Wiring End Feeds

1: Strip ground wire and connect to a 0.25 in (6.35 mm) female quick disconnect terminal (not
supplied). Push terminal onto tap clamp at ground plate. Use provided green wire for connecting
between tap clamp and feed connector terminal.
2: Strip white Neutral 1 wire and connect to Neutral 1 terminal (N1) of feed connector. Clamp wire
using screw. See
3: Strip Hot 1 supply wire and connect to a 0.25 in (6.35 mm) female quick disconnect (not
supplied). Push onto the Line tap clamp on the overcurrent device.
4: Connect load from overcurrent device to track feed connector terminal (L1) using provided wire.
See Figure 17
5: Follow the same instructions for Neutral 2 and Hot 2.
Installation
Figure 17
.
CIRCUIT
BREAKER
CIRCUIT
BREAKER
Figure 17: End feed wiring
.
N1
L1
P E
L2
N2
