Appendix A. Coolbox
Unboxing
Carefully remove the items from the box as directed.
1. Remove the Top Foam : Beneath the top foam, you will see the Coolbox and all needed accessories.
2. Remove Right Packaging Box: Remove the larger box to the right and check that all the following
parts are included: 2-Pin Cable (1), 4-Pin Cable (1) and AC Power Cable (1).
3. Remove Right Packaging Box: Remove the smaller box to the left and check that all parts are
included. Cooling Fan (1), 4-Pin Molex to 4-Pin Terminal Connector (1) and a small plastic bag
containing: 2mm Hex Key (1), 2.5mm Hex Key (1), 5.5/7mm Wrench (1), two M3 Nuts (2) and four
Acorn Nuts (4).
4. Remove Coolbox: Start by removing the three pieces of side foam, securing the Coolbox.Then,
gently lift the Coolbox from the box. You can lift and remove the adapter plate and the foamsheet at
the same time as the Coolbox.
5. Remove Exhaust Fan Cowling: Remove the exhaust fan cowling and its support foam.
6. Remove Muse 3D Side Panel: Remove foam covering the side panel. Remove the new Muse 3D
side panel from the box. Your Coolbox is unboxed.
Parts Checklist
Coolbox Unit (1)
Exhaust Fan Cowling (1)
Adapter Plate (1)
2-Pin Cable (1)
4-Pin Cable (1)
AC Power Cable (1)
Cooling Fan (1)
Connector (1)
Technical Support is available 8am-5pm PST. Monday - Friday
support@fslaser.com
2.5mm Hex Key (1)
5.5/7mm Wrench (1)
M3 Nuts (2)
M4 Acorn Nuts (4)
