1. INTRODUCTION

1.1 Model Names and Basic Specifications

Model
FC2250-60VC
FC2250-120MG
FC2250-120ES
FC2250-120VC
FC2250-180ES
FC2250-180VC

1.2 Standard Accessories

Item
Power cable
Cutter pen set
Water based fiber-tip pen
Sheet holder plates
Hexagon wrench
Height adjustment plates
Durable flexible hose
Hose band
Vacuum pump installation base For VC models only
USB cable
CD-ROM
CAUTION
• The vacuum pump is an option. It is not provided with the VC models.
• Make sure that the vacuum pump used with a VC model is affixed with either a label showing compliance
with the relevant safety standard or with the CE marking.
FC2250-UM-251-9370
Media hold down method
Vacuum suction
Magnetic
Electrostatic adhesion
Vacuum suction
Electrostatic adhesion
Vacuum suction
PPA31-CB15B, CB15U-2SP, CB15U-K30-5SP
KF552-BK
For MG models only (2 large, 2 medium, 4 small)
For M4 bolts
10 mm, 4 mm height
For VC models only, 1.5 m to 5 m (can expand/contract)
Connection bore diameter: Ø38mm (-60), Ø58mm (-120/180)
For VC models only, Ø38mm (-60), Ø58mm (-120/180)
User's manual, Driver, other software
Cutting area
610 (X) x 920 (Y) mm
1200 (X) x 920 (Y) mm
1740 (X) x 920 (Y) mm
Description
1-1
1. INTRODUCTION
Q'ty
1
1 set
1
1 set
1
1 of each
1
2
1
1
1
