Electrical Safety - Full Spectrum Laser MUSE 3D Operation Manual

Section 1. Safety
Electrical Safety & References

Electrical Safety

The power supply is capable of outputting DC 20,000V at up to 20mA. This power is also provided to the
discharge terminals on the laser tube itself. Your laser shipped with silicone terminal covers that prevent
access to bare wiring—notify Full Spectrum Laser support and immediately cease operations if these covers
ever slip and expose bare wire.
CAUTION
The standard reference for laser safety is the American Standard for the Safe Use of Lasers, Z136.12000, developed
by the American National Standards Institute (ANSI). This reference is the basis for many of the federal regulations
for laser and laser system manufacturers, and for the Occupational Safety and Health Administration (OSHA) laser
safety guidelines. It contains detailed information concerning proper installation and use of laser systems. While
the ANSI standard itself does not have the force of law, its recommendations, including warning signage, training,
and the designation of a laser safety officer, may be compulsory under local workplace regulations when operating
laser systems above Class I. It is the operator's responsibility to ensure that the installation and operation of the Full
Spectrum Laser Hobby Laser System is performed in accordance with all applicable laws. Copies of ANSI Standard
Z136.12000 are available from: LASER INSTITUTE OF AMERICA 12424 RESEARCH PARKWAY, SUITE 125
ORLANDO, FL 32826 (407) 3801553.
• Do not open any of the machine's access panels while the unit is plugged in.
Opening a panel may expose the operator to the unit's AC input power. The AC
input power is potentially lethal and is located on the far right within the cabinet.
• Never make or break any electrical connections to the system while the unit
is turned on.
• Never access the electronics area with hands or tools unless the unit is
disconnected from power for at least one hour.
• Never replace the installed 10 amp fuse with a fuse of a higher rating. This
will void your warranty and the electronics will not be adequately protected from
surges or short circuits.
• POWER ON/OFF is controlled by the switch at the back of the machine. To power
the machine on, press the (-) side down. To turn power off, press the "o" side down.
• In case of a blown fuse always contact Technical Support before replacing
any fuses.
Technical Support is available 8am-5pm PST. Monday - Friday
support@fslaser.com • 702-802-3103
8
