Irideon
FPZ
User Manual
Rev A
Copyright © 2016 Electronic Theatre Controls, Inc.
All rights reserved. Product information and specifications subject to change.
Part Number: 7191M1200-1.0.0 Rev: A
Released: February 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Irideon FPZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ETC Irideon FPZ

Summary of Contents for ETC Irideon FPZ

  • Page 1 ™ Irideon User Manual Rev A Copyright © 2016 Electronic Theatre Controls, Inc. All rights reserved. Product information and specifications subject to change. Part Number: 7191M1200-1.0.0 Rev: A Released: February 2016...
  • Page 2 Electronic Theatre Controls, Inc. in the United States and other countries. All other trademarks, both marked and not marked, are the property of their respective owne rs. ETC intends this document, whether printed or electronic, to be provided in its entirety.

  • Page 3: Table Of Contents

    Table of Contents Introduction ....1 Specifications ....2 Basic Assembly .

  • Page 5: Introduction

    Introduction The Irideon FPZ takes the beauty and punch of the Source Four Mini beam and puts it into a fixture designed to work in any architectural environment. With built in zoom optics, three-plane shutters and a rotating barrel, the FPZ can create a sharp or soft focused light in any shape you need.

  • Page 6: Specifications

    • Long-life LED: 35,000 hours L70 LEDs lumen maintenance • Cree LED source -- Irideon FPZ 3000K: 80+ CRI -- Irideon FPZ 3000K Gallery: 90+ CRI -- Irideon FPZ 4000K: 80+ CRI -- Irideon FPZ 5000K: 80+ CRI • Beam edge continually adjustable Optical hard to soft •...

  • Page 7: Basic Assembly

    WARNING: When using the circuit selection lock, ensure the selected circuit is a constant power circuit. Dialing into a dimmable circuit may cause fixture damage that will void the ETC warranty. Adjustments Step 4: Focus the fixture. See on page 5.

  • Page 8: Addressing

    For runs of fixtures totaling more than 32 DMX devices, a DMX splitter will need to be used to split the DMX runs. When using RDM with track fixtures, ETC recommends connecting no more than 20 fixtures on a single run. Alternative DMX Addressing Functions Certain DMX addresses are reserved for special functions.

  • Page 9: Initial Power Up

    Control and configuration of the Irideon FPZ can be achieved over a DMX/RDM control network, or directly from a connected computer running appropriate software. When controlling the Irideon FPZ directly from a PC, a Gadget Interface or DMX/RDM gateway is required.

  • Page 10: Shaping The Beam

    Shaping the Beam The beam can be shaped using the four shutters or with a pattern. The Irideon FPZ has four shutters: left, right, top, and bottom. Each shutter can be pulled out or pushed in to create the desired beam shape.

  • Page 11: Rotating The Lens Barrel

    2mm Allen wrench (provided). Pattern Projection The Irideon FPZ has a pattern holder slot on the top side of the shutter barrel, in front of the shutter. It accommodates an E-size (37.5mm with a 25.4mm image area) pattern. The maximum pattern thickness that can be accommodated is 4mm (0.158”).

  • Page 12: Integrated Media Holder

    Integrated Media Holder The Irideon FPZ comes equipped with an integrated media holder, which is a metal frame used to hold color media (often referred to as gel) or diffusion in front of the lens. The media holder is equipped with a magnetic retaining clip that prevents the media from falling out.

  • Page 13: Cleaning The Glass Lens

    Cleaning the Glass Lens WARNING: Do not use ammonia-based or other harsh commercial cleaners. Clean lens only as directed. Commercially available glass cleaning agents should be avoided as they may contain ammonia, other harsh chemical detergents, or abrasive agents. These cleaners may damage the glass surface and the Anti-Reflective coatings.
  • Page 14 Rear Lens Front Lens Metal Front Shaft Casting Integrated Media Lens Adjustment Holder Knobs Light Block Bracket Three Screws...
  • Page 16 Service: (Asia) service@etcasia.com   Web: www.etcconnect.com Copyright © 2016 ETC. All Rights Reserved.  Product information and specifications subject to change. ETC intends this document to be provided in its entirety.  7191M1200-1.0.0 Rev A Released 2016-02  ...
