Appendix B: Transmitter Installation
a. On the LCD programming keypad, press
display.
Figure B- 32: LCD Programming Keypad
b. Press
c. Press
c. Confirm registration to the Control System as follows:
d. When Save? appears on the Control System's LCD display, press
9. Test the repeater from the required mounting location before permanently mounting the unit.
10. Mount the base to the wall using four screws and replace the front cover.
Registering Transmitters to the Repeater
You can register up to eight transmitters to the EL-2635 repeater.
Figure B- 33: Transmitter Registration Procedure
Figure B- 35: TX List Procedure
Caution: Do not register the same transmitter to more than one repeater.
To register transmitters to the repeater:
1. On the LCD programming keypad, press
2. Press ; New Device appears on the display.
3. Press again; Transmit 1 appears on the display.
4. Send two transmissions from the device you want to register.
5. When the transmitter number and Save? appear on the display, press
Note: The EL-2635 repeater automatically allocates a transmitter number to each newly registered device.
Write this number and the zone number on the sticker provided with the sensor and stick it inside the
transmitter's cover for future reference.
iConnect Installation Manual
.
again.
until 4. TX Register appears on the display.
until 5. STS Transmit appears on the
Figure B- 34: Transmitter Deletion Procedure
Figure B- 36: TX Test Procedure
to confirm registration.
.
