7 Devices
When installing 2-way sirens, the wireless siren also includes a transmitter that must be registered to the Control
System. For information on registration and deletion, see p. 43, 7.2.1 Registering Wireless Devices, and p. 43, 7.2.2
Deleting Wireless Devices.
7.7.1. Wireless Siren Type
The Control System supports both 1-way and 2-way wireless sirens. For this feature to function correctly, you must
define the wireless siren type in programming.
The following options are available:
1-Way Siren – if using the WSM or EL-2623 wireless siren.
2-Way Siren – if using the EL-2626AC wireless siren.
2-Way Siren/Kpd – if using the EL-2626AC wireless siren and the 2-way EL-2724 Wireless Terminal
To program the wireless siren type:
1. From the Programming menu, select Devices, Siren, WL Siren Type [9152].
2. Select a siren type or No WL Siren if no siren is installed.
7.7.2. Wireless Siren Delay
The Wireless Siren Delay is the period of time during which the wireless siren is not sounded after an alarm is triggered by
Normal, Follower or 24Hr zones. This feature is implemented only when the system is not fully armed. During the
Wireless Siren Delay, the Control System's built-in siren is sounded but the alarm report is not sent until the delay has
expired. This gives the user enough time to disarm in the event that the alarm was accidentally triggered during Part or
Perimeter arming. If the user disarms the system during the Siren Delay, an alarm event is not reported to the central
station.
To program the Wireless Siren Delay time:
1. From the Programming menu, select Devices, Siren, WL Siren Delay [9153].
2. Enter a Siren Delay time (00-63 seconds), then press
7.7.3. Siren Cut-Off
The Siren Cut-Off is the period of time the sirens are activated after an alarm has occurred. You may program a Siren
Cut-Off time in the interval between ten seconds to twenty minutes.
To program the Siren Cut-Off time:
1. From the Programming menu, select Devices, Siren, Cut-Off [9154].
2. Enter a Siren Cut-Off time MM:SS (00:10 - 20:00), then press
7.7.4. Wired Siren
When the system generates an audible alarm, both the wired built-in siren and the wireless siren are sounded. This
option allows you to disable the alarm from the Control System's built-in siren. If disabled, the Control System's built-
in siren may still be used to sound arm/disarm and entry/exit tones.
To program the Wired Siren option:
1. From the Programming menu, select Devices, Wired Siren [9155].
2. Select Enabled or Disabled.
7.7.5. Camera Trigger
Always enable this option when working using the ELAS-V cameras. Each time a detector detects intrusion, the ELAS-
V camera will be triggered to generate a video clip.
To program the Camera Trigger Option:
1. From the Programming menu, select Devices, Siren, Camera Trigger [9156].
2. Select Enabled or Disabled.
7.8.

Smartkeys

Smartkeys enable the user to arm and disarm the system without needing to enter a code. You can register up to 16
smartkeys to the system. For information on registration and deletion, see p. 43, 7.2. Wireless Devices. For descriptor
editing, see p. 43, 7.1 Device Descriptors.
Note: Smartkey function existence is model dependant.
