Specifications

General
Zones: 32 wireless zones (1 transmitter per zone), 1
hardwire zone (Zone 33), or zones 1 – 8 as wired zones,
zones 9 – 32 as wireless and 1 hardwire zone (Zone 33).
Wireless Keyfobs: 19 (Controlled or Non-controlled)
Wireless Keypads: up to 4, including one way/EL-2640/EL-2724
Hardwire LCD Keypads: 3
Repeaters: 4
Smartkeys: 16 (Controlled or Non-controlled)
Wireless Siren: 1 (1-way or 2-way)
User Codes: 32
Arming Methods: Full, Part or Perimeter; for partitioned
systems: Full, Partition 1, Partition 2
Event Log: 1022 event capacity, time and date stamped
Weight: 1.350g
Dimensions: 270 x 222 x 50mm
Communications
Event Reporting Accounts: up to 6, including Central Station,
Follow-Me, and Voice .
Telephone Numbers: 6
Callback, Service Call, 5 speed dial numbers.
Communication Interface
Ethernet.
Home Automation
Control Medium: Power-line carrier
Protocol: X10
HA Units: 16 individually addressed
Power connection to the unit should be according to the national electrical code for
!
permanent installation.
The power supply should be fed from a readily accessible disconnect device.
If the unit is permanently wired to the mains power, use a 2-pole disconnect device (15A max.)
and the wires should be min. 0.75mm
If the mains power is connected with a plug, the plug should be indicated as the disconnecting
device and the socket shall be max. 2m from the Control System.
Batteries shall be provided by a distributor and replaced by authorized service personnel.
The backup battery pack should be replaced every five years.
Batteries should be stored in a cool, dry place.
1.3.

System Overview

The iConnect Control System is a full-featured wireless control system that is expected to provide a solution to the
needs of most residential installations. This system has been developed based upon a design concept geared towards
easy installation and use. With this in mind, the user interface is based on a simple, menu-driven model that suits the
essential requirements of both the user and installer alike. You can program the iConnect Control System on-site using
the on-board LCD keypad or PC, or off-site via a PC using local programming option of the Remote Programmer.
The system offers GPRS and Ethernet network connectivity, providing high-speed central station reporting via a GPRS or
Ethernet interface. The Electronics Line Application Server (ELAS) handles all communication between the system, service
providers and web users enabling monitoring and control to be performed via the Web. Backup communication is carried
out by Communication module via PSTN or GSM.
Central station communication and remote parameters programming and maintenance employ Ethernet, GPRS, GSM or
standard PSTN communication. SMS messaging provides an innovative method used for both central station and Follow-
Me user monitoring. Additionally, SMS messages can be sent to the Control System enabling the user to send commands to
the system from anywhere on the planet.
The Control System's home automation capabilities provide a wealth of features. The Home Automation module interfaces
with X10 units over the powerline network and grants the user appliance control via a number of different media.
*
* The measurements are with fully charged battery. AC current was measured on fuse F1 and DC current was measured on fuse F2.
2
event reporting accounts,
Options: GPRS, GSM,
2
in a conduit of at least 16mm.
Receiver
Type: Super-heterodyne, fixed frequency
Frequency: 418MHz, 868.35, 433.92 (optional).
Data Encryption: SecuriCode™
*
Electrical
Power Input: 230VAC, 50Hz
AC Current Consumption (GPRS Configuration): 30mA
(alarm), 17mA (standby)
AC Current Consumption (Ethernet Configuration): 35mA
(alarm), 17mA (standby)
DC Current Consumption (GPRS Configuration): 280mA
(alarm), 130mA (standby)
DC Current Consumption (Ethernet Configuration): 330mA
(alarm), 135mA (standby)
Maximum Auxiliary Output Current Rating : 50mA
Battery low: below 7.15V
Backup Battery Pack: 1 x 7.2V/1.8Ah Part No. BT5780
(6 x 1.2V Ni-MH rechargeable cells, size AA)
The maximum charging current for the BT-5780 is 5.4A
RP
For
PSTN, mandatory.
Fuse Ratings: 63mA/250V for 230VAC – Part No. EF1063,
PGM Relay Output Contact Rating: 100mA (max. load)
Built-in Siren: 93dB @ 10ft
Tamper Switch: N.C.
Operating Temperature: 0-60°C /32-140°F
Complies with EN-50131-3 Grade 2 Class II
Power Supply Type A
EN-50131 standard, 1.8Ah
