10 Communications

10. Communications
This section explains how to determine the way the Control System communicates via the GPRS, GSM, Ethernet and
PSTN modules to the Central Station and to the user.

10.1. System Reporting

The Control System supports six report accounts for central station and user reporting. Each account has its own
telephone number and communications options.
The first account is always primary, every other account (that is not a voice report) may be chosen as primary or
backup. Each primary account may have one, several, or no backup accounts at all. The order of calling is the
following:
1. First, the Control System calls all the primary accounts, in ascending order. In case a primary account
report fails, the Control System calls the backup accounts.
2. After that, the system calls the Voice Report accounts – see p. 67, 10.3 Vocal Message Dialer.
Note: If account is set as Backup after Voice Report account, reports to this account will be discarded. It is
Installer responsibility to program primary and backup accounts in proper order. To ensure proper
functionality, Installer will not be able to set Account 1 as Voice Report or Backup.
10.1.1. Telephone Number
To edit an account's telephone number:
1. From the Programming menu, select Communications, Accounts [951].
2. Select the account you want to program (1-6).
3. From the account's sub-menu, select Phone Number [#1].
4. Enter up to 16 digits. Use the key to enter "*", "#", "," (pause), "T" (switch to DTMF tone dialing), "P"
(switch to pulse dialing) or "+" (international code). Use the key to delete one character at a time.
Press .
10.1.2. Protocol
To program an account's communication protocol:
1. From the Programming menu, select Communications, Accounts [951].
2. Select the account you want to program (1-6).
3. From the account's sub-menu, select Protocol [#2].
4. Select a protocol from the options available.
Notes: Set account 1 to IP protocol if you use GPRS communication.
Account number 3 is designed for use with the Follow me feature. It is the only telephone number that
can be programmed by the user.
10.1.3. Communication Interface
For each account, you can choose whether the system employs PSTN, GSM, Ethernet (LAN), or GPRS communication.
To program an account's communication interface:
1. From the Programming menu, select Communications, Accounts [951].
2. Select the account you want to program account (1-6).
3. From the account's sub-menu, select Interface [#3].
4. Select PSTN, GSM, LAN, or GPRS (GPRS or LAN is used only for the first account).
10.1.4. Two-Way Audio
The Two-Way audio option determines whether Two-Way Audio is enabled for the account. For further information,
see p. 39, 5.2.2 TWA Alarm Reporting.
To program the Two-Way Audio option for an account:
1. From the Programming menu, select Communications, Accounts [951].
