3.6.

System Status LEDs (LED Top Cover)

The System Status LEDs show System Troubles, Open Zone condition, and Power Status.
OK
LED
(green)
Off
Green On
Flashing
Table 3-7: Armed LED Indication
!
LED Status
(yellow)
Off
Yellow On
Yellow Flashing
(slow)
Yellow Flashing
(fast)
Yellow Intermittent
On/Off
Table 3-8: Power LED Indication
Note: Alarm indication is not displayed after a silent panic alarm.
3.7.

Arming Status LEDs (LED Top Cover)

In unpartitioned systems, meaning of the three arming Status LEDs is: Full, Part, and Perimeter. In partitioned systems,
meaning of the three arming Status LEDs is: Full, Partition 1, and Partition 2 respectively.
Arming LED
Status
Off
Red Flashing
Green On
All the three Arm
Status LEDs are
flashing red
Table 3-9: Arm Status LED Indication
3.8.

Front Panel Keypad (LED Top Cover)

The LED Top Cover keypad is used to activate the three basic end user functions listed in the following table. If your
Control system is configured with an LED Top Cover, use a hardwire LCD keypad to perform any function that
requires keypad/ LCD interface.
20
Meaning
Status
System cannot be armed.
The system is ready for arming.
Open Zone. Check that the relevant entrances are secured (i.e. e. windows and doors are
closed and no movement is detected by the sensors within the protected area).
Meaning
System Power Status is OK and there is no trouble condition.
System Trouble.
Backup battery low or low battery from transmitters.
AC loss.
System Trouble in addition to AC loss/Low Battery.
Meaning
The corresponding arming method is not active. In partitioned systems, the
corresponding partition is disarmed. If all the three LEDs are off, the system is disarmed.
The exit or entry delay is counting down for this arming mode.
The System is armed using the arming method shown by this LED. In partitioned
systems, the corresponding partition/whole system is armed.
An alarm has occurred. Alarm indication is cleared the next time that an arming
sequence is initiated.
