E5CC/E5CC-B/E5CC-U
Watertight Cover
Y92A-48N
87.7
79.2
67.6
Protective Cover
Y92A-48D
Note: This Protective Cover cannot be used
E5CC-U Wiring Socket
Front-connecting Socket
P2CF-11
Note: 1. A model with finger protection (P2CF-11-E) is also available.
2. You cannot use the P2CF-11 or P2CF-11-E together with the Y92F-45.
Back-connecting Socket
P3GA-11
Note: 1. Using any other sockets will adversely affect accuracy. Use only the specified sockets.
2. A Protective Cover for finger protection (Y92A-48G) is also available.
3. You cannot use the P3GA-11 together with the Y92F-45.
38
21.9
14
(2)
69
12
if the Waterproof Packing is installed.
This Protective Cover is soft type.
It is able to operate the controller with using
this cover.
Eleven, M3.5 × 7.5
3
7.8
sems screws
70 max.
Two,
4.5-dia.
holes
4
50 max.
27dia.
45
45
4.5 16.3 6.2
Mounting Adapter
Y92F-49
Protective Cover
Y92A-48H
Terminal Layout/Internal Connections
4.5
(Top View)
35.4
9
31.2 max.
Eleven, M3.5
Terminal Layout/Internal Connections
sems screws
4
7
3
25.6
6
8.7
The Mounting Adapter is provided with the
Temperature Controller.
Order the Mounting Adapter separately if it
becomes lost or damaged.
This Protective Cover is hard type.
Please use it for the mis-operation
prevention etc.
8
7
6
5
Mounting Holes
4
Two, 4.5 dia. mounting holes
3
Note: Can also be mounted
10 11
1
2
to a DIN track
(Bottom View)
5 6 7 8
4
3
9
2
1
11
10
±0.2
40
