ETC DataTrack Planning And Installation Manual page 56

T-coupler Housing
5.05 in
128.2 mm
52
3.46 in
88 mm
5.05 in
128.2 mm
11.81 in
300 mm
• Housing for T-coupler (see
page 35
Color
Black
White
Silver
Custom
Related Accessories: DataTrack T-coupler
Ground
Inside
Right
Inside
Left
Outside
Right
Outside
Left
3.23 in
82.1 mm
1.71 in
43.5 mm
DataTrack/DataTrack Backbone System Planning and Installation Manual
T-coupler
)
DataTrack Backbone
Model Number
DTB-T-BLK
DTB-T-WHT
DTB-T-SLV
DTB-T-CST
Color Model Number
Black EDTRTC-GIR
White EDTRTC-GIR-1
Silver EDTRTC-GIR-5
Black EDTRTC-GIL
White EDTRTC-GIL-1
Silver EDTRTC-GIL-5
Black EDTRTC-GOR
White EDTRTC-GOR-1
Silver EDTRTC-GOR-5
Black EDTRTC-GOL
White EDTRTC-GOL-1
Silver EDTRTC-GOL-5
on
.79 in
20 mm
