Connect To Software - Full Spectrum Laser MUSE 3D Operation Manual

Section III. Installation & Assembly

7. Connect to Software

Assembly Stage 7: Connect to Software
RetinaEngrave v3.0 is a combination of a print driver and control software that communicates with,
downloads jobs to, and controls the laser system. There is no download required for RetinaEngrave v3.0.
With a local connection (achievable with Wi-Fi or the included Ethernet cable) your Muse 3D will link with the
software's IP address.
1.Turn On Muse 3D: Turning on your Muse 3D will automatically boot up your Muse Touch Screen interface.
Allow 30 seconds or so for the machine and touch screen to boot up.
2.Go To Settings: On the Touch Screen interface, push the gear icon to go to Settings.
3.Choose Network: Push "Network" at the top center of the screen.
4.Type IP Into Browser: On the Network Screen you will see a "Wired IP" number. Using your computer,
type this IP number into your favorite browser (Google Chrome is recommended). This will link you to
the RetinaEngrave v3.0 interface. You now have full access to the software. There is no need to install or
download anything. You must, however, keep a local connection, either through Wi-Fi or the Ethernet cable.
• Occasionally, RetinaEngrave v3.0 software will run an update. This is an
automatic process that can happen when you first boot up the machine. Typically,
updates are quick, however, there may be some occasions where updates can
take longer. You will know the machine is updating when the interior lights of the
Muse 3D turn off. When this happens, Do not turn off your machine. Allow the
update to complete and the machine lights will turn back on.
• The laser must be powered on when operating the software or when connecting
the laser via the Ethernet cable. You will need uninterrupted Internet access for
this process.
Technical Support is available 8am-5pm PST. Monday - Friday
support@fslaser.com • 702-802-3103
23
