for each PID set and MV limit values. Move to a particular PID set from the Display PID Set Selection parameter, which is displayed first in the PID setting level.
  • Page 306 6 Parameters d.pid Display PID Selection This parameter is used to select the PID set for making the display settings. • This parameter selects the PID set for which the display settings are to be made. • You can use up to eight sets of the following values by registering them for PID set num- bers 1 to 8: PID constants, MV upper/lower limits, dead bands, manual reset values, auto- Function matic selection range upper limits, and LBA detection times.
  • Page 307 6 Parameters PID * Proportional Band 2-PID control must be used. PID * Integral Time PID * Derivative Time (*: 1 to 8) These parameters set the PID constants for each PID set. If auto-tuning is executed, these parameters are set automatically. For the P action, the MV is proportional to the derivative.
  • Page 308 6 Parameters *.c-p PID * Proportional Band (Cooling) The control must be set to heating/cooling control *.c-i PID * Integral Time (Cooling) and 2-PID control. PID * Derivative Time (Cooling) *.c-d (*: 1 to 8) These parameters set the PID constants for each PID set number. If auto-tuning is executed, these parameters are set automatically.
  • Page 309 6 Parameters The control method must be set to standard control PID * Manual Reset Value *.ofr and 2-PID control and the integral time must be set (*: 1 to 8) to 0. • These parameters set the required manipulated variable to remove the offset during settling in P or PD control for each PID set number.
  • Page 310 6 Parameters PID * Automatic Selection Range *.aut 2-PID control must be used. Upper Limit (*: 1 to 8) These parameters set the upper limit for each PID set when PID sets are selected automatically. • These parameters are used to set the automatic selection range upper limits for PID sets 1 to 8.

  • Page 311: Monitor/Setting Item Level

    6 Parameters Monitor/Setting Item Level Monitor/setting items can be displayed by means of the PF key when the PF Setting parameter (Advanced Function Setting Level) is set to PFDP: Monitor/Setting Item. Power ON Operation Program S Key Setting Level Level Press the O Key Monitor/Setting for less than 1 s.
  • Page 312 6 Parameters The PF Setting parameter must be set to PFDP, and pfd1 to 5 Monitor/Setting Item Display 1 to 5 the Monitor/Setting Item 1 to 5 parameters must not be set to OFF. • When the PF Key is set to display monitor/setting items, pressing the PF Key will display in order the contents of the Monitor/Setting Item 1 to 5 parameters.

  • Page 313: Manual Control Level

    6 Parameters Manual Control Level If you change to Manual Mode, the Manual MV parameter will be displayed and the displayed value will be output as the MV. Power ON Operation Program Level Setting Level Press the for less than 1 s. PID Setting Adjustment Level...
  • Page 314 6 Parameters PV/MV (Manual MV) • The manual control level display appears as shown below. Function 50.0 PV/Manual MV Monitor range Unit Process value Temperature: According to indication range for each sensor. Analog: Scaling lower limit −5% FS to Scaling upper limit +5% FS (Refer to A-7 Sensor Input Setting Range, Indication Range, Con- trol Range.) Set point...

  • Page 315: Initial Setting Level

    6 Parameters Initial Setting Level This level is used to set up the basic Digital Controller specifications. In this level, you can set the Input Type parameter to set the sensor input to be connected, limit the setting range of set points, set the alarm modes, and perform other operations.
  • Page 316 6 Parameters Initial Setting Level Page Page Page Standard or Input Type tr-h Transfer Output in-t s-hc 6-56 6-73 Heating/Cooling 6-64 100.0 Upper Limit stnd tr-l Transfer Output Scaling Upper in-h Control Period 6-57 6-73 6-65 Limit Lower Limit (Heating) Event Input Scaling Lower Control Period...
  • Page 317 6 Parameters in-t Input Type • The Input Type parameter is used to set the input type. • When this parameter is changed, the set point limiter is changed to the defaults. If the limiter must be specified, set the SP Upper Limit and SP Lower Limit parameters (Initial Function Setting Level) again.
  • Page 318 6 Parameters in-h Scaling Upper Limit in-l Scaling Lower limit The input type must be set for an analog input. Decimal Point • The Decimal Point parameter specifies the decimal point position of parameters (set point, etc.) whose unit is EU. Function •...
  • Page 319 6 Parameters sl-h SP Upper Limit sl-l SP Lower Limit • These parameters set the upper and lower limits of the set points. A set point can be set within the range defined by the upper and lower limit set values in the SP Upper Limit and SP Lower Limit parameters.
  • Page 320 6 Parameters Step Time/Rate of Rise t-pr Programming This parameter specifies the segment setting method when a program is set. There are two methods: Step Time, in which the arrival time and arrival SP are set, and Rate of Rise Programming, in which the segment type is set (to ramp, soak, or step) and the Function values are set.
  • Page 321 6 Parameters rtsm Reset Operation This parameter sets the control operation to perform when a reset has been performed. • Stopping control: Control is stopped. If an MV is set for the MV at reset, it is output. • Fixed SP operation: Control is executed for a fixed SP (FSP). The mode will always be Function Fixed SP Mode.
  • Page 322 6 Parameters eset Operation End Operation This parameter sets the operation to perform when the program has been completed. • Reset: Operation ends Function • Continue: Operation is continued using the SP of the last segment. The final segment number is held and the elapsed program time is held. The Hold and Advance parameters cannot be used.
  • Page 323 6 Parameters The Step Time/Rate of Rise Programming parameter must be set to Step Time, or the Step pvst PV Start Time/Rate of Rise Programming parameter must be set to Rate of Rise and the Reset Operation parameter must be set to Fixed SP Operation. •...
  • Page 324 6 Parameters Control must be set to 2-PID control and the PID tspu All PID AT Upper Limit SP Set Automatic Selection Data parameter must not be set to DV (deviation). This parameter sets the last SP for auto-tuning when auto-tuning all PID sets. •...
  • Page 325 2 terminal (SUB2) is assigned as the control output for cooling. Function • If heating/cooling control is selected for the E5EC-T/E5AC-T when there is only one control output, the auxiliary output 4 terminal (SUB4) is assigned as the control output for cooling.
  • Page 326 6 Parameters The cooling control output and heating control output must be assigned to relay or voltage Control Period (Heating) outputs (for driving SSR). c-cp Control Period (Cooling) The control must be set to 2-PID control. For the Control Period (Cooling) parameter, the control must be set to heating/cooling control.
  • Page 327 6 Parameters oreV Direct/Reverse Operation • "Direct operation" refers to control where the manipulated variable is increased when the process value increases. Alternatively, "reverse operation" refers to control where the manipulated variable is increased when the process value decreases. Function Setting range Default or-r: Reverse operation, or-d: Direct operation...
  • Page 328 6 Parameters Alarm output operation Alarm type Description of function When alarm value When alarm value value X is positive X is negative Upper- and Set the upward deviation in the set point for the alarm lower-limit range upper limit (H) and the lower deviation in the set point for the alarm lower limit (L).
  • Page 329 6 Parameters Alarm output operation Alarm type Description of function When alarm value When alarm value value X is positive X is negative MV absolute-value Standard Control Standard Control This alarm type turns ON the alarm when the lower-limit alarm manipulated variable (MV) is lower than the alarm Heating/Cooling...
  • Page 330 6 Parameters Related Parameters Alarm Value 1 to 4 (Operation Level): Page 6-20 Alarm Value Upper Limit 1 to 4 and Alarm Value Lower Limit 1 to 4 (Operation Level): Page 6-21 Alarm 1 to 4 Hysteresis (Initial Setting Level): Page 6-70 Standby Sequence Reset (Advanced Function Setting Level): Page 6-83 Auxiliary Output 1 to 4 Open in Alarm (Advanced Function Setting Level): Page 6-84 Alarm 1 to 4 Latch (Advanced Function Setting Level): Page 6-89...
  • Page 331 6 Parameters Alarm 1 must be assigned. alh1 Alarm 1 Hysteresis The alarm 1 type must not be 0, 12, or 13. Alarm 2 must be assigned. alh2 Alarm 2 Hysteresis The alarm 2 type must not be 0, 12, or 13. Alarm 3 must be assigned.
  • Page 332 6 Parameters o1st Control Output 1 Signal Control output 1 must be a linear current output. o2st Control Output 2 Signal Control output 2 must be a linear current output. These parameters set the output signal for linear current outputs. •...
  • Page 333 6 Parameters tr-t Transfer Output Type There must be a transfer output. • This parameter sets the transfer output type. Function Transfer output type Default Setting sp-m Present SP MV (heating) c-mV MV (cooling) Valve opening This function can be set for a Position-proportional Model, but the setting will be disabled. This function can be set for standard control or for a Position-proportional Model, but the setting will be disabled.
  • Page 334 6 Parameters tr-h Transfer Output Upper Limit There must be a transfer output. The transfer output type must not be set to OFF. tr-l Transfer Output Lower Limit • This parameter sets the upper and lower limit values of transfer outputs. Function Default Transfer...
  • Page 335 6 Parameters eV-1 Event Input Assignment 1 There must be event inputs. eV-2 Event Input Assignment 2 eV-3 Event Input Assignment 3 eV-4 Event Input Assignment 4 eV-5 Event Input Assignment 5 eV-6 Event Input Assignment 6 • The following functions can be assigned to event inputs 1 to 6. •...
  • Page 336 6 Parameters Setting Function none None Setting rr-1 Run (OFF)/Reset (ON) rr-2 Run (ON)/ Reset (OFF) manu Auto/Manual Reset hld1 Hold/Clear Hold hld2 Hold Advance prg0 Program Number Switch 0 prg1 Program Number Switch 1 prg2 Program Number Switch 2 Direct/Reverse Operation Program SP Mode/Fixed SP Mode at-2...
  • Page 337 6 Parameters calb Motor Calibration A Position-proportional Model must be used. The Motor Calibration parameter is used to calibrate the valve position and automatically set the travel time from completely open to completely closed. You can then check the valve opening with the Valve Opening Monitor parameter.
  • Page 338 6 Parameters • This parameter sets the count that indicates the position where the valve is completely closed. • This parameter is set automatically when motor calibration is executed. There is normally Function no need to change it manually. • To use the results of automatic motor calibration calculations with another Digital Controller, set the following parameters as a set: Travel Time, Valve Completely Closed Position, Valve Completely Open Position, and Potentiometer Specification Setting.
  • Page 339 6 Parameters Potentiometer Specification A Position-proportional Model must be used. Setting • This parameter is used to set a number that indicates a potentiometer specification, the resistance range. • This parameter is set automatically according to the potentiometer specification when Function motor calibration is executed.
  • Page 340 6 Parameters Move to Advanced Function The Initial Setting/Communications Protect amoV Setting Level parameter must be set to 0. • Set the Move to Advanced Function Setting Level parameter set value to "−169." • Move to the advanced function setting level either by pressing M Key or O Key or by waiting or two seconds to elapse.

  • Page 341: Advanced Function Setting Level

    6 Parameters 6-10 Advanced Function Setting Level The Advanced Function Setting Level is used for Power ON optimizing Controller performance. To move to this level, input the password ("−169") from the Initial Set- Operation Program ting Level. Level Setting Level Press the To be able to enter the password, the Initial Set- O Key for less than 1 s.
  • Page 342 6 Parameters Advanced Function Setting Level Page Page Page Page LCT Cooling Parameter init a1lt lcmt 6-82 6-89 LBA Detection 6-95 Alarm 1 Latch 6-104 Output Min. Initialization Time ON Time PF Setting pend Program End a2lt lbal LBA Level 6-89 6-96 6-82...
  • Page 343 6 Parameters init Parameter Initialization • This parameter returns all parameter settings to their defaults. • After the initialization, the set value automatically turns OFF. Function Setting range Default off: Initialization is not executed. Setting fact: Initializes to the factory settings described in the manual. pend Program End ON Time •...
  • Page 344 6 Parameters rest Standby Sequence Reset Alarm 1 to 4 type must be 5, 6, 7, 10, or 11. • This parameter selects the conditions for enabling reset after the standby sequence of the alarm has been canceled. • Output is turned OFF when switching to the Initial Setting Level, Communications Setting Function Level, Advanced Function Setting Level, or Calibration Level.
  • Page 345 6 Parameters sb1n Auxiliary Output 1 Open in Alarm Auxiliary output 1 must be assigned. sb2n Auxiliary Output 2 Open in Alarm Auxiliary output 2 must be assigned. sb3n Auxiliary Output 3 Open in Alarm Auxiliary output 3 must be assigned. sb4n Auxiliary Output 4 Open in Alarm Auxiliary output 4 must be assigned.
  • Page 346 6 Parameters HB and HS alarms must be supported. Heater Burnout Latch The HB ON/OFF parameter must be set to ON. • When this parameter is set to ON, the heater burnout alarm is held until either of the following conditions is satisfied. a Heater burnout detection is set to 0.0 A.
  • Page 347 6 Parameters alfa α 2-PID control must be set. • Normally, use the default for this parameter. • This parameter sets the 2-PID control a constant. Function Setting range Default 0.00 to 1.00 0.65 Setting Related Parameters PID ON/OFF (Initial Setting Level): Page 6-63 tidu Integral/Derivative Time Unit Control must be set to 2-PID control.
  • Page 348 6 Parameters at-g AT Calculated Gain Control must be set to 2-PID control. at-h AT Hysteresis Control must be set to 2-PID control or close lcma Limit Cycle MV Amplitude position-proportional control. • Normally use the default values for these parameters. •...
  • Page 349 6 Parameters Moving Average Count • This parameter sets the number of inputs to include in the moving average. The data after moving average processing is illustrated in the following figure. Function Input data Operation result Time • Use a moving average to suppress rapid changes in the input. Setting range Unit Default...
  • Page 350 6 Parameters Alarm 1 must be assigned, and the alarm 1 type a1lt Alarm 1 Latch must not be 0. Alarm 2 must be assigned, and the alarm 2 type a2lt Alarm 2 Latch must not be 0 or 12. Alarm 3 must be assigned, and the alarm 3 type a3lt Alarm 3 Latch...
  • Page 351 6 Parameters prlt Move to Protect Level Time • This parameter sets the key pressing time required to move to the Protect Level from the Operation Level, Program Setting Level, Adjustment Level, PID Setting Level, or Monitor/Setting Item Level. Function Setting range Unit Default...
  • Page 352 6 Parameters Alarm 1 must be assigned, and the alarm 1 type a1on Alarm 1 ON Delay must not be 0, 12, or 13. Alarm 2 must be assigned, and the alarm 2 type a2on Alarm 2 ON Delay must not be 0, 12, or 13. Alarm 3 must be assigned, and the alarm 3 type a3on Alarm 3 ON Delay...
  • Page 353 6 Parameters Alarm 1 must be assigned, and the alarm 1 type a1of Alarm 1 OFF Delay must not be 0, 12, or 13. Alarm 2 must be assigned, and the alarm 2 type a2of Alarm 2 OFF Delay must not be 0, 12, or 13. Alarm 3 must be assigned, and the alarm 3 type a3of Alarm 3 OFF Delay...
  • Page 354 6 Parameters Control must be set to 2-PID control. A Position-proportional Model set to Close Control mani Manual MV Initial Value with the Direct Setting of Position-proportional MV parameter set to ON must be used. This parameter sets the initial value of the manual MV to use after control moves from Auto- matic Mode to Manual Mode.
  • Page 355 6 Parameters HS Alarm Use HB and HS alarms must be supported. • Set this parameter to use HS alarms. Function Setting range Default on: Enabled, off: Disabled Setting HB and HS alarms must be supported. HS Alarm Latch The HS Alarm Use parameter must be set to ON. •...
  • Page 356 6 Parameters HB and HS alarms must be supported. HS Alarm Hysteresis The HS Alarm Use parameter must be set to ON. The HS Alarm Latch parameter must be set to OFF. • This parameter sets the hysteresis for HS alarms. Function Setting range Unit...
  • Page 357 6 Parameters A Standard Model must be used. Alarm 1 must be assigned. lbal LBA Level The alarm type must be set to 12 (LBA). The LBA detection time must not be 0. • This parameter sets the LBA level. •...
  • Page 358 6 Parameters out1 Control Output 1 Assignment A Standard Model must be used. A Standard Model with two control outputs must be out2 Control Output 2 Assignment used. • These parameters set the function to assign to control outputs 1 and 2. Function Setting range Default...
  • Page 359 6 Parameters sub1 Auxiliary Output 1 Assignment There must be an auxiliary output 1. sub2 Auxiliary Output 2 Assignment There must be an auxiliary output 2. sub3 Auxiliary Output 3 Assignment There must be an auxiliary output 3. sub4 Auxiliary Output 4 Assignment There must be an auxiliary output 4.
  • Page 360 6 Parameters alma Integrated Alarm Assignment The integrated alarm must be assigned. You can use the integrated alarm to output an OR of alarm 1, alarm 2, alarm 3, alarm 4, the HB alarm, the HS alarm, the input alarm. Set this parameter to the sum of the codes of the status for which to output an OR.
  • Page 361 6 Parameters sptr SP Tracking • This parameter sets the operation to perform when moving from Program SP Mode to Fixed SP Mode. • When this parameter is turned ON, operation continues using the program SP as the Function fixed SP. •...
  • Page 362 6 Parameters p-db PV Dead Band A Position-proportional Model must be used. When the PV enters the PV dead band, any unnecessary output is stopped to prevent the valve from deteriorating. Function Unnecessary output is stopped in this range. PV Dead Band Setting range Unit Default...
  • Page 363 6 Parameters Direct Setting of Position Close control must be used (Position-proportional pmvd Proportional MV Model). • The Direct Setting of Position Proportional MV parameter can be set to ON to enable specifying the valve open with the MV at Stop, MV at PV Error, and Manual MV parameters.
  • Page 364 6 Parameters The control must be set to heating/cooling control hctm Heating/Cooling Tuning Method and 2-PID control. This parameter sets the tuning method that is suitable for the cooling control characteristics. Function Setting range Default 0: Same as heating control Setting 1: Linear 2: Air cooling...
  • Page 365 6 Parameters A Standard Model must be used. The control must be set to 2-PID control. ompw Minimum Output ON/OFF Band The heating and cooling control outputs must be assigned. This parameter sets the minimum ON/OFF width of the outputs that are assigned for the heating and cooling control outputs.
  • Page 366 6 Parameters PF Setting • This parameter sets the function of the PF Key. Function • The default is SHFT (Digit Shift). Set value Setting Function Setting OFF: off Disabled Does not operate as a function key. RUN: run Specifies RUN status. RST: rst Reset Specifies Reset status.*1...
  • Page 367 6 Parameters pfd1 PF Monitor/Setting Item Display 1 pfd2 PF Monitor/Setting Item Display 2 The PF Setting parameter must be set to pfd3 PF Monitor/Setting Item Display 3 PFDP. pfd4 PF Monitor/Setting Item Display 4 pfd5 PF Monitor/Setting Item Display 5 •...
  • Page 368 These parameters set the items to display on the No. 1 display, No. 2 display, and No. 3 dis- play. Function No. 3 display Set value No. 1 display No. 2 display (E5EC-T/E5AC-T only) Setting Nothing is displayed. Nothing is displayed. Nothing is displayed. Process value Set point Nothing is displayed.
  • Page 369 6 Parameters pvst PV Status Display Function • This parameter sets a control or alarm status that is displayed alternately in 0.5-s cycles on the No. 1 display when the PV is set to be displayed in the No. 1 display. •...
  • Page 370 6 Parameters svst SV Status Display Function • This parameter sets a control or alarm status that is displayed alternately in 0.5-s cycles on the No. 2 display when the PV is set to be displayed in the No. 1 display. •...
  • Page 371 6 Parameters burn Burnout Method • This parameter specifies whether the input value when an input error occurs is to be treated as the upper limit or the lower limit. • The setting of this parameter applies to alarms, a PV transfer output, or automatic PID set Function selection with the PV/DV.

  • Page 372: Communications Setting Level

    6 Parameters 6-11 Communications Setting Level psel Protocol Setting u-no Communications Unit No. Communications Baud Rate Communications Data Length CompoWay/F must be selected as the protocol. sbit Communications Stop Bits CompoWay/F must be selected as the protocol. CompoWay/F or Modbus must be selected as the prty Communications Parity protocol.
  • Page 373 6 Parameters • Each parameter is enabled when the power is reset. • Match the communications specifications of the E5@C-T and the host computer. If multiple devices are connected, ensure that the communications specifications for all Function devices in the system (except the Communications unit number) are the same. Item Display Set values...

  • Page 374: User Calibration

    User Calibration 7-1 User Calibration ..........7-2 7-2 Parameter Structure .

  • Page 375: User Calibration

    If, however, it must be calibrated by the user, use the parameters for calibrating temperature input and analog input. OMRON, however, cannot ensure the results of calibration by the user. Also, calibration data is overwritten with the latest calibration results. The default calibration settings cannot be restored after user calibration.

  • Page 376: Parameter Structure

    7 User Calibration Parameter Structure • To execute user calibration, enter the password "1201" at the Move to Calibration Level parameter in the Advanced Function Setting Level. The mode will be changed to the calibration mode, and adj will be displayed. •...

  • Page 377: Thermocouple Calibration

    7 User Calibration Thermocouple Calibration • Calibrate according to the type of thermocouple: thermocouple group 1 (input types 5, 7, 11, 12, 15, 19, and 20) and thermocouple group 2 (input types 6, 8, 9, 10, 13, 14, 16, 17, 18, 21, 22, 23, and 24). •...
  • Page 378 7 User Calibration In this example, calibration is shown for a Controller with thermocouple/infrared temperature sensor set as the input type. 1. Connect the power supply. 2. Connect a standard DC current/voltage source (STV), precision digital multimeter (DMM), and contact junction compensator (e.g., a zero controller as in the figure) to the thermocouple input terminals, as shown in the figure below.
  • Page 379 7 User Calibration 7. When the M Key is pressed, the status changes as shown to the left. bia5 35b8 8. Change the wiring as follows: Open in non-connected state − Short-circuit Zero controller OUTPUT INPUT Compensating conductor of currently selected thermocouple.

  • Page 380: Resistance Thermometer Calibration

    7 User Calibration Resistance Thermometer Calibration In this example, calibration is shown for Controller with a resistance thermometer set as the input type. Use connecting wires of the same thickness 1. Connect the power supply. 2. Connect a precision resistance box (called a "6-dial variable resistor" in this manual) to the resistance thermometer input terminals, as shown in the following diagram.
  • Page 381 7 User Calibration 7. When the M Key is pressed, the status changes as shown to the left. The data to be temporarily registered is not displayed if it is not complete. Press the U Key. The No. 2 display changes to yes. Release the key and wait two seconds or press the M Key.

  • Page 382: Calibrating Analog Input

    7 User Calibration Calibrating Analog Input Calibrating a Current Input In this example, calibration is shown for a Controller with an analog input, with a current input set as the input type. 1. Connect the power supply. 2. Connect an STV and DMM to the current input terminals, as shown in the following diagram.

  • Page 383: Calibrating A Voltage Input

    7 User Calibration Calibrating a Voltage Input In this example, calibration is shown for a Controller with an analog input, with a voltage input set as the input type. 1. Connect the power supply. 2. Connect an STV and DMM to the voltage input terminals, as shown in the following diagram.

  • Page 384: Calibrating The Transfer Output

    Controllers that have a transfer output. Use the following procedure to calibrate the transfer output for 4 to 20 mA. 1. Connect a DMM to the transfer output terminals. E5CC-T E5EC-T/E5AC-T Input power supply Input power supply − −...
  • Page 385 7 User Calibration Use the following procedure to calibrate the transfer output for 1 to 5 V. 1. Connect a DMM to the transfer output terminals. E5CC-T E5EC-T/E5AC-T Input power supply Input power supply − − 2. Press the M Key to display the parameter for the transfer output.

  • Page 386: Checking Indication Accuracy

    7 User Calibration Checking Indication Accuracy • After calibrating the input, be sure to check the indication accuracy to make sure that the calibration has been executed correctly. • Operate the E5@C-T in the process value/set point monitor mode. • Check the indication accuracy at the following three values: upper limit, lower limit, and mid-point. •...
  • Page 387 7 User Calibration Resistance Thermometer • Preparations The diagram below shows the required device connections. E5CC-T Input power supply 6-dial variable resistor E5EC-T/AC-T Input power supply 6-dial variable resistor • Operation Set the 6-dial variable resistor to the resistance that is equivalent to the test value. 7 - 14 E5@C-T Digital Temperature Controllers User’s Manual (H185)
  • Page 388 7 User Calibration Analog Input • Preparations The diagram below shows the required device connections. (The connection terminals depend on the model and input type.) Current Input E5CC-T Input power supply − E5EC-T/AC-T Input power supply − Voltage Input E5CC-T Input power supply −...
  • Page 389 7 User Calibration 7 - 16 E5@C-T Digital Temperature Controllers User’s Manual (H185)

  • Page 390: Appendices

    Appendices A-1 Specifications ..........A-2 A-1-1 Ratings .

  • Page 391: Specifications

    E5CC-T: SPST-NO, 250 VAC, 3 A (resistive load), Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference value) Relay outputs E5EC-T/E5AC-T: SPST-NO, 250 VAC, 5 A (resistive load), Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference value) E5CC-T: Output voltage: 12 VDC ±20% (PNP), Maximum load current: 21 mA,...
  • Page 392 Character heights: PV: 15.2 mm, SV: 7.1 mm Character heights: E5EC-T: PV: 18.0 mm, SV: 11.0 mm, MV: 7.8 mm E5AC-T: PV: 25.0 mm, SV: 15.0 mm, MV: 9.5 mm E5EC-T/E5AC-T Three display levels. Contents: PV, SP, program No. and segment No., remaining...

  • Page 393: A-1-2 Characteristics

    Controller: Approx. 210 g, Adapters: Approx. 4 g × 2 Weight E5EC-T Terminal Cover: Approx. 1 g each Controller: Approx. 250 g, Adapters: Approx. 4 g × 2 E5AC-T Terminal Cover: Approx. 1 g each Degree of protection Front panel: IP66, rear case: IP20, terminals: IP00 Memory protection...

  • Page 394: A-1-3 Program Controls

    Top panel: An E58-CIFQ2 USB-Serial Conversion Cable is used to connect to a USB port on the computer. Setup Tool ports Front panel (E5EC-T/E5AC-T): An E58-CIFQ2 USB-Serial Conversion Cable and E58-CIFQ2-E Conversion Cable are used together to connect a USB port on the computer.

  • Page 395: A-1-4 Waterproof Packing

    A Appendices A-1-4 Waterproof Packing If the Waterproof Packing is lost or damage, order one of the following models. Y92S-P8 (for DIN 48 × 48) Y92S-P9 (for DIN 48 × 96) Y92S-P10 (for DIN 96 × 96) A - 6 E5@C-T Digital Temperature Controllers User’s Manual (H185)

  • Page 396: A-1-5 Setup Tool Port Cover For Front Panel

    Setup Tool Port Cover for Front Panel A Y92F-P7 Setup Tool Port Cover for the front panel is included with the E5EC-T/E5AC-T. Order this Port Cover separately if the Port Cover on the front-panel Setup Tool port is lost or damaged. The Waterproof Packing must be periodically replaced because it may deteriorate, shrink, or harden depending on the operating environment.

  • Page 397: Current Transformer (Ct

    A Appendices A-2 Current Transformer (CT) A-2-1 Specifications Item Specifications Model number E54-CT1 E54-CT3 Max. continuous current 50 A 120 A Dielectric strength 1,000 VAC (for 1 min) Vibration resistance 50 Hz, 98 m/s Weight Approx. 11.5 g Approx. 50 g Accessories None Armature (2), Plug (2)

  • Page 398: Usb-Serial Conversion Cable And Conversion Cable

    A USB-Serial Conversion Cable is used to connect the E5@C-T to a computer. The E58-CIFQ2-E Con- version Cable is also required to connect to the Setup Tool port on the front panel of the E5EC-T or E5AC-T. The following table lists the cables and ports that are used. Connection port...

  • Page 399: A-3-2 E58-Cifq2-E Conversion Cable

    Not receiving data from the USB-Serial Conversion Cable A-3-2 E58-CIFQ2-E Conversion Cable Specifications Item Specification Applicable models E5EC/E5AC Series and E5EC-T/E5AC-T Series Connector Digital Controller: 4-pin plug specifications E58-CIFQ2: Small special connector Ambient temperature 0 to 55°C (with no condensation or icing)

  • Page 400: Error Displays

    A Appendices A-4 Error Displays When an error occurs, the error contents are shown on the No. 1 or the No. 2 display. This section describes how to check error codes on the display, and the actions to be taken to remedy the problems.
  • Page 401 A Appendices [[[[ Display Range Exceeded ]]]] Meaning Though this is not an error, it is displayed if the process value exceeds the display range when the control range is larger than the display range. The display ranges are shown below (with decimal points omitted). •...
  • Page 402 A Appendices e111 Memory Error Meaning Internal memory operation is in error. Action First, turn the power OFF then back ON again. If the display remains the same, the Controller must be repaired. If the display is restored, then the probable cause is electrical noise affecting the control system.
  • Page 403 A Appendices ---- Potentiometer Input Error (Position-proportional Models Only) Meaning “----” will be displayed for the Valve Opening Monitor parameter if any of the following error occurs. • Motor calibration has not been performed. • The wiring of the potentiometer is incorrect or broken. •...

  • Page 404: Troubleshooting

    A Appendices A-5 Troubleshooting Checking Problems If the Digital Controller is not operating normally, check the following points before requesting repairs. If the problem persists, contact your OMRON representative for details on returning the product. Timing Status Meaning Countermeasures Page...
  • Page 405 A Appendices Timing Status Meaning Countermeasures Page During Output will not turn ON The Digital Controller is Set the Run/Reset parameter to Run. If the reset 5-12 operation set to reset status. operation is set to stop control, control will stop when the (continued) (default: RST) RST indicator lights.
  • Page 406 A Appendices Symptom: Cannot Communicate or a Communications Error Occurs Meaning Countermeasures The communications wiring is not correct. Correct the wiring. The communications line has become Connect the communications line securely and tighten the screws. disconnected. The communications cable is broken. Replace the cable.

  • Page 407: Parameter Operation Lists

    A Appendices A-6 Parameter Operation Lists A-6-1 Operation Level Parameter Characters Setting (monitor) value Display Default Unit Process Value (1) (2) Temperature: According to indication range for each sensor. Analog: Scaling lower limit −5% FS to Scaling upper limit +5% FS Set Point (1) (2) SP lower limit to SP upper limit Auto/Manual Switch...

  • Page 408: A-6-2 Program Setting Level

    A Appendices A-6-2 Program Setting Level Parameter Characters Setting (monitor) value Display Default Unit d.prg Display Program 0 to 7 Number of None Selection program currently used for control. s-no Number of Segments 1 to 32 None Used END or 0 to Number of segments used − 1 d.seg Display Segment None...

  • Page 409: A-6-3 Adjustment Level

    A Appendices A-6-3 Adjustment Level Parameters Characters Setting (monitor) value Display Default Unit l.adj Adjustment Level Display off, at-2, AT Execute/Cancel OFF, AT Cancel None at-1, ata1, AT-2: 100%AT Execute ata2 AT-1: 40%AT Execute ATA1: All PID 40% AT Execute ATA2: All PID 100% AT Execute cmwt off, on...
  • Page 410 A Appendices Parameters Characters Setting (monitor) value Display Default Unit °C or °F Hysteresis (Heating) Temperature input: 0.1 to 999.9 Analog input: 0.01 to 99.99 0.10 °C or °F chys Hysteresis (Cooling) Temperature input: 0.1 to 999.9 Analog input: 0.01 to 99.99 0.10 Standard: −5.0 to 105.0 mv-r...

  • Page 411: A-6-4 Pid Setting Level

    A Appendices A-6-4 PID Setting Level Parameters Characters Setting (monitor) value Display Default Unit d.pid Display PID Selection 1 to 8 Currently selected PID set number PID * Proportional °C or °F Temperature input: 0.1 to 999.9 Band Analog input: 0.1 to 999.9 10.0 PID * Integral Time Standard,...

  • Page 412: A-6-5 Initial Setting Level

    A Appendices A-6-5 Initial Setting Level Parameters Characters Setting (monitor) value Display Default Unit in-t Input Type Temperature 0: Pt100 None input 1: Pt100 2: Pt100 3: JPt100 4: JPt100 5: K 6: K 7: J 8: J 9: T 10: T 11: E 12: L...
  • Page 413 A Appendices Parameters Characters Setting (monitor) value Display Default Unit s-hc stnd, h-c Standard or Standard or heating/cooling Standard None Heating/Cooling 0.1, 0.2, 0.5, 1 Control Period 0.1, 0.2, 0.5, or 1 to 99 Relay Seconds to 99 (Heating) output: 20 Voltage output (for driving...
  • Page 414 A Appendices Parameters Characters Setting (monitor) value Display Default Unit alt4 Alarm 4 Type Same as Alarm 1 Type except that 12 (LBA) cannot None be set. °C or °F alh4 Alarm 4 Hysteresis Temperature input: 0.1 to 999.9 for all alarms except for MV absolute-value upper-limit or MV lower-limit alarms Analog input: 0.01 to 99.99 for all alarms except for...

  • Page 415: A-6-6 Manual Control Level

    A Appendices Parameters Characters Setting (monitor) value Display Default Unit ev-5 Event Input Same as Event Input Assignment 1. Same as NONE None Assignment 5 Event Input Assignment 1. ev-6 Event Input Same as Event Input Assignment 1. Same as NONE None Assignment 6...

  • Page 416: A-6-8 Advanced Function Setting Level

    A Appendices A-6-8 Advanced Function Setting Level Parameters Characters Setting (monitor) value Display Default Unit init off, fact Parameter Initialization OFF, FACT None pend on, 0.0, or Program End ON Time ON: Continue output, 0.0: No output, or 0.1 to 10.0 Seconds 0.1 to 10.0 Standby Time Unit...
  • Page 417 A Appendices Parameters Characters Setting (monitor) value Display Default Unit off, on HS Alarm Use OFF, ON None off, on HS Alarm Latch OFF, ON None HS Alarm Hysteresis 0.1 to 50.0 LBA Detection Time 0 to 9999 (0: LBA function disabled) Second °C or °F lbal...
  • Page 418 A Appendices Parameters Characters Setting (monitor) value Display Default Unit sub1 none Auxiliary Output 1 NONE: No assignment ALM1 None Assignment *Controllers O: Control output (heating) without HB C-O: Control output (cooling) and HS alm1 ALM1: Alarm 1 alarm alm2 ALM2: Alarm 2 detection: alm3...
  • Page 419 A Appendices Parameters Characters Setting (monitor) value Display Default Unit pmvd off, on Direct Setting of OFF, ON None Position Proportional pvrp PV Rate of Change 1 to 999 Sampling Calculation Period period hctm Heating/Cooling Tuning 0: Same as heating control None Method 1: Linear...

  • Page 420: A-6-9 Protect Level

    A Appendices Parameters Characters Setting (monitor) value Display Default Unit spd1 PV/SP No. 1 Display 0: Nothing is displayed. None Selection 1: PV/SP/Nothing displayed 2: PV/Nothing displayed/Nothing displayed 3: SP/SP (character display)/Nothing displayed 4: PV/SP/MV (heating) (valve opening for Position-proportional Models) 5: PV/SP/MV monitor (cooling) 6: PV/SP/Program number and segment number 7: PV/SP/Remaining segment time...

  • Page 421: A-6-10 Communications Setting Level

    A Appendices A-6-10 Communications Setting Level Parameters Characters Setting (monitor) value Display Default Unit psel Protocol Setting CWF: CompoWay/F CompoWay/ None MOD: Modbus CMP: Component communications fins FINS: Host Link (FINS) mcp4 MCP4: MC Protocol (Type 4) u-no Communications Unit No. 0 to 99 None 9.6, 19.2,...

  • Page 422: A-6-11 Initialization According To Parameter Changes

    A Appendices A-6-11 Initialization According to Parameter Changes The parameters that are initialized when parameters are changed are shown under Related initialized parameters. Changed parameter Related initialized parameters SP Upper Limit ---| --- SP Lower Limit Segment SP Integral/Derivative Time Unit MV at Reset MV at PV Error Manual MV...
  • Page 423 A Appendices Changed parameter Related initialized parameters Alarm 4 Hysteresis AT Hysteresis LBA Level LBA Band Startup Operation Operation End Operation Proportional Band Proportional Band (Cooling) Integral Time Integral Time (Cooling) Derivative Time Derivative Time (Cooling) MV Upper Limit MV Lower Limit Automatic Selection Range Upper Limit Program Start...
  • Page 424 A Appendices • MV Lower Limit: Standard 0.0, heating/cooling −100.0 For heating and cooling control, initialized to Control Output (Cooling) as follows: (The defaults for standard control are the defaults in the parameter list.) • With control output 2: The Control Output 2 Assignment parameter is initialized to control output (cooling). •...

  • Page 425: Sensor Input Setting Range, Indication Range, Control Range

    A Appendices A-7 Sensor Input Setting Range, Indication Range, Control Range Specifica Input setting range Input indication range tions value −200 to 850 (°C)/−300 to 1500 (°F) −220 to 870 (°C)/−340 to 1540 (°F) Resistance Pt100 thermometer −199.9 to 500.0 (°C)/−199.9 to 900.0 (°F) −199.9 to 520.0 (°C)/−199.9 to 940.0 (°F) −20.0 to 120.0 (°C)/−40.0 to 250.0 (°F) 0.0 to 100.0 (°C)/0.0 to 210.0 (°F)

  • Page 426: Setting Levels Diagram

    A Appendices A-8 Setting Levels Diagram This diagram shows all of the setting levels. To move to the Advanced Function Setting Level and Cali- bration Level, you must enter passwords. Some parameters are not displayed depending on the protect level setting and the conditions of use. Control stops when you move from the Operation Level to the Initial Setting Level.

  • Page 427: Parameter Flow

    A Appendices A-9 Parameter Flow Some parameters may not be displayed depending on the model and other settings. Starting in manual mode Monitor/Setting Item Level PF Monitor/ Power ON PF Monitor/Setting Manual Control Level Setting Item Item display 2 to 5 display 1 * The monitor/setting items to display are set in the Monitor/Setting Item 1 to 5 parameters PV/Manual MV...
  • Page 428 A Appendices Press O Key Protect Level for at least 1 s. Press O + M Key for at least 3 s. Operation/Adjustment oapt pfpt PF Key Protect pmov Protect Move to Protect Level Initial Setting/ Parameter Mask Enable icpt pmsk Press O + M Key for at least 3 s.
  • Page 429 A Appendices Advanced Function Setting Level Direct Setting of Position init mant pmvd Manual Output Method Proportional MV Parameter Initialization hold PV Rate of Change mani pvrp pend Manual MV Initial Value Program End ON Time Calculation Period Heating/Cooling Tuning hctm Standby Time Unit Method...

  • Page 430: Index

    Index Index-1 E5@C-T Digital Temperature Controllers User’s Manual (H185)
  • Page 431 ..............4-59 alarms ................. 4-24 alarms (standard alarms) ..........1-4 front panel ..............3-4 analog inputs ............5-5, 7-9 E5AC-T ..............3-5 assigning outputs ............4-23 E5CC-T ..............3-4 AT (auto-tuning) ............4-50 E5EC-T ..............3-4 auto/manual control ............. 5-12 auto-tuning (AT) ..........
  • Page 432 Alarm 1 To 4 OFF Delay ........6-92 Alarm 1 to 4 ON Delay .......... 6-91 Alarm 1 to 4 Type ......... 4-56, 6-66 Keys Alarm 1 to 4 Upper Limit ........4-59 D Down Key ............3-7 Alarm Lower Limit Value ........4-59 O Level Key ............
  • Page 433 Proportional Band (Cooling) ....4-21, 5-9, 6-37 Hysteresis (Heating) ..........6-38 Protocol Setting ........... 6-111 Initial Setting/Communications Protect ....6-4 PV Rate of Change Calculation Period ..4-60, 6-102 Input Digital Filter ........... 6-87 PV Status Display Function ......... 6-108 Input Type ............ 6-56, A-23 PV/MV (Manual MV) ..........
  • Page 434 SV status display ............5-77 switching the SP mode ..........5-13 temperature unit ............4-20 terminal arrangement ............ 2-7 terminal block wiring examples E5AC-T ..............2-11 E5CC-T ..............2-7 E5EC-T ..............2-11 thermocouple calibration ..........7-4 thermocouple or infrared temperature sensor ..... 7-13 three-position control ..........
  • Page 435 Index-6 E5@C-T Digital Temperature Controllers User’s Manual (H185)
  • Page 437 The Netherlands IL 60173-5302 U.S.A. Tel: (31)2356-81-300/Fax: (31)2356-81-388 Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 © OMRON Corporation 2014 All Rights Reserved. OMRON (CHINA) CO., LTD. OMRON ASIA PACIFIC PTE. LTD. In the interest of product improvement, Room 2211, Bank of China Tower, No.
  • Page 438 Below is a list of articles with direct links to our shop Electric Automation Network where you can see: • Quote per purchase volume in real time. • Online documentation and datasheets of all products. • Estimated delivery time enquiry in real time. •...

This manual is also suitable for:

E5ec-tE5cc-t

Table of Contents

Save PDF
