3 Basic System Operation
3.3.

Front Panel Keypad and Hardwire LCD Keypad

The alphanumeric keypad on the front panel enables you to perform various operation and programming tasks. Apart
from the regular functions of a standard alphanumeric keypad, Full, Part, and Perimeter arming, Home Automation
and PGM control, the keypad offers a number of special functions.
In addition to the front panel keypad, you can install up to three, individually addressed, hardwire LCD keypads. The
layout of the hardwire LCD keypad is similar to the front panel keypad and most of the functionality is identical – see
p. 17, Table 3-3.
Note: See p. 23, 3.10.2 Arming Keys for Front Panel arming keys functionality.
Key
1
0
/ FULL
/ PART
Table 3-3: Front Panel Keypad and Hardwire LCD Keypad Functions
Hardwire Keypad LEDs functionality is identical to those of the Front Panel keypad – see p. 16, 3.2 Front Panel System
Status LEDs (LCD Top Cover).
iConnect Installation Manual
Special function
Used to enter symbols in descriptor editing.
Used to enter symbols in descriptor editing.
Used to cancel the current selection.
Used to return to the previous menu level.
Used to enter Menu mode.
Used to select the current menu item.
Used to signify the end of an entered value.
Toggles status in Zone Bypass/Unbypass function.
Used to switch Home Automation units or PGM on / Full arming.
In descriptor editing, used to insert a space before the current character
In phone number editing, used to enter "T", ",", "P", "+", "*", "#".
In account number editing, used to enter Hexadecimal digits (A-F).
Toggles item descriptors and default names.
In the event log, toggles the time/date stamp.
Toggles AM and PM when setting the time in 12hr format.
Used to switch Home Automation units or PGM off / Part or Perimeter arming (partition 1 or
partition 2 arming).
In descriptor and phone number editing, used to delete the current character.
Used to Part arm or Perimeter arm the system. In partitioned systems, used to arm partition
1 and partition 2 separately.
Used to scroll backwards in the current menu level.
For Global Chime and Message Center features, used to access shortcuts.
+ (Global Chime shortcut)
+ (Record Message shortcut, front panel keypad only)
+ (Play Message shortcut, front panel keypad only)
Used to scroll forwards in the current menu level.
During standby, used to scroll through the list of system trouble conditions.
