ETC DataTrack Planning And Installation Manual page 64

Pigtail Adapter
1.2 in
30.5 mm
60
• Provides data and power to fixtures mounted using a
• Includes a blanking plug (part number J1648) for fixtures
1.72 in
43.6 mm
1.37 in
34.9 mm
fixture hanger (see Fixture Hanger
Fixture Hanger for Emergency Lighting
that automatically terminate DMX (to ensure that the
DMX signal continues along the DataTrack data bus)
DataTrack Backbone
Connector
Black
®
PowerCON
White
connector
Silver
3.12 in
79.3 mm
DataTrack/DataTrack Backbone System Planning and Installation Manual
on page 58
page 59
on
Color Model Number
DTB-PTP-BLK
DTB-PTP-WHT
DTB-PTP-SLV
1.26 in
31.9 mm
1.37 in
34.9 mm
and
)
