Full Spectrum Laser Muse Core Operation Manual

Hide thumbs Also See for Muse Core:
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Muse Core and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Full Spectrum Laser Muse Core

Summary of Contents for Full Spectrum Laser Muse Core

  • Page 2: Table Of Contents

    Section Review ................8 Section II. Unboxing Your Muse Core Unboxing Steps .
  • Page 3 Table of Contents Section VIII. Operations Creating a Design ............... . 40 Mouse Control .

  • Page 4: Introduction

    Introduction Thank you for purchasing your new Muse Core. Our high quality products will provide years of service simply by following proper usage and upkeep. With proper usage and upkeep your machine will be a key part in any design work.

  • Page 5: Section I. Safety

    Section I. Safety Fire Safety Laser cutting and engraving systems can present a significant fire hazard due to the extremely high temperatures generated when the laser beam is in use. Some material are extremely flammable, catching fire quite easily and damaging the machine and its surroundings.

  • Page 6: Safety During Operation

    In order to prevent access to bare wiring your laser shipped with silicone terminal covers. Please notify Full Spectrum Laser support and immediately cease operations if the covers ever slips and exposes the bare wires.

  • Page 7: Harmful Materials

    Section I. Safety HARMFUL MATERIALS: WARNING!! TRYING TO CUT THESE ITEMS WILL VOID WARRANTY!! CUT AT YOUR OWN RISK! Material DANGER! Issues PVC (Poly Vinyl Chloride)/Vinyl/ Emits Chlorine gas fumes This material can ruin the optics as well as cause the metal of the Pleather/Most Artificial Leather machine to corrode.

  • Page 8: Diagrams

    Section I. Safety The following diagrams will help you locate all of the machines components. Top View: Water Exhaust Power Switch In/out Touchscreen Play/ Pause Button Side View: Back View: Rotary Port Air Inlet Machine Water Water Control Power Switch Side View: USB Port Ethernet...

  • Page 9: Section Review

    Section I. Safety Section Review: Do’s: ● Remember to make sure your work area is nice an clean. Keep your laser system clean. Always keep an eye on your machine. ● ● Always inspect your machine for damage or breakage before each use. ●...

  • Page 10: Section Ii. Unboxing Your Muse Core

    Section II. Unboxing The Muse Core has a weight of 54 lbs. To avoid the potential of injury, two people are needed to lift and unbox the machine. Lift At Your Own Risk. 13.7” 25.55” 36.7” Unboxing Steps Follow these instructions for best results: Prepare Work Space: You will need an open, level work space to place your laser cutter.
  • Page 11 Section II. Unboxing Open the box. Carefully remove the Honeycomb tray. Remove the foam layer to access the machine. Two people should carefully remove the Muse Core from the box.
  • Page 12 Section II. Unboxing Inspect the outside of your machine. Open the Muse and remove the Coolbox package. Remove the Accessory box. Remove the Foam from under the Gantry. Remove the Foam from under the side panels.

  • Page 13: Checklist

    Never use unapproved ducting in the exhaust system as it is potentially flammable. ● Never operate your laser without a working exhaust. Full Spectrum Laser recommends exhaust systems capable of AT LEAST 500CFM. Keep in mind that exhaust systems with high flow rates may require a particle filter for materials with...

  • Page 14: Section Review

    Section II. Unboxing Section Review: Do’s: ● Remember to Lift Your Box with a partner. Remember to lift with your knees. Check your 3D for any damage prior to use. ● ● Make sure to check that your machine came with all the items on the checklist. Don’ts: ●...

  • Page 15: Section Iii. Setting Up Your Muse

    Section III. Setting Up Your Muse This assembly is a simple process that should take less than half an hour to complete. For simplicity we divided the assembly into five easy steps. Locate & Remove Zip Ties Connect the Exhaust System Assemble the Water System(Hobby Kit) Assemble the Air Compressor(Hobby Kit) Connect Electrical Power...

  • Page 16: Connect The Exhaust System

    “exhaust” on the back of your Muse Core machine. (see Fig. 4). Ventilate Outside or to Fume Extractor: Set the open end outside of a window or to a fume extractor. Check your system for leaks and be aware that the protective housing is not designed to be airtight;...

  • Page 17: Preparing Water System

    Section III. Setting Up Your Muse 3. Water System Assembly The Muse Core comes with an optional Hobby Kit that contains both the Air Compressor and Water Pump. If the Coolbox option was selected instead, then proceed to the “Add-on” section on pg 62.
  • Page 18 Section III. Setting Up Your Muse Prepare the Water Bucket: Fill a 5 gallon bucket(not included) by about 2/3rd using distilled water. Make sure to only use distilled water and replace often. If you live in a cold climate you can use a 1:2 Propylene Glycol and Distilled water mix to prevent freezing.

  • Page 19: Connect The Air Compressor

    Section III. Setting Up Your Muse 4. Connect the Air Compressor Air is used as a pressurized gas to assist in cutting and engraving operations. This pressurized air is critical to safe and efficient cutting operations as it not only helps cut through material more quickly, but also helps prevent the formation of flames.

  • Page 20: Connect The Electrical Power

    Section III. Setting Up Your Muse The Muse Core and its accessories are configured to accept 110VAC at 60Hz. For international purposes we offer an optional single-phase 220VAC converter. Prepare Power Cord: Remove the electrical cord from its packaging. Plug in Power Cord To Laser Cutter: The power cord plugs into the C14 slot located on the back of the machine.

  • Page 21: Section Review

    Section III. Setting Up Your Muse Section Review: Do’s: ● Remember to remove all the zip-ties before trying to use your machine. Remember to connect the machine to external ventilation, such as to a window or a fume extractor. ● Don’ts: ●...

  • Page 22: Section Iv. Touchscreen Interface

    Section IV. Touchscreen Interface The touchscreen that comes on your Muse allows you to control the basic functions of your laser without needing a computer. Jobs are accessible through the touchscreen once loaded in from the RE3 interface. Home The Home screen contains the device’s IP address, the QR Code for RE3 and controls for the laser head.

  • Page 23: Machine Indicator

    Section IV. Touchscreen Interface Machine Indicator: Lock Indicator: Locked Icon: Indicates the gantry is locked. When locked, the user must move the gantry using JOG controls. Unlocked Icon: Indicates the gantry is unlocked. When unlocked, the user must manually move the gantry Lid Indicator: The Titan’s lid has a magnetic failsafe that disconnects the laser when the lid is open.

  • Page 24: Speed Indicators

    Section IV. Touchscreen Interface Speed Indicators: Your machine has 3 speed setting that can be changed by selecting the icon on the touchscreen or from RE3. Running Icon: The machines default speed and the fastest speed, used for fast movement across the work area Jogging Icon: The second speed, also known as the intermediate speed, used for normal adjustments before running a job Walking Icon: The final and slowest speed, used for small adjustments.

  • Page 25: Section Review

    Section IV. Touchscreen Interface Section Review: Do’s: ● Make sure your Gantry is locked before use. Make sure the lid is closed before use. ● ● Make sure the water system is running. Don’ts: ● Do Not use your machine if the gantry is unlocked. Do Not use your machine if the water system is off.

  • Page 26: Section V. Internet Connection

    Fig. 14 Connect Directly to Computer: Connecting the Muse Core and the computer should only be done if the previous two options are not possible. The Muse can connect to the computer via ethernet cable. Note: The location of the ethernet port varies on computer models. Some computers may not have an ethernet...

  • Page 27: Connect To Software

    Muse Core will link with the software’s IP address Turn On Muse Core: Turning on your Muse Core will automatically boot up your Muse Touchscreen interface. Allow 30 seconds or so for the machine and touch screen to boot up.

  • Page 28: Section Review

    Section V. Internet Connection Section Review: Do’s: ● Make sure your machine is connected to the internet before you attempt your first project. Remember to let your machine fully boot up before attempting to enter RE3. ● Don’ts: ● Do Not take off the Wi-Fi dongle. ●...

  • Page 29: Section Vi. Tests & Adjustments

    Section VI. Laser Alignment The laser tube that came pre-installed in your Muse Core was carefully aligned in our facilities in Nevada. However, it is possible that the mirrors may come out of alignment during shipping. Before running your first job, you will want to check and make sure the mirrors are properly aligned using the following procedure.I f your mirror is out of...

  • Page 30: Mirror Alignment

    Section VI. Laser Alignment Position Laser Head to 1st Position: Move the laser head into the left most position. Close The Safety Lid: Safety measures are in place to ensure laser does no fire with the safety lid open. Regardless, never attempt to fire the laser with the safety lid open.
  • Page 31 Section VI. Mirror Alignment Preparation: Tools: Thermal Paper (included with accessories) 2.5mm Hex Wrench (included with accessories) Make sure to prepare your tools and workspace. Turn on Titan: Allow the machine time to fully boot up. Unlock Driver Motor On the touch screen, press the “Locked” icon. It will enter the “Unlocked” position signifying the gantry motor is disabled.
  • Page 32 Section VI. Mirror Alignment Laser Output to Mirror 1: Align the laser output to Mirror #1 making sure that the beam hits close to the center of the mirror. Open the Safety Lid. Place Thermal Paper On Mirror 1. Make sure to place it firmly over Mirror #1 to create a reference ring. Close Safety Lid: Machine should be unable to fire the laser with the safety lid open.
  • Page 33 Section VI. Mirror Alignment Mirror 1 to Mirror 2: Mirror 1 is stationary but Mirrors 2 and 3 are located on the Y and X gantry respectively. Therefore both of those Mirrors need to be aligned in the nearest and farther position from the previous Mirror for proper alignment. Mirror 1 Mirror 2 Mirror 2...
  • Page 34 Section IV. Test and Adjustment Section VI. Mirror Alignment 2. Mirror Alignment Procedure Mirror 2 to Mirror 3: Mirror 3 is located on the laser head assembly, we will have to check the alignment along the X-gantry. We recommend selecting three position to test the alignment and using two of those positions to adjust the red diode. POSITION 1/ POSITION 3/ POSITION 2...
  • Page 35 Section IV. Test and Adjustment Section VI. Mirror Alignment 2. Mirror Alignment Procedure Mirror 3 to Focus Lens: The focus lens converges the laser beam to a single point. The focus lens does not require manual focusing, however it is important to ensure that the path from mirror #3 to the focal lens is straight throughout the Z-axis. Fig.
  • Page 36 Section IV. Test and Adjustment Section VI. Mirror Alignment 2. Mirror Alignment Procedure 1st Position 2nd Position Fig. 23 Position Laser Head to 1st Position. Manually adjust the laser head assembly so that the z- belt is as high as it goes. Close Safety Lid.

  • Page 37: Section Review

    Section VI. Laser Alignment Section Review: Do’s: ● Before attempting to run a project you should perform the Alignment Test. Remember to adjust the Red Diode after Adjusting Mirror 1 and during the alignment of Mirror 3. ● ● Remember to unlock the gantry before starting the Alignment Test and the Mirror Alignment. ●...

  • Page 38: Section Vii. Focusing Your Laser

    Section VII. Focusing Your Laser Focus Procedure The Muse Core must be focused manually for each new material. The Muse Core comes with a 20mm focusing billet. Fig. 24 Use the job controls on RE3 or from your touchscreen to move the laser over your material.
  • Page 39 Section VII. Focusing Your Laser Adjust the knob to secure the laser head in place. Fig. 26 Remove the billet. Your laser is now ready to start engraving. Fig. 27...

  • Page 40: Section Review

    Section VII. Focusing Your Laser Section Review: Do’s: ● Focusing can be done manually using the focusing billet or something of equal height. If you place a new material into the workspace remember to refocus your laser head. ● Don’ts: ●...

  • Page 41: Section Viii. Operations

    Section. VIII Operations This section will guide you through using your Muse Core. To get started, it is important to understand the meanings of “Vector Cutting” and “Raster Engraving” and their associated file types. Vector Cutting Raster Engraving Vectors use mathematical formulas to create paths Rasters are make of white and colored pixels.

  • Page 42: Mouse Control

    Section. VIII Operations Mouse Controls: Drag ‘n Drop: Click and hold a design file, it will become highlighted letting you know it can then be dragged. Drag it into the workspace and a move prompt will appear below the object showing it can be dropped into the workspace.

  • Page 43: Section Review

    Section. VIII Operations Section Review: Do’s: ● PDF is preferred for Vectors, while JPEG is preferred for Rasters. Remember when preparing your own design to use thicker lines. ● ● Remember that previews are seen in 200 DPI but are imported as 500 DPI. ●...

  • Page 44: Section Ix. Retinaengrave V3

    Section. IX Retina Engrave V3 Starting on RE3 Using your new machine for the first time can seem intimidating but we've worked to make this guide as clear as possible regarding our software. We have broken down the entire process into 7 steps. Connect to Software Create or Import Design Adjust Object Properties...
  • Page 45 Section. IX Retina Engrave V3 Import Design Select the file you wish to engrave via your editing software or an image saved on your computer. It can be place into RE3 using three methods: -It can be imported by going to the File->Import->Image -It can be “dragged”...
  • Page 46 Section. IX Retina Engrave V3 5.Focus Lens Your Core will need to be manually focused before each project. 6. Align your design with your material. This can be done by using the perimeter icon to preview the area where the laser will engrave. *You can the camera capture option that can help for better alignment of your design.

  • Page 47: Compound Shapes & Objects

    Section. IX Retina Engrave V3 Here is some other information that will be useful when performing your first jobs on RE3. Creating and Manipulating Compound Shapes & Objects These functions are available in the Grouping section of the toolbar (see above). Compound Shapes & Objects Operators can combine and modify shapes and objects to create unique compound shapes and objects with these functions: Union: Subtract:...

  • Page 48: Passes

    Section. IX Retina Engrave V3 Passes: Passes are typically used for different things in rastered material than in vectored. Vector Passes In vectors, multiple passes are done to cut through thicker material. Sometimes, such as when cutting wood, a single cut is not enough therefore we can program multiple passes to ensure we cut through our material.

  • Page 49: Stopping Your Laser

    This should be your first method of stopping the laser during an emergency. This is a safety feature of Muse Core and under no circumstances should this safe lid auto-shutoff device be tampered with or removed.
  • Page 50 Section. IX Retina Engrave V3-Stopping Laser Software E-stop: Located on the top right corner of the webpage. Software Pause Button: If near your computer, the Pause Button (found were the Play button was) can halt the laser. This may take a second to process,so it is not recommended as a method of stopping the laser in an emergency.

  • Page 51: Section Review

    Section IX. Retina Engrave V3 Section Review: Do’s: ● Remember there are three methods to importing a file. If one does not seem to be working for you, then try the others. Remember to use the Perimeter option to align your design with your materials. ●...

  • Page 52: Section X. Maintenance

    Replacing the Laser Tube This section provides procedures and a walkthrough to replace the laser tube on your Muse Core. Although it should last for hundreds of hours, the laser tube is considered a consumable and will eventually need to be replaced. Please carefully read all instructions before beginning the replacement procedure as there are several critical steps which must be properly followed to avoid breaking the laser tube.
  • Page 53 Section X. Maintenance 4. Remove the Return/Grounding Wire: Remove the grounding wire using the clip attached. Fig. 30 Note: The clips in the grounding wire may appear differently than the picture but functions the same. 5. Disconnect High Voltage wire: The voltage wire is found on the right side of the laser tube. Unplug the wire. Fig.

  • Page 54: Setting Up New Tube

    Section X. Maintenance Disconnect Water: Detach the water tubes from their connectors on the laser tube from both ends and drain the water into a bucket. WARNING! INLET AND OUTLET ARE FRAGILE! DO NOT PULL EXCESSIVELY! WARNING! WATER CAN SPILL! HAVE A CLEANING RAG NEARBY IF NEEDED! Removing Laser Tube: Take the provided hex key and remove the screws atop each bracket to release the tube.

  • Page 55: Belt Replacement

    Belt Replacement: The belts on your laser system are a consumable item and will eventually stretch beyond a usable length or break. You can contact Full Spectrum Laser support for replacements. Required Parts and Tools ● 2.5mm Hex key (included with accessories) Belt Replacement Instructions: 1.

  • Page 56: Lens & Air Assist Cone Replacement

    Section X. Maintenance Focus Lens and Air Assist Cone Replacement Instructions: Parts: Air Assist Cone, Assist Fitting, and Focus Lens w/ Case (C) Note:This is for replacing air assist cones and different sized lenses.If you are replacing a lens that has become damaged or broken you just need to slide the new lens in.
  • Page 57 Section X. Maintenance Place the new air assist cone under the focus lens and into the slot. Tighten “set” screw with a 1.5hex wrench. Reattach air hose. Fig. 35 Slide the current focus lens out of the slot. This does not require tools. Slide the new lens into the slot.

  • Page 58: Pass-Through

    Section X. Maintenance The Muse Core and Muse 3D both come with removable floors. These are ideal for cutting/engraving larger materials or using our rotary accessory. It is also possible to install a passthrough for longer materials. This opens you up to a wide range of products and materials to use with your Muse laser.

  • Page 59: General Maintenance

    Section X. Maintenance Before starting a job: Make sure the lens and optics are clean and cleared of debris using an optic lens wipes. Note: This is the only recommended options for cleaning lenses as other options can cause micro scratches in your optics.

  • Page 60: Section Review

    Section X. Maintenance Section Review: Do’s: ● Remember to follow daily, weekly, and monthly maintenance to ensure a long lasting machine. When installing a new laser tube, make sure all the wires are securely fastened. ● ● When replacing tubing make sure to check for holes. Don’ts: ●...

  • Page 61: Section Xi. Add-Ons

    Section XI. Add-ons Coolbox Set-up Muse 3D comes with the Muse Coolbox. The Muse Coolbox acts as both a water and air system. Remove Water Cap: Remove the short silicone tubing, capping the water inlet and outlet on the back of the machine. Attach Water Tubes: Remove the coolbox from its packaging.
  • Page 62 Section XI. Add-ons Attach the Air Tubing: Connect one end of the air tubing to the back of the 3D and the other to the air out on the back of the Coolbox. Fig. 39 Preparing the Coolbox: Fill the Coolbox using 1.5 Liters of DISTILLED water. Make sure to only use distilled water and replace often.

  • Page 63: Warranty

    Warranty Warranty Full Spectrum Laser will replace or repair any defective parts free of charge within the first 30 days. Ground shipping is free with overnight shipping available at extra charge. Full Spectrum Laser will replace or repair any defective part within the warranty period free of charge but shipping charges are the responsibility of the customer.

  • Page 64: Customer Support

    Customer Support For a list of Frequently Asked Question and a series of help guides, visit us at our Help Center We offer a variety of free projects to help you get started, just check out our Free Projects page. For more information on laser engraving, check out our Blog Technical Support:...
