2. Enter time (003-255 minutes or 000 to disable), then press

10.8. TWA Event Report Options

10.8.1. TWA Event Report
The TWA Event Report is an event report that is sent to the central station to indicate that Two-Way Audio
communication is about to commence. If enabled, the system sends the Contact ID event code 606000 before
establishing Two-Way Audio communication.
Note: This option affects Contact ID only. If using SIA, a TWA event report is always sent together with the
TC/VM timeout, regardless of the configuration for this option.
To program the TWA Event option:
1. From the Programming menu, select Communications, Comm. Options, TWA Event Rept. [95415].
2. Select Enabled or Disabled.
10.8.2. TWA Time Report
If the TWA Time Report option is enabled, the last three digits of the TWA Event Report are replaced with the amount of
seconds programmed for the TC/VM Timeout – p. 72, 10.6.11 Telecontrol/Vocal Message Timeout. For example, if the
TC/VM Timeout is programmed as 120 seconds, the Contact ID event code to be sent for the TWA Event Report will be
606120.
To program the TWA Time Report option:
1. From the Programming menu, select Communications, Comm. Options, TWA Time Rept. [95416].
2. Select Enabled or Disabled.
10.8.3. Caller ID Mode and Incoming Number
Incoming number feature allows the installer to program up to three high-priority telephone numbers so that the user
would be able to use Telecontrol/2-way audio over GSM during a GPRS session. If the Control System recognizes the
incoming call as a high-priority call, the GPRS session will be suspended. Caller ID Mode option allows selection of the
ID Mode applicable to your specific network.
Notes: Caller ID Mode option affects PSTN too.
There is no Caller ID Fail trouble for the incoming calls over GSM.
To choose the applicable Caller ID Mode option:
1. From the Programming menu, select Communications, Comm. Options, CallerID MODE. [95417].
2. Choose the mode applicable to your PSTN network (Bellcore, British Telecom, Japan). You can also
disable Caller ID by choosing Caller ID Disable.
To program/edit the Incoming Number:
1. From the Programming menu, select Communications, Comm. Options, Incoming #. [95418].
2. Select the telephone number you want to edit (1-3).
3. Enter up to 16 digits. Use the key to enter "*", "#", "," (pause), "T" (switch to DTMF tone dialing), "P"
(switch to pulse dialing) or "+" (international code). Use the key to delete one character at a time.
Press when you have finished editing.
10.8.4. Remote Firmware Update
Electronics Line 3000's Remote Firmware Update feature allows the Installer or service provider to perform firmware
update from a remote PC using WEB communication.
Note: Before performing the firmware update, locally disarm the system and make sure that there are no AC
LOSS or BATTERY LOW conditions.
To setup the firmware update mode:
1. From the Programming menu, select Communications, Comm. Options, Rem. SW Update [95419].
2. Select the Remote Firmware Update mode from the following table:
Access option
Always Enable
74
Description
Update is always possible.
.
