Data

DataTrack and DataTrack Backbone provide integrated wiring for DMX-512A (ANSI E.1.11)
and bidirectional RDM (ANSI E1.20-2010) control signals. The electrical specifications of these
DMX512A and RDM standards are based on ANSI/TIA/EIA-485-A-1998.
DMX512A standards require a continuous daisy-chain data-link topology with a terminating
switch or resistor with a value of 100–120 ohms to eliminate ringing and signal reflection. No
"Tees" or "Stars" are permitted.
Wire used for bringing the DMX signal into the track system must be Belden 9729 or
equivalent with shield connected to ground at one end, preferably the signal source.

Load Capacity

DataTrack and DataTrack Backbone distribute one or two 120V circuits (230V for EUTRAC
systems), up to 16A on a 20A circuit. Each circuit has an independent neutral for individual
control and a common ground.
• Maximum Feed: 2 x 20A branch circuits
• Maximum Load: 2 x 16A (2 x 1920W at 120V)
• Maximum Load for EUTRAC systems: 2 x 16A (2 x 4600W at 230V)
• Supply Wiring: 12 AWG (2.5 mm
The DataTrack Backbone fixture adapter has a load capacity of 300W (120V supply), or 600W
(230V supply) for EUTRAC systems.

Document Conventions

This document uses the following conventions to draw your attention to important
information.
Note:
CAUTION:
WARNING:
WARNING:
Please email comments about this manual to:
2
2
) feed wires
Notes are helpful hints and information that is supplemental to the main text.
A Caution statement indicates situations where there may be undefined or
unwanted consequences of an action, potential for data loss or an equipment
problem.
A Warning statement indicates situations where damage may occur, people
may be harmed, or there are serious or dangerous consequences of an action.
RISK OF ELECTRIC SHOCK! This warning statement indicates situations where
there is a risk of electric shock.
