Terminal Unit; Conversion Cable - Omron E5 C Series Manual

E5DC/E5DC-B
Accessories (Order Separately)

Terminal Unit

E5DC-SCT1S
USB-Serial Conversion Cable
E58-CIFQ2

Conversion Cable

E58-CIFQ2-E
Conversion Cable
(1510)
Note: Always use this product together with the E58-CIFQ2.
72
22.5
30.7
+1.15
90
35
-0.2
4
250
USB connector
(type A plug)
Connecting to the E58-CIFQ2 USB-Serial Conversion Cable
250
Push-In Plus Terminal Unit
E5DC-SCT1B
+1.15
90
-0.2
(2110)
263
LED (RD)
LED (PWR)
LED (SD)
(2110)
263
E58-CIFQ2 (Order separately)
(6.5)
22.5
36.2
35
4
1510
Serial connector
1510
Conversion Cable
