an AC Loss Delay to be between 1 and 255 minutes after the system first senses the AC loss condition. Alternatively
you can program a random AC Loss Delay.
The AC Restore message is also sent using the same method described above. AC Restore is reported only if the AC
Loss report was sent.
To program the AC Loss Delay:
1. From the Programming menu, select System Options, AC Loss Delay [9405].
2. Enter a delay time (001-255 minutes) or enter 000 if you require the system to choose a random AC
Loss Delay, then press
9.5.1. Random AC Loss Delay
In the event of AC loss, an event message is sent to the central station between 15 and 30 minutes after the AC loss
condition is sensed. The system chooses this delay at random in order to prevent the central station being inundated by
simultaneous AC Loss reports in the event of a regional power cut.
9.6.

Display Options

The following options relate to the information the system displays on the front panel keypad and the LCD keypad.
9.6.1. Arm Status Display
The Arm Status Display includes the current arm status and any trouble conditions that may exist within the system.
You can program the system to display this information at all times, only for two minutes, or only for 30 seconds after
arming or disarming the system.
To program the Arm Status Display options:
1. From the Programming menu, select System Options, Display, Arm Status [94061].
2. Select Display Always, Display 2 Min, or Display 30 sec.
To meet the requirements of the EN50131 standard, the Arm Status Display must be set to
30 seconds.
9.6.2. Banner
The Banner is the 16-character text that you can program to appear on the top row of the LCD display. This text replaces
the arm status if it is programmed to display for two minutes or 30 seconds only – see p.58, 9.6.1 Arm Status Display.
To edit the Banner text:
1. From the Programming menu, select System Options, Display, Banner [94062].
2. Edit the Banner text using the alphanumeric keypad, then press
Note: The system never displays the Banner text if the Arm Status Display option is programmed as Always.
9.6.3. Time/Date Format
This option determines the format in which the time and date are displayed.
The following options are available:
DD/MM/YY, 24Hr
DD/MM/YY, 12Hr
To program the Time/Date format:
1. From the Programming menu, select System Options, Display, Time Format [94063].
2. Select the required format from the options available.
9.6.4. Supervision Loss Indication
This option enables you to select whether the system trouble display will indicate transmitter supervision loss to
the user.
To program the Supervision Loss Indication setting:
1. From the Programming menu, select System Options, Display, SV Loss Ind. [94064].
2. Select Enabled or Disabled.
58
.
.
MM/DD/YY, 24Hr
MM/DD/YY, 12Hr
