RetinaEngrave v3.0 Software
Raster Properties Window
Halftone Dither: Apply Halftone Dither.
Intensity: Adjust intensity from -255 to 255.
Blur: Adjust blur filter radius from 0 to 30.
Edge: Adjust edge enhancement threshold from 0 to 30.
Threshold: Apply Threshold; adjust from 0 to 255.
Invert: Reverse Black and White elements.
Power%: Select power percentage from 1 to 100.
Speed: Select speed from 1 to 2000.
Pulse Rate: Select pulse rate from 20,000 to 80,000.
Autofocus: Allows user to autofocus to the selected point.
Object Packing
(Appears when an object is selected)
Allows the user to arrange multiple designs relative to the top-left corner with
customized spacing.
Padding: Spacing between objects.
Size: Determine packing space.
Vector Fill & Rasterize
Use the this Window to set an infill for shapes and designs.
Infill: Set the pattern of your fill.
Generation: Generates raster lines based off all objects or for each.
Rasterize: Clicking icon opens raster menu.
(G)
(G)
Technical Support is available 8am-5pm PST. Monday - Friday
support@fslaser.com
SECTION VI. SOFTWARE
Using RetinaEngrave v3.0 Software
In this section you will be introduced to the major interface features of RetinaEngrave
v3.0.
Figure 6.1
