Current Limiters

Note:
End-feed: Ground Left or Right
1.37 in
34.9 mm
Parts and Accessories
Title 24 compliant limiters are also available and include a 12 in (30.48 cm)
permanently attached track section in compliance with California Title 20/24
requirements.
5.64 in
143.2 mm
Title 24 Compliant
12 in
304.8 mm
• End power feed with overcurrent device
• Overcurrent devices must be ordered separately (see
Overcurrent Device
on
• Can be used in a DataTrack Backbone installation,
but will not be supported within the DataTrack
Backbone
DataTrack
Ground Color
Black
Right White
Silver
Black
Left White
Silver
Black
Right
(Title 24 White
compliant)
Silver
Black
Left
(Title 24 White
compliant)
Silver
1.73 in
44.0 mm
5.64 in
143.2 mm
page 47
for options)
Model Number
EDTREFCL-GR
EDTREFCL-GR-1
EDTREFCL-GR-5
EDTREFCL-GL
EDTREFCL-GL-1
EDTREFCL-GL-5
EDTREFCLT24-GR
EDTREFCLT24-GR-1
EDTREFCLT24-GR-5
EDTREFCLT24-GL
EDTREFCLT24-GL-1
EDTREFCLT24-GL-5
