Fixture Hanger
58
2.18 in
55.4 mm
7.05 in
179 mm
• Fixture hanger for mounting fixtures without track
adapters to DataTrack Backbone
• Uses wingnut bolt to secure hanger to DataTrack
Backbone
• Combination of steel and nylon washers provides
both the secure mounting of the fixture yoke to the
hanger and the ability to hand-focus the fixture
DataTrack Backbone
Color
Black
White
Silver
Custom
5.25 in
133.4 mm
DataTrack/DataTrack Backbone System Planning and Installation Manual
Model Number
DTB-FH-BLK
DTB-FH-WHT
DTB-FH-SLV
DTB-FH-CST
1.81 in
46 mm
1.5 in
38.1 mm
