ETC DataTrack Planning And Installation Manual page 60

Straight Locking Joint
2.05 in
52 mm
56
10 in
254 mm
DataTrack/DataTrack Backbone System Planning and Installation Manual
• Connector for two pieces of Backbone
where the track is joined by an
electrical straight coupler (see
Straight Coupler page 38
on
DataTrack Backbone
Color Model Number
N/A DTB-LJ
Related Accessories: DataTrack
Electrical Straight Coupler
Color Model Number
Black EDTRSC
White EDTRSC-1
Silver EDTRSC-5
1.71 in
43.5 mm
0.5 in
12.7 mm
1.37 in
34.9 mm
Electrical
)
