Problem
Multi adapter will not
close after data bus
contact is installed and
wiring connected
Multi adapter will not
close after inserting
nipple
No data through current
limiter
Uncertainty if current
limiter is T24 compliant
Uncertainty if NT24 can
be converted to T24 in
the field
30
Troubleshooting
• Check wiring routing and
connections are properly
secured
• Make sure nipple is installed
properly
• Verify the two cover screws
are aligned properly
• Make sure wires are not
interfering with cover
• Check overcurrent device on
limiter
• Check that end feeds are
correct and able to transfer
data
• Check track to be data bus
equipped
• Check that the breaker is the
correct amperage for the
track installed
• 12 in (30.48 cm) track
section is secured to limiter
on end feed with theft-
resistant fastener
• Cannot be converted in field • Order correct limiter model if not correct.
• Open adapter by removing two side screws.
Check connections and routing.
• Verify nipple is installed properly, making sure
the notch on the nipple is locked in place with
the rib on the inside of adapter.
• Make sure data bus contact is installed
properly.
• Make sure correct data bus contact is installed.
• The notches on the nipple should align with
rib on adapter to prevent free turning.
• Remove screws, align side cover of adapter
with screw holes. Hand-start one screw and
then the other.
• Finish securing screws with screwdriver.
• Remove cover. Tuck any loose wires out of the
way when closing the cover. Never interfere
with wire connections.
• If tripped, reset overcurrent device.
• If incorrect end feeds are installed, reorder
correct ones.
• Order correct track if not equipped with data.
• Change breaker to correct amperage required.
• Order correct limiter if not correct.
DataTrack/DataTrack Backbone System Planning and Installation Manual
Remedy
