  • Page 1 ™ Source Four Zoom Assembly Guide...
  • Page 2 Electronic Theatre Controls, Inc.

  • Page 3: Table Of Contents

    Front lens assembly ..........16 Rear lens asembly ..........16 25º–50º lens tube assembly .........17 Gel frame endcap assembly ......17 Front lens assembly ..........17 Rear lens assembly ...........17 15º–30º and 25º–50º assembly instructions ....18 Cleaning glass lenses ...........19 Source Four Zoom Assembly Guide...

  • Page 4: 30º Final Assembly

    Figure 1 Figure 2 15º - 30º Final assembly Reference Part Description Quantity Number Number Required 7060A2030 15°-30° lens tube 7060A2020 Rear housing assembly, double clutch 7060A2408 Lamp socket assembly 7060A4008-01 Knob set with male insert 7060A4037 Handle, insulated rear HW5197 Screw, 1/4-20 x 5/8, black zinc HW2181...

  • Page 5: 50º Final Assembly

    25°-50° lens tube 7060A2020 Rear housing assembly, double clutch 7060A2408 Lamp socket assembly 7060A4008-01 Knob set with male insert 7060A4037 Handle, insulated rear HW5197 Screw, 1/4-20 x 5/8, black zinc HW2181 Screw, 6-32x3/4, black Taptite Source Four Zoom Assembly Guide...
  • Page 6 Figure 4 Lamp burner Lamp socket assembly assembly Reference Part Description Quantity Number Number Required 7060A3055 Housing, socket, casting, painted 7060A3057 Socket, light baffle casting, painted 7060A4007 Knob, X-Y, lamp set 7060A4008-02 Knob, Z, lamp set w/female insert 7060A4011 Bushing, cup 7060A3011 Hub, index, casting 7060A3012...

  • Page 7: Lamp Socket Assembly

    5. (Also see figure 12 on page 9.) Note: Do not install the screw if the fixture will be used with 77V lamps and ETC’s Dimmer Doubler. This screw prevents 77V lamps from being installed. 2. Insert the bolt (19) through the light baffle socket casting (2).
  • Page 8 10. Insert the knurled head screw (13) through the housing socket Figure 8 casting (1) as shown in figure 8. 11. Install the shorter green ground wire (24) with the prongs on the crimped connector toward the casting onto the screw. 12.

  • Page 9: Figure

    11. 21. Place the Tinnerman clip (26) over the retainer clip crossbar between the two hooks and press it down firmly until it snaps into place. Figure 12 Source Four Zoom Assembly Guide...

  • Page 10: Reflector Housing Assembly

    (4 required) (3 required) (2 required) (2 required) (4 required) (4 required) Figure 13 Reflector housing assembly Reference Part Description Quantity Number Number Required 7060A3054 Housing, reflector casting, painted black 7060A3006 Clip, reflector retainer 7060A4010 Bushing, gate 7060A3016 Plate, clutch 7060A3019 Spring, reflector support 7060A4015...
  • Page 11 Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth using alcohol or distilled water (alcohol is recommended). Warning: Do not use glass and window cleaners on the reflector. Chemicals in these cleaners will stain the reflector. Source Four Zoom Assembly Guide...

  • Page 12: Gate Housing Assembly

    Figure 18 Note: The bottom divider plate (4) (See detail to the right) has four dimples punched into the surface; the top plate (6) has none. The middle divider plates (5) are noticeably thinner-gauge metal than the other two. Figure 17 Gate Housing assembly Reference Part...
  • Page 13 Caution: During assembly, the shutter springs can pop out of place. Always wear protective eyewear during this procedure. 12. Place iris slot cover (9) over the iris slot. Use two screws (10) to secure the cover. Source Four Zoom Assembly Guide...

  • Page 14: 30º Lens Tube Assembly

    Figure 19 15°-30° lens tube assembly Gel frame endcap assembly Figure 20 Figure 21 Figure 22 Rear lens assembly Front lens assembly Electronic Theatre Controls, Inc.

  • Page 15: Gel Frame Endcap Assembly

    Required HW4117 Washer, flat, Teflon HW4112 Screw, #10-14 x 5/8, plastic HW3118 Washer, flat #8, zinc HW3114 Screw, 8-32 x 2, PHST plastic 7060A4051 Rear gear rack 7060A4068 Rear lens glass 7060A4048 Rear lens holder Source Four Zoom Assembly Guide...
  • Page 16 Figure 23 25°-50° lens tube assembly Figure 24 Gel frame endcap assembly Figure 25 Figure 26 Front lens assembly Rear lens assembly Electronic Theatre Controls, Inc.

  • Page 17: Gel Frame Endcap Assembly

    Description Quantity Number Number Required 7060A4048 Rear lens holder 7060A4070 Rear lens glass 7060A4053 Rear gear rack HW4117 Washer, flat, Teflon HW4112 Screw, #10 - 10x5/8, plastic HW3116 Screw, 8-10x1-1/2 HW3118 Washer, flat #8, zinc Source Four Zoom Assembly Guide...
  • Page 18 Assembling the lens tube; 15°-30° and 25°-50° alligned hash marks rear lens front lens Figure 27 gear teeth Figure 28 1. Slide the front lens holder (3) into the left-hand top raceway as shown in figure 27. 2. Slide the rear lens holder (4) into the left-hand bottom raceway as shown in figure 27.
  • Page 19 2. Starting from the center, gently wipe the lens. Note: Refer to the Source Four Zoom User Guide instruction booklet, included with your fixture, for information regarding lens tube orientation and lens position when cleaning.
  • Page 20 Revised 2/00. Part number 7060M1010 This document is the confidental property of ETC and is loaned subject to return upon demand. Title to this document is never sold or transferred for any reason. This document is to be used only pursuant to written...
