11 Internet Options (Relevant to Ethernet/GPRS & ELAS Configuration)
11. Internet Options (Relevant to Ethernet/GPRS &
ELAS Configuration)
The following options concern the configuration of the GPRS and Ethernet Communication Modules. In most cases, the
Internet options will be pre-programmed as defaults and you will not be required to change any of the settings apart
from the CPID and password for each customer.

11.1. ELAS Connection Parameters

The following parameters, required to connect Control System to ELAS, are set by ELAS administrator.
11.1.1. XML Proxy IP
To edit the XML Proxy IP:
1. From the Programming menu, select Communications, Internet, XML Proxy IP [9571].
2. Enter the XML Proxy IP provided by your ELAS administrator. Use the "1" key to enter ".", key to
insert and the key to delete one character at a time. Press
11.1.2. XML Proxy Port
To edit the XML Proxy Port:
1. From the Programming menu, select Communications, Internet, XML Proxy Port [9572].
2. Enter the XML Proxy Port provided by your ELAS administrator. Use the "1" key to enter ".", key to
insert and the key to delete one character at a time. Press

11.2. Control System Parameters

The following parameters, required to connect Control System to ELAS, should be provided by your ELAS
administrator.
11.2.1. CP ID
To edit the Control System ID:
1. From the Programming menu, select Communications, Internet, CP ID [9573].
2. Enter the unique Control System ID provided by your ELAS administrator to connect the Control
System to ELAS. Use the "1" key to enter ".", key to insert and the key to delete one character at a
time. The ID length must be six up to sixteen characters. Press
11.2.2. CP Password
To edit the Control System Password:
1. From the Programming menu, select Communications, Internet, CP Password [9574].
2. Enter the Control System Password provided by your ELAS administrator to connect the Control
System to ELAS. Use the "1" key to enter ".", key to insert and the key to delete one character at a
time. The password length must be six up to sixteen characters. Press
11.2.3. ELAS Connection on/off
To enable/disable ELAS connection option:
1. From the Programming menu, select Communications, Internet, ELAS Connect [9575].
2. Select Enabled or Disabled.

11.3. GPRS Network Parameters

The following parameters, required to program your GPRS connection, should be provided by the cellular provider.
11.3.1. APN
To edit the APN name of your GPRS connection:
1. From the Programming menu, select Communications, Internet, GPRS Options, APN [95761].
2. Enter the APN name provided by the cellular provider. Use the "1" key to enter ".", key to insert and
the key to delete one character at a time.
iConnect Installation Manual
when finished.
when finished.
when finished.
when finished.
77
