Pet Immunity Guidelines (EL-2745PI)
It is expected that the detector will eliminate false alarms caused by animals up to 45kg/100lbs, several small rodents
and random flying birds.
Note: The weight of the animal should only be used as a guide, other factors such as the length and color of
fur also affect the level of immunity
For maximum pet immunity the following guidelines are recommended:
Mount the center of the detector at a height of 2.2m
Set the pulse counter to Adaptive. If the weight of the animal is over 25kg, set the pulse counter to 3.
Do not aim the detector at stairways that can be climbed by an animal.
Avoid a location where an animal can come within 1.8m of the detector by climbing on furniture, boxes
or other objects.
Installation Instructions
1. Open the housing. To do so, slide the detector up while gently pressing it and detach it from the
mounting bracket (see Figure B- 2). Insert a screwdriver in the release slot (see Figure B- 2, position 1) ,
turn the screwdriver 90º to release the cover.
Note: Do not touch the face of the PYRO sensor.
2. Apply battery power. To do so, open the battery compartment door on the back cover (see Figure B- 2,
position 2), then remove the isolator that separates the battery from the contacts on the battery holder.
Close the battery compartment door.
3. Place the Mode jumper over pins 2 & 3 (Radio Mode); the LED flashes.
Note: Install the Mode jumper only after applying battery power.
4. Set the receiver to Registration mode and wait for the receiver to indicate that the transmitter has been
registered successfully. Write the number of the zone and the transmitter number (if applicable) on the
sticker provided. Affix the sticker inside the front cover for future reference.
Note: Alternatively, the EL-2745/EL-2745PI can be registered to the receiver by manually entering the
transmitter's serial number.
5. Remove the jumper and place it over one pin for storage – see Mode Jumper Safeguard.
6. Place the detector at the appropriate mounting height (2.2 m/6.6 ft is recommended for maximum pet
immunity) and test the transmitter from the exact mounting position before permanently mounting the
unit.
Note: If you choose mounting height other that recommended 2.2m (which is not advised), please perform a
walk test to check the lens coverage. The recommended mounting height is the best in terms of
detection area
7. Knock out the mounting holes and attach the mounting bracket to the wall.
8. If using the rear tamper switch, insert a screw into the rear tamper mounting hole located in the center
of the bracket (See Figure B- 2, position 3). When the bracket is removed from the wall, the screw
causes the tamper release to break away from the bracket and the rear tamper switch is released.
9. Replace the front cover. Align the pins on the mounting bracket with the slots on the detector's base
(see Figure B- 2, positions 4 & 5), attach the EL-2745/EL-2745PI to the bracket and slide it down while
gently pressing it to fit to its place, then attach the screw provided in the detector kit to the bottom of
the mounting bracket (see Figure B- 2, position 6).
Operation and Adjustment
Warm-up Time
The detector will need to warm up for the first 90 seconds after applying power.
Pulse Counter
The pulse counter determines the amount of beams that need to be crossed before the sensor will produce an alarm.
The available options are 1, 2, 3 or Adaptive pulse count. Using the Adaptive pulse count feature, the detector chooses
