Appendix B: Transmitter Installation

Transmitter Specifications

The technical specifications for the transmitters that appear in this appendix are listed below. All transmitters are
available in 868.35, or 433.92MHz (optional) FM frequencies.
EL-2600 PIR
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 30mA (transmission) 6µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 46 x 46ft (14 x 14m)
Pulse Count: 1, 2 or 3 Jumper Selectable
LED Indicator: Jumper Selectable
Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: 14 to 140°F (-10 to 60°C)
Fire Protection: ABS Plastic Housing
Dimensions: 4.33"H x 2.36"W x 1.77"D (110 x 60 x 45mm)
EL-2600PI PIR
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 30mA (transmission), 6µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 39.3 x 39.9ft (12 x 12m)
Pulse Count: 1, 2 or 3 Jumper Selectable
LED Indicator: Jumper Selectable
Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: 14 to 140°F (-10 to 60°C)
Fire Protection: ABS Plastic Housing
Dimensions: 4.33"H x 2.36"W x 1.77"D (110 x 60 x 45mm)
EL-2645 PIR
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 30mA (transmission) 12µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 46 x 46ft (14 x 14m)
Pulse Count: 1, 2, 3 or Adaptive
LED Indicator: Selectable
Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: 14 to 140°F (-10 to 60°C)
Fire Protection: ABS Plastic Housing
Dimensions: 4.33"H x 2.36"W x 1.77"D (110 x 60 x 45mm)
EL-2645PI PIR
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 30mA (transmission), 12µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 39.3 x 39.9ft (12 x 12m)
Pulse Count: 1, 2, 3 or Adaptive
LED Indicator: Selectable
Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: 14 to 140°F (-10 to 60°C)
Fire Protection: ABS Plastic Housing
Dimensions: 4.33"H x 2.36"W x 1.77"D (110 x 60 x 45mm)
EL-2745 PIR
Antenna: Built-in Internal Whip
Frequency: 868.35MHz*, 433.92MHz, or 418 MHz
Power: 3.6V ½ AA Lithium Battery
Caution: Fire, explosion and severe burn hazard! Do not
recharge, disassemble or heat above 100°C (212F).
Current Consumption: 30mA (transmission) 12µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 14 x 14m
Pulse Count: 1, 2, 3 or Adaptive (selectable)
LED Indicator: Selectable
Digital Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: -10 to 60°C
Fire Protection: ABS Plastic Housing
Dimensions: 110 x 62 x 50mm
iConnect Installation Manual
Screw recommended: ST 2.9x22 DIN 7981 (ISO 7049)
* Complies with EN-50131 2-2 Grade 2
Class II, Power Supply Type C
EL-2745PI PIR
Antenna: Built-in Internal Whip
Frequency: 868.35MHz*, 433.92MHz, or 418 MHz
Power: 3.6V ½ AA Lithium Battery
Caution: Fire, explosion and severe burn hazard! Do not
recharge, disassemble or heat above 100°C (212F).
Current Consumption: 30mA (transmission)/12µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 12 x 12m
Pulse Count: 1, 2, 3 or Adaptive (selectable)
LED Indicator: Selectable
Digital Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: -10 to 60°C
Fire Protection: ABS Plastic Housing
Dimensions: 110 x 62 x 50mm
Screw recommended: ST 2.9x22 DIN 7981 (ISO 7049)
* Complies with EN-50131 2-2 Grade 2
Class II, Power Supply Type C
EL-2601 Magnetic Contact/EL-2602 Universal
Transmitter
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 25mA (transmission) 10µA (standby)
Loop Input Voltage Range for EL-2602: 0-15VDC/AC (peak to peak)
RFI Immunity: 40V/m
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 2.5"H x 1.18"W x 0.9"D (65 x 30 x 25mm)
EL-2603 Smoke Detector
Antenna: Built-in Internal Whip
Current Consumption: 30mA (transmission), 20µA (standby)
Power: 9V Alkaline Battery
RFI Immunity: 40V/m
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 5.43"H x 4.65"W x 1.73"D (138 x 118 x 44mm)
EL-2603EN Smoke Detector
Antenna: Built-in Internal Whip
Frequency: 868.35MHz FM
Power: 9V Alkaline Battery
Current Consumption: 27mA (transmission) 10
Humidity Range: 15%-95% RH (non-condensing)
LED Indication: Power, Trouble and Alarm (Red) RF
transmission (Blue)
Alarm: 85dB @ 3m
RFI Immunity: 10V/m
Operating Temperature: 0-55°C
EL-2606 Glassbreak Sensor
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 25mA (transmission)
30µA (standby)
Warning: Fire, explosion and severe burn hazard! Do not
recharge, disassemble or heat above 100°C (212 °F).
Microphone: Omni-directional electret
Maximum Range: 6m (plate, tempered, laminated and
wired glass)
3.65m (armor-coated glass)
RFI Immunity: 20V/m
Operating Temperature: 32 to 122°F (0 to 50°C)
Dimensions: 3.14"H x 4.25"W x 1.69"D (80 x 108 x 43mm)
EL- 2661 Flood Sensor
Antenna: Built-in Internal Whip
Frequency: 868.35, 433.92 or 418MHz FM
Power: 3.6V ½ AA Lithium Battery BT5055
A (standby)
μ
