4 Advanced System Operation
To activate cancel report:
From the main menu, select Cancel Report. [1].
4.3.

Zone Bypassing/Unbypassing

When a sensor is bypassed, it is ignored by the system and does not generate an alarm when triggered.
To bypass or unbypass a sensor:
1. From the Bypass Zones menu, select Bypass/Unbyp. [21].
2. Using the arrow keys, scroll to the sensor you want to bypass or unbypass.
3. Press to change the bypass status.
4. Press ; Save Changes? is displayed.
5. Press to confirm the changed bypass status.
To unbypass all sensors (In partitioned systems, Master Code is required):
1. From the Bypass Zones menu, select Unbypass All [22].
2. Press ; all sensors are unbypassed.
Note: All bypassed zones are automatically unbypassed when the system is disarmed.
A Fire zone cannot be bypassed.
In partitioned systems, to bypass/unbypass a zone, you must have a user code assigned to the same
partition as the zone is.
4.4.

User Codes

The Control System supports up to 32 individual user codes. Each of these codes is four digits long. Most system
operations require you to enter a valid user code. The ability to perform an operation is defined by your user code's
authorization level. These authorization levels are pre-defined for each code as explained below.
Notes: Codes 1-29 can be edited only by the Master code.
The Installer code, Guard Code and the Central Station TWA Code can be edited only by the installer.
Code 1: Master Code
The Master code is the highest user authorization level. With the Master code, you can edit all other user codes except
the Installer code, the Guard code and the Central Station TWA Code. Additionally, the Master code grants access to
the Event Log, the Service menu and Home Automation Schedule programming. The Master code is a "controlled"
code. Arming and disarming using this code causes the Control System to notify the central station with an
Arm/Disarm event message
Caution: The default Master code is 1234. Change this code immediately after installing the system!
Codes 2-19: Controlled Codes*
When you use a controlled user code for arming and disarming, the Control System notifies the central station with an
Arm/Disarm event message.
Codes 20-25: Non-controlled Codes
Non-controlled codes do not cause the Control System to send Arm/Disarm event messages to the central station. The
Control System sends a Disarm message only if you use this code to disarm the system after an alarm occurrence.
Codes 26-27: Limited Codes
A Limited code enables the user to issue a code that is valid for one day only. This code automatically expires 24 hours
after it has been programmed. These codes are "controlled" in that their use for Arm/Disarm is notified to the central
station.
Only if arm/disarm reporting is enabled during System Programming
*
iConnect Installation Manual
* . In partitioned systems, Master Code is always assigned to both partitions.
